YOLOv8 实时目标检测:使用 OpenCV 调用摄像头
要调用摄像头进行实时目标识别,您可以使用 OpenCV 库来获取视频流并使用 YOLOv8 模型进行实时推理。以下是一个基本的示例代码:
import cv2
import numpy as np
# 加载 YOLOv8 模型
net = cv2.dnn.readNet('yolov8.weights', 'yolov8.cfg')
# 获取输出层
layer_names = net.getLayerNames()
output_layers = [layer_names[i[0] - 1] for i in net.getUnconnectedOutLayers()]
# 读取摄像头视频流
cap = cv2.VideoCapture(0)
while True:
# 读取视频流帧
ret, frame = cap.read()
# 将帧转换为 blob
height, width, channels = frame.shape
blob = cv2.dnn.blobFromImage(frame, 0.00392, (416, 416), (0, 0, 0), True, crop=False)
# 将 blob 输入到模型中进行推理
net.setInput(blob)
outs = net.forward(output_layers)
# 解析模型输出并绘制边界框
class_ids = []
confidences = []
boxes = []
for out in outs:
for detection in out:
scores = detection[5:]
class_id = np.argmax(scores)
confidence = scores[class_id]
if confidence > 0.5: # 置信度阈值
# 边界框坐标
center_x = int(detection[0] * width)
center_y = int(detection[1] * height)
w = int(detection[2] * width)
h = int(detection[3] * height)
x = int(center_x - w / 2)
y = int(center_y - h / 2)
boxes.append([x, y, w, h])
confidences.append(float(confidence))
class_ids.append(class_id)
# 非最大抑制处理
indexes = cv2.dnn.NMSBoxes(boxes, confidences, 0.5, 0.4)
# 绘制边界框和类别标签
font = cv2.FONT_HERSHEY_SIMPLEX
for i in range(len(boxes)):
if i in indexes:
x, y, w, h = boxes[i]
label = str(class_ids[i])
confidence = confidences[i]
color = (0, 255, 0) # 边界框颜色 (BGR 格式)
cv2.rectangle(frame, (x, y), (x + w, y + h), color, 2)
cv2.putText(frame, label + ' ' + str(round(confidence, 2)), (x, y - 10), font, 0.5, color, 2)
# 显示视频流帧
cv2.imshow('Real-time Object Detection', frame)
if cv2.waitKey(1) == ord('q'): # 按下 'q' 键退出
break
# 释放摄像头和销毁窗口
cap.release()
cv2.destroyAllWindows()
请注意,您需要将 YOLOv8 的权重文件 ('yolov8.weights') 和配置文件 ('yolov8.cfg') 放在与代码文件相同的目录下,并根据您的实际文件名进行替换。
此示例代码将打开摄像头并实时显示视频流,同时在检测到的目标周围绘制边界框。您可以根据需要进行调整,例如更改置信度阈值、边界框颜色或添加其他处理步骤。
