手势识别与机器人控制：基于 Unitree 摄像头和 PaddleLite 的实时实现

/*

• Copyright (C) 2023 Coder.AN
• Email: an.hongjun@foxmail.com
• This program is free software: you can redistribute it and/or modify
• it under the terms of the GNU General Public License as published by
• the Free Software Foundation, either version 3 of the License, or
• (at your option) any later version.
• This program is distributed in the hope that it will be useful,
• but WITHOUT ANY WARRANTY; without even the implied warranty of
• MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
• GNU General Public License for more details.
• You should have received a copy of the GNU General Public License
• along with this program. If not, see https://www.gnu.org/licenses/. */ #include <unistd.h> #include <stdlib.h> #include <UnitreeCameraSDK.hpp>

#include "viz.h" #include "opencv.h" #include "LinuxUdp.h" #include "paddle_api.h"

using namespace LinuxUdp; using namespace paddle::lite_api;

static const int INPUT_W = 320; static const int INPUT_H = 320;

struct PACK { float delta_w; float delta_h; int mode; };

int64_t ShapeProduction(const shape_t& shape) { int64_t res = 1; for (auto i : shape) res *= i; return res; }

void blobFromImage(cv::Mat& img, float* blob){ int img_h = img.rows; int img_w = img.cols; for (size_t h = 0; h < img_h; h++) { for (size_t w = 0; w < img_w; w++) { cv::Vec3b pix = img.atcv::Vec3b(h, w); float r = (float)pix[0]; float g = (float)pix[1]; float b = (float)pix[2]; r = ((r / 255.0) - 0.485) / 0.229; g = ((g / 255.0) - 0.456) / 0.224; b = ((b / 255.0) - 0.406) / 0.225; blob[0 * img_w * img_h + h * img_w + w] = r; blob[1 * img_w * img_h + h * img_w + w] = g; blob[2 * img_w * img_h + h * img_w + w] = b; } } }

int main(int argc, char *argv[]){ UdpClient udp_client("192.168.123.161", 8900);

// init unitree camera
int deviceNode = 1;
cv::Size frameSize(928, 400); ///< default frame size 1856x800
int fps = 100; ///< default camera fps: 30
UnitreeCamera cam(deviceNode); ///< init camera by device node number
if(!cam.isOpened())   ///< get camera open state
    exit(EXIT_FAILURE);
cam.setRawFrameSize(frameSize); ///< set camera frame size
cam.setRawFrameRate(fps);       ///< set camera camera fps
cam.setRectFrameSize(cv::Size(frameSize.width >> 2, frameSize.height >> 1)); ///< set camera rectify frame size
cam.startCapture(); ///< disable image h264 encoding and share memory sharing

// init predictor
MobileConfig config;
config.set_model_from_file("shared/voc_hand.nb");
config.set_power_mode(static_cast<paddle::lite_api::PowerMode>(0));
config.set_threads(4);
std::shared_ptr<PaddlePredictor> predictor = CreatePaddlePredictor<MobileConfig>(config);
std::unique_ptr<Tensor> image_tensor(std::move(predictor->GetInputByName("image")));
std::unique_ptr<Tensor> scale_tensor(std::move(predictor->GetInputByName("scale_factor")));
image_tensor->Resize({1, 3, INPUT_H, INPUT_W});
scale_tensor->Resize({1, 2});
auto* image_data = image_tensor->mutable_data<float>();
auto* scale_data = scale_tensor->mutable_data<float>();
scale_data[1] = INPUT_W / ((frameSize.width >> 2) * 1.0);
scale_data[0] = INPUT_H / ((frameSize.height >> 1) * 1.0);


usleep(500000);
std::vector<uint8_t> buffer;
cv::Mat img, rgb_img, pr_img;

PACK pack;

while(cam.isOpened()){
    // read img
    cv::Mat left,right;
    if(!cam.getRectStereoFrame(left,right)){ ///< get rectify left,right frame
        usleep(1000);
        continue;
    }
    cv::flip(left, img, -1);

    // preprocess
    cv::cvtColor(img, rgb_img, cv::COLOR_BGR2RGB);
    cv::resize(rgb_img, pr_img, cv::Size(INPUT_W, INPUT_H));
    blobFromImage(pr_img, image_data);

    // predict
    predictor->Run();

    // postprocess
    std::unique_ptr<const Tensor> res_tensor(std::move(predictor->GetTensor("multiclass_nms3_0.tmp_0")));
    std::unique_ptr<const Tensor> num_tensor(std::move(predictor->GetTensor("multiclass_nms3_0.tmp_2")));
    auto res_data = res_tensor->data<float>();
    auto num_data = num_tensor->data<int>();
    std::cout << num_data[0] << std::endl;

    int max_cls = -1;
    float max_area = 0;
    float cx, cy;

    // viz
    for (int i = 0; i < num_data[0]; i++)
    {
        const float* res = res_data + i * 6;
        int cls = int(res[0]);
        if (cls == 3) continue; // no_gesture
        float score = res[1];
        if (score < 0.6) continue;
        float x1 = res[2];
        float y1 = res[3];
        float x2 = res[4];
        float y2 = res[5];
        float area = (x2 - x1) * (y2 - y1);
        if (area > max_area)
        {
            cx = (x1 + x2) / 2.0;
            cy = (y1 + y2) / 2.0;
            max_area = area;
            max_cls = cls;
        }
        printf("cls:%d score:%.2f x1:%.2f y1:%.2f x2:%.2f y2:%.2f\n", cls, score, x1, y1, x2, y2);
        viz(img, cls, score, x1, y1, x2 - x1, y2 - y1);
    }

    if (max_cls != -1)
    {
        pack.delta_w = (frameSize.width >> 3) - cx;
        pack.delta_h = (frameSize.height >> 2) - cy;
        if (max_cls == 0)
        {
            pack.mode = 1;  // 跳舞
            pack.delta_w = 0;
            pack.delta_h = 0;
        }
        else if (max_cls == 1)
        {
            pack.mode = 0;  // 跟随
        }
        else if (max_cls == 2)
        {
            pack.mode = 2;  // 停止
        }
    }
    else
    {
        pack.mode = -1;
        pack.delta_w = 0;
        pack.delta_h = 0;
    }
    printf("mode:%d delta_w:%.2f delta_h:%.2f\n", pack.mode, pack.delta_w, pack.delta_h);
    udp_client.UdpSend((void*)&pack, sizeof(PACK));

    // cv::imshow("demo", img);
    // cv::waitKey(5);
}

cam.stopCapture(); ///< stop camera capturing

return 0;

}

该程序是一个手势识别的示例，可以使用Unitree摄像头获取实时视频流并对其进行预测。程序首先通过UnitreeCameraSDK初始化摄像头，然后使用opencv库对图像进行预处理，例如：调整图像大小，转换图像通道。接着，使用PaddleLite API加载训练好的模型来预测手势，预测结果会被用于控制机器人的行为。最后，程序使用LinuxUdp库将机器人的行为发送给远程机器人。
