设计神经网络对 minist 数据集进行分类使模型在测试集上的准确率最高分析的时候要求 Loss-acc 图混淆矩阵分析每一类的识别准确率。

首先，我们可以使用Python中的PyTorch库来设计神经网络并对minist数据集进行分类。下面是一个基本的代码框架，你可以在此基础上进行修改和扩展。

import torch
import torch.nn as nn
import torch.optim as optim
import torch.nn.functional as F
from torch.utils.data import DataLoader
from torchvision.datasets import MNIST
from torchvision.transforms import ToTensor
from sklearn.metrics import confusion_matrix
import matplotlib.pyplot as plt
import numpy as np

# 设置随机种子
torch.manual_seed(123)

# 加载数据集
train_dataset = MNIST(root='./data', train=True, transform=ToTensor(), download=True)
test_dataset = MNIST(root='./data', train=False, transform=ToTensor(), download=True)

# 创建数据加载器
train_loader = DataLoader(train_dataset, batch_size=64, shuffle=True)
test_loader = DataLoader(test_dataset, batch_size=64, shuffle=False)

# 定义神经网络模型
class Net(nn.Module):
    def __init__(self):
        super(Net, self).__init__()
        self.fc1 = nn.Linear(784, 128)
        self.fc2 = nn.Linear(128, 64)
        self.fc3 = nn.Linear(64, 10)

    def forward(self, x):
        x = x.view(-1, 784)
        x = F.relu(self.fc1(x))
        x = F.relu(self.fc2(x))
        x = self.fc3(x)
        return x

model = Net()

# 定义损失函数和优化器
criterion = nn.CrossEntropyLoss()
optimizer = optim.SGD(model.parameters(), lr=0.01)

# 训练模型
losses = []
accuracies = []
for epoch in range(10):
    running_loss = 0.0
    correct = 0
    total = 0
    for i, data in enumerate(train_loader, 0):
        inputs, labels = data
        optimizer.zero_grad()
        outputs = model(inputs)
        loss = criterion(outputs, labels)
        loss.backward()
        optimizer.step()

        # 计算准确率
        _, predicted = torch.max(outputs.data, 1)
        total += labels.size(0)
        correct += (predicted == labels).sum().item()

        running_loss += loss.item()
        if i % 100 == 99:
            losses.append(running_loss / 100)
            accuracies.append(correct / total)
            running_loss = 0.0
            correct = 0
            total = 0

# 绘制 Loss-acc 图
plt.figure(figsize=(10, 5))
plt.subplot(1, 2, 1)
plt.plot(losses)
plt.xlabel('Iterations')
plt.ylabel('Loss')

plt.subplot(1, 2, 2)
plt.plot(accuracies)
plt.xlabel('Iterations')
plt.ylabel('Accuracy')

# 在测试集上评估模型
model.eval()
all_labels = []
all_predictions = []
with torch.no_grad():
    for data in test_loader:
        images, labels = data
        outputs = model(images)
        _, predicted = torch.max(outputs.data, 1)
        all_labels.extend(labels.numpy())
        all_predictions.extend(predicted.numpy())

# 计算混淆矩阵
cm = confusion_matrix(all_labels, all_predictions)

# 绘制混淆矩阵
plt.figure(figsize=(10, 8))
plt.imshow(cm, interpolation='nearest', cmap=plt.cm.Blues)
plt.colorbar()
plt.xticks(np.arange(10))
plt.yticks(np.arange(10))
plt.xlabel('Predicted Label')
plt.ylabel('True Label')
plt.title('Confusion Matrix')

# 分析每一类的识别准确率
class_acc = cm.diagonal() / cm.sum(axis=1)
plt.figure(figsize=(10, 5))
plt.bar(np.arange(10), class_acc)
plt.xlabel('Class')
plt.ylabel('Accuracy')

plt.show()

这个代码会训练一个包含两个隐藏层的神经网络，每个隐藏层都有ReLU激活函数。训练完成后，会绘制训练过程中的Loss-acc图、混淆矩阵和每一类的识别准确率柱状图。你可以通过调整网络结构、优化器、学习率等参数，以期望在测试集上获得最高的准确率。
