Please paraphrase the following paragraph Using the MODE pin the SGM5100SGM5101 parallel digital output can be selected for offset binary or 2’s complement format Connecting MODE to GND or 13VDD selec
The SGM5100/SGM5101 parallel digital output can be chosen to be in offset binary or 2's complement format by using the MODE pin. When the MODE pin is connected to GND or 1/3VDD, the offset binary output format is selected. On the other hand, connecting the MODE pin to 2/3VDD or VDD selects the 2's complement output format. The logic values of 1/3VDD or 2/3VDD can be set using an external resistor divider. The logic states for the MODE pin are shown in Table 2.
