The offset binary or 2's complement format of the LTC2248/LTC2247/LTC2246 parallel digital output can be chosen by using the MODE pin. By connecting MODE to GND or 1/3VDD, offset binary output format is selected. On the other hand, connecting MODE to 2/3VDD or VDD selects 2's complement output format. The logic values of 1/3VDD or 2/3VDD can be set using an external resistor divider. Table 2 provides the logic states for the MODE pin.

Please paraphrase the following paragraph Using the MODE pin the LTC2248LTC2247LTC2246 parallel digital output can be selected for offset binary or 2’s complement format Connecting MODE to GND or 13VD
