InOutScope Name Type Initial CommentInput MODE GEN_MODE Types availableTRIANGLE Triangular from -AMPLITUDE to +AMPLITUDETRIANGLE_POS Triangular from 0 to +AMPLITUDESAWTOOTH_RISE Sawtooth increasing

Description:

The InOut table defines the inputs, outputs, and variables used in a function generator. The input MODE selects the type of waveform to be generated, with options for triangular, sawtooth, rectangular, sine, and cosine waveforms. The BASE input selects whether the period is defined by the number of cycles or a specific time period. If BASE is set to TRUE, the PERIOD input defines the time period of the waveform, while if BASE is set to FALSE, the CYCLES input defines the number of cycles per period. The AMPLITUDE input sets the amplitude of the waveform to be generated.

The RESET input, when set to TRUE, resets the output value to zero. The output OUT is the generated function value, which varies based on the selected waveform type and other input parameters
