基于 Zernike 矩的亚像素边缘检测 MATLAB 实现
基于 Zernike 矩的亚像素边缘检测 MATLAB 实现
本文提供一个基于 Zernike 矩的亚像素边缘检测算法的 MATLAB 实现示例。
代码:
% 输入图像
image = imread('image.jpg');
% 转换为灰度图像
gray_image = rgb2gray(image);
% 计算图像的大小
[height, width] = size(gray_image);
% 定义Zernike矩的阶数
n = 7;
% 定义Zernike矩的模板
M = zeros(n+1, n+1);
M(1, 1) = 1;
M(2, 1) = 1;
M(2, 2) = 1;
M(3, 1) = 2;
M(3, 3) = 1;
M(4, 1) = 3;
M(4, 2) = 3;
M(4, 3) = 1;
M(4, 4) = 1;
M(5, 1) = 6;
M(5, 2) = 10;
M(5, 3) = 4;
M(5, 4) = 1;
M(5, 5) = 1;
% 初始化边缘点坐标
edge_points = [];
% 遍历图像的每个像素点
for i = 1:height
for j = 1:width
% 计算Zernike矩
Z = zeros(n+1, n+1);
for p = 1:n+1
for q = 1:n+1
Z(p, q) = sum(sum(double(gray_image) .* M(p, q) .* exp(1i * angle(double(gray_image)))));
end
end
% 计算边缘角度
angle_Z31 = atan2(imag(Z(4, 1)), real(Z(4, 1)));
% 计算边缘长度
l1 = sqrt((5*real(Z(5, 1)) + 3*real(Z(3, 1))) / (8*real(Z(3, 1))));
l2 = sqrt((5*real(Z(4, 1)) + real(Z(2, 1))) / (6*real(Z(2, 1))));
l = (l1 + l2) / 2;
% 计算k和h
k = 3 * real(Z(2, 1)) / (2 * (1 - l2^2)^(3/2));
h = (real(Z(1, 1)) - (k*pi)/2 + k*asin(l2) + k*l2*sqrt(1-l2^2)) / pi;
% 判断是否为边缘点
kt = 0.1; % k的判断阈值
lt = 0.1; % |l2 - l1|的判断阈值
if k >= kt && abs(l2 - l1) <= lt
% 保存边缘点坐标
edge_points = [edge_points; j, i];
end
end
end
% 显示原始图像
subplot(1, 2, 1);
imshow(image);
title('Original Image');
% 显示边缘检测结果
subplot(1, 2, 2);
imshow(image);
hold on;
plot(edge_points(:, 1), edge_points(:, 2), 'r.');
title('Edge Detection Result');
hold off;
代码解释:
- 读取图像并转换为灰度图像: 使用
imread函数读取图像,使用rgb2gray函数将彩色图像转换为灰度图像。 - 定义 Zernike 矩的阶数和模板: 设置 Zernike 矩的阶数
n,并定义对应的 Zernike 矩模板M。 - 遍历图像像素点: 使用嵌套循环遍历图像中的每个像素点。
- 计算 Zernike 矩: 对于每个像素点,根据定义计算其对应的 Zernike 矩
Z。 - 计算边缘参数: 根据 Zernike 矩计算边缘角度
angle_Z31,以及边缘长度l1、l2和l。 - 计算参数 k 和 h: 根据公式计算参数
k和h。 - 判断边缘点: 根据预设的阈值
kt和lt,判断当前像素点是否为边缘点。 - 保存边缘点坐标: 如果当前像素点为边缘点,则将其坐标保存到
edge_points数组中。 - 显示结果: 使用
subplot和imshow函数显示原始图像和边缘检测结果。
注意:
- 该代码仅提供一个基本的框架,具体的阈值和参数需要根据实际情况进行调整。
- 代码中使用了图像处理工具箱中的函数
rgb2gray和imshow,请确保已安装并加载该工具箱。
希望以上内容能够帮助您理解如何使用 MATLAB 实现基于 Zernike 矩的亚像素边缘检测算法。
