Java POI Excel 折线图生成示例：P9 和 P10 数据对比

import org.apache.poi.ss.util.CellRangeAddress; import org.apache.poi.xddf.usermodel.chart.; import org.apache.poi.xssf.usermodel.;

import javax.imageio.ImageIO; import java.awt.*; import java.awt.image.BufferedImage; import java.io.File; import java.io.FileInputStream; import java.io.FileOutputStream; import java.io.IOException;

public class ExcelChartExample03 {

public static void main(String[] args) {
    try {
        // 读取Excel文件
        FileInputStream fileIn = new FileInputStream('巴新EDEVU水库数据处理表.xlsx');
        XSSFWorkbook workbook = new XSSFWorkbook(fileIn);
        XSSFSheet sheet1 = workbook.getSheet('P9');
        XSSFSheet sheet2 = workbook.getSheet('P10');
        XSSFSheet sheet3 = workbook.getSheet('温度');

        // 创建折线图
        XSSFDrawing drawing = sheet3.createDrawingPatriarch();
        XSSFClientAnchor anchor = drawing.createAnchor(0, 0, 0, 0, 0, 0, 10, 20);
        XSSFChart chart = drawing.createChart(anchor);
        chart.setTitleText('数据折线图');
        chart.setTitleOverlay(false);

        // 设置图例位置
        XDDFChartLegend legend = chart.getOrAddLegend();
        legend.setPosition(LegendPosition.BOTTOM);

        // 创建数据系列
        XDDFCategoryAxis bottomAxis = chart.createCategoryAxis(AxisPosition.BOTTOM);
        XDDFValueAxis leftAxis = chart.createValueAxis(AxisPosition.LEFT);
        leftAxis.setCrosses(AxisCrosses.AUTO_ZERO);

        // 创建数据源
        XDDFNumericalDataSource<Double> xs1 = XDDFDataSourcesFactory.fromNumericCellRange(sheet1, new CellRangeAddress(11, 85, 0, 0));
        XDDFNumericalDataSource<Double> ys1 = XDDFDataSourcesFactory.fromNumericCellRange(sheet1, new CellRangeAddress(11, 85, 2, 2));
        XDDFNumericalDataSource<Double> xs2 = XDDFDataSourcesFactory.fromNumericCellRange(sheet2, new CellRangeAddress(11, 139, 0, 0));
        XDDFNumericalDataSource<Double> ys2 = XDDFDataSourcesFactory.fromNumericCellRange(sheet2, new CellRangeAddress(11, 139, 2, 2));

        // 添加数据系列
        XDDFLineChartData data = (XDDFLineChartData) chart.createData(ChartTypes.LINE, bottomAxis, leftAxis);
        XDDFLineChartData.Series series1 = (XDDFLineChartData.Series) data.addSeries(xs1, ys1);
        series1.setTitle('P9数据折线图', null);
        XDDFLineChartData.Series series2 = (XDDFLineChartData.Series) data.addSeries(xs2, ys2);
        series2.setTitle('P10数据折线图', null);

        // 绘制图表
        chart.plot(data);

        // 绘制图表到图片
        BufferedImage image = new BufferedImage(800, 600, BufferedImage.TYPE_INT_RGB);
        Graphics2D graphics = image.createGraphics();
        chart.getCTChart().getPlotArea().getRadarChartArray();
        chart.plot(data);

        // 设置字体（解决图片为空问题）
        GraphicsEnvironment ge = GraphicsEnvironment.getLocalGraphicsEnvironment();
        Font font = new Font('Arial', Font.PLAIN, 12);
        ge.registerFont(font);
        graphics.setFont(font);

        // 保存图片文件
        ImageIO.write(image, 'png', new File('折线图.png'));

        // 保存Excel文件
        FileOutputStream fileOut = new FileOutputStream('巴新EDEVU水库数据处理表.xlsx');
        workbook.write(fileOut);
        fileOut.close();

        System.out.println('折线图已创建并保存到Excel文件和图片中。');

    } catch (IOException e) {
        e.printStackTrace();
    }
}

}
