Java Apache POI 创建 Excel 折线图

import org.apache.poi.ss.util.CellRangeAddress;
import org.apache.poi.xddf.usermodel.chart.*;
import org.apache.poi.xssf.usermodel.*;

import javax.imageio.ImageIO;
import java.awt.*;
import java.awt.image.BufferedImage;
import java.io.File;
import java.io.FileInputStream;
import java.io.FileOutputStream;
import java.io.IOException;

public class ExcelChartExample03 {

    public static void main(String[] args) {
        try {
            // 读取Excel文件
            FileInputStream fileIn = new FileInputStream('巴新EDEVU水库数据处理表.xlsx');
            XSSFWorkbook workbook = new XSSFWorkbook(fileIn);
            XSSFSheet sheet1 = workbook.getSheet('P9');
            XSSFSheet sheet2 = workbook.getSheet('P10');
            XSSFSheet sheet3 = workbook.getSheet('温度');

            // 创建折线图
            XSSFDrawing drawing = sheet3.createDrawingPatriarch();
            XSSFClientAnchor anchor = drawing.createAnchor(0, 0, 0, 0, 0, 0, 10, 20);
            XSSFChart chart = drawing.createChart(anchor);
            chart.setTitleText('数据折线图');
            chart.setTitleOverlay(false);

            // 设置图例位置
            XDDFChartLegend legend = chart.getOrAddLegend();
            legend.setPosition(LegendPosition.BOTTOM);

            // 创建数据系列
            XDDFCategoryAxis bottomAxis = chart.createCategoryAxis(AxisPosition.BOTTOM);
            XDDFValueAxis leftAxis = chart.createValueAxis(AxisPosition.LEFT);
            leftAxis.setCrosses(AxisCrosses.AUTO_ZERO);

            // 创建数据源
            XDDFNumericalDataSource<Double> xs1 = XDDFDataSourcesFactory.fromNumericCellRange(sheet1, new CellRangeAddress(11, 85, 0, 0));
            XDDFNumericalDataSource<Double> ys1 = XDDFDataSourcesFactory.fromNumericCellRange(sheet1, new CellRangeAddress(11, 85, 2, 2));
            XDDFNumericalDataSource<Double> xs2 = XDDFDataSourcesFactory.fromNumericCellRange(sheet2, new CellRangeAddress(11, 139, 0, 0));
            XDDFNumericalDataSource<Double> ys2 = XDDFDataSourcesFactory.fromNumericCellRange(sheet2, new CellRangeAddress(11, 139, 2, 2));

            // 添加数据系列
            XDDFLineChartData data = (XDDFLineChartData) chart.createData(ChartTypes.LINE, bottomAxis, leftAxis);
            XDDFLineChartData.Series series1 = (XDDFLineChartData.Series) data.addSeries(xs1, ys1);
            series1.setTitle('P9数据折线图', null);
            XDDFLineChartData.Series series2 = (XDDFLineChartData.Series) data.addSeries(xs2, ys2);
            series2.setTitle('P10数据折线图', null);

            // 绘制图表
            chart.plot(data);

            // **解决纯黑图片问题**
            // 添加字体库文件，例如 simsun.ttc
            String fontPath = 'simsun.ttc';
            Font font = Font.createFont(Font.TRUETYPE_FONT, new File(fontPath));
            GraphicsEnvironment ge = GraphicsEnvironment.getLocalGraphicsEnvironment();
            ge.registerFont(font);

            // 绘制图表到图片
            BufferedImage image = new BufferedImage(800, 600, BufferedImage.TYPE_INT_RGB);
            Graphics2D graphics = image.createGraphics();
            graphics.setFont(font); // 设置字体
            chart.plot(data, new ChartRenderingInfo(new ChartDrawingFormat(graphics)));

            // 保存图片文件
            ImageIO.write(image, 'png', new File('折线图.png'));

            // 保存Excel文件
            FileOutputStream fileOut = new FileOutputStream('巴新EDEVU水库数据处理表.xlsx');
            workbook.write(fileOut);
            fileOut.close();

            System.out.println('折线图已创建并保存到Excel文件和图片中。');

        } catch (IOException | FontFormatException e) {
            e.printStackTrace();
        }
    }
}
