以下是使用 TypeScript 语言编写的 Cocos Creator 中拖拽物体的代码:

  1. 首先,需要在场景中创建一个节点,并将其添加到 Canvas 节点下。创建一个脚本组件,命名为 DragObject。

  2. 在 DragObject 组件中,先定义需要使用的变量:

const {ccclass, property} = cc._decorator;

@ccclass
export default class DragObject extends cc.Component {

    // 需要拖拽的节点
    @property(cc.Node)
    dragNode: cc.Node = null;

    // 是否可以拖拽
    @property()
    canDrag: boolean = true;

    // 是否限制在父节点范围内
    @property()
    limitParent: boolean = false;

    // 父节点
    private parent: cc.Node = null;

    // 偏移量
    private offset: cc.Vec2 = cc.v2(0, 0);
}
  1. 在 onLoad 生命周期回调函数中,初始化变量:
onLoad () {
    // 获取父节点
    this.parent = this.node.parent;

    // 绑定事件
    this.node.on(cc.Node.EventType.TOUCH_START, this.onTouchStart, this);
    this.node.on(cc.Node.EventType.TOUCH_MOVE, this.onTouchMove, this);
    this.node.on(cc.Node.EventType.TOUCH_END, this.onTouchEnd, this);
    this.node.on(cc.Node.EventType.TOUCH_CANCEL, this.onTouchCancel, this);
}
  1. 实现触摸事件回调函数:
private onTouchStart (event: cc.Touch) {
    if (!this.canDrag) return;

    // 计算偏移量
    const worldPos = this.node.convertToWorldSpaceAR(this.dragNode.position);
    const localPos = this.parent.convertToNodeSpaceAR(worldPos);
    this.offset = localPos.sub(event.getLocation());

    // 改变节点的层级顺序,使其置于最上层
    this.node.setSiblingIndex(this.parent.childrenCount - 1);
}

private onTouchMove (event: cc.Touch) {
    if (!this.canDrag) return;

    // 计算新的位置
    const pos = event.getLocation().add(this.offset);

    // 限制位置在父节点范围内
    if (this.limitParent) {
        const minX = -this.parent.width / 2 + this.dragNode.width / 2;
        const maxX = this.parent.width / 2 - this.dragNode.width / 2;
        const minY = -this.parent.height / 2 + this.dragNode.height / 2;
        const maxY = this.parent.height / 2 - this.dragNode.height / 2;

        pos.x = cc.misc.clamp(pos.x, minX, maxX);
        pos.y = cc.misc.clamp(pos.y, minY, maxY);
    }

    // 更新节点位置
    this.dragNode.position = this.parent.convertToNodeSpaceAR(pos);
}

private onTouchEnd (event: cc.Touch) {
    // do something
}

private onTouchCancel (event: cc.Touch) {
    // do something
}
  1. 最后,在脚本组件上挂载需要拖拽的节点,并设置相应的属性即可。
@property(cc.Node)
dragNode: cc.Node = null;

@property()
canDrag: boolean = true;

@property()
limitParent: boolean = false;

以上就是使用 TypeScript 语言编写的 Cocos Creator 中拖拽物体的代码。
