这里是一份使用Python实现对复合波进行傅里叶时频变换和傅里叶反变换的代码:

import numpy as np
import matplotlib.pyplot as plt

# 定义复合波
fs = 1000  # 采样频率
t = np.arange(0, 1, 1/fs)  # 时间序列
f1 = 10  # 基频1
f2 = 50  # 基频2
f3 = 100  # 基频3
x = np.sin(2*np.pi*f1*t) + 0.5*np.sin(2*np.pi*f2*t) + 0.2*np.sin(2*np.pi*f3*t)

# 进行傅里叶变换
X = np.fft.fft(x)
freq = np.fft.fftfreq(len(x), 1/fs)

# 绘制时域和频域波形
fig, ax = plt.subplots(2, 1, figsize=(6, 6))
ax[0].plot(t, x)
ax[0].set_xlabel('Time (s)')
ax[0].set_ylabel('Amplitude')
ax[0].set_title('Time-domain waveform')
ax[1].plot(freq, np.abs(X))
ax[1].set_xlabel('Frequency (Hz)')
ax[1].set_ylabel('Magnitude')
ax[1].set_title('Frequency-domain waveform')
plt.tight_layout()
plt.show()

# 进行傅里叶反变换
x_new = np.fft.ifft(X)
t_new = np.arange(0, len(x), 1) / fs

# 绘制反变换后的时域波形
fig, ax = plt.subplots(1, 1, figsize=(6, 3))
ax.plot(t_new, x_new.real)
ax.set_xlabel('Time (s)')
ax.set_ylabel('Amplitude')
ax.set_title('Time-domain waveform after inverse Fourier transform')
plt.tight_layout()
plt.show()

在上面的代码中,我们首先定义了一个复合波,包括三个基频分别为10Hz、50Hz和100Hz的正弦波。然后使用np.fft.fft()函数进行傅里叶变换,得到频域波形和对应的频率轴。我们使用plt.subplots()函数创建了一个2x1的子图,分别绘制时域和频域波形。

接着,我们使用np.fft.ifft()函数进行傅里叶反变换,得到反变换后的时域波形,并使用plt.subplots()函数创建了一个1x1的子图绘制反变换后的时域波形。

最后,我们使用plt.show()函数显示绘制的图形。你可以运行这段代码,查看程序的输出结果。
