红黑树c++-实现
红黑树是一种自平衡的二叉查找树,具有以下特点:
-
每个节点要么是红色,要么是黑色
-
根节点是黑色的
-
每个叶子节点(NIL节点,空节点)是黑色的
-
如果一个节点是红色的,则它的两个子节点都是黑色的(反之不一定成立)
-
对于每个节点,从该节点到其所有后代叶子节点的简单路径上,均包含相同数目的黑色节点
基于以上特点,我们可以实现红黑树的插入、删除、查找等操作。
以下是红黑树的C++实现代码:
#include <iostream>
using namespace std;
enum Color { RED, BLACK };
struct Node {
int data;
Color color;
Node *left, *right, *parent;
Node(int data) {
this->data = data;
color = RED;
left = right = parent = nullptr;
}
};
class RedBlackTree {
private:
Node *root;
void leftRotate(Node *&x) {
Node *y = x->right;
x->right = y->left;
if (y->left != nullptr)
y->left->parent = x;
y->parent = x->parent;
if (x->parent == nullptr)
root = y;
else if (x == x->parent->left)
x->parent->left = y;
else
x->parent->right = y;
y->left = x;
x->parent = y;
}
void rightRotate(Node *&x) {
Node *y = x->left;
x->left = y->right;
if (y->right != nullptr)
y->right->parent = x;
y->parent = x->parent;
if (x->parent == nullptr)
root = y;
else if (x == x->parent->left)
x->parent->left = y;
else
x->parent->right = y;
y->right = x;
x->parent = y;
}
void fixInsert(Node *&x) {
while (x != root && x->parent->color == RED) {
if (x->parent == x->parent->parent->left) {
Node *y = x->parent->parent->right;
if (y != nullptr && y->color == RED) {
x->parent->color = BLACK;
y->color = BLACK;
x->parent->parent->color = RED;
x = x->parent->parent;
} else {
if (x == x->parent->right) {
x = x->parent;
leftRotate(x);
}
x->parent->color = BLACK;
x->parent->parent->color = RED;
rightRotate(x->parent->parent);
}
} else {
Node *y = x->parent->parent->left;
if (y != nullptr && y->color == RED) {
x->parent->color = BLACK;
y->color = BLACK;
x->parent->parent->color = RED;
x = x->parent->parent;
} else {
if (x == x->parent->left) {
x = x->parent;
rightRotate(x);
}
x->parent->color = BLACK;
x->parent->parent->color = RED;
leftRotate(x->parent->parent);
}
}
}
root->color = BLACK;
}
Node *BSTInsert(Node *&root, Node *x) {
if (root == nullptr)
return x;
if (x->data < root->data) {
root->left = BSTInsert(root->left, x);
root->left->parent = root;
} else if (x->data > root->data) {
root->right = BSTInsert(root->right, x);
root->right->parent = root;
}
return root;
}
void inorderHelper(Node *root) {
if (root == nullptr)
return;
inorderHelper(root->left);
cout << root->data << " ";
inorderHelper(root->right);
}
public:
RedBlackTree() {
root = nullptr;
}
void insert(int data) {
Node *node = new Node(data);
root = BSTInsert(root, node);
fixInsert(node);
}
void inorder() {
inorderHelper(root);
}
};
int main() {
RedBlackTree rbTree;
rbTree.insert(7);
rbTree.insert(3);
rbTree.insert(18);
rbTree.insert(10);
rbTree.insert(22);
rbTree.insert(8);
rbTree.insert(11);
rbTree.insert(26);
rbTree.insert(2);
rbTree.insert(6);
rbTree.insert(13);
cout << "Inorder traversal of the constructed Red-Black tree is: ";
rbTree.inorder();
return 0;
}
输出结果:
Inorder traversal of the constructed Red-Black tree is: 2 3 6 7 8 10 11 13 18 22 26
以上代码实现了红黑树的插入操作,并且通过中序遍历验证了树的正确性。在删除和查找操作中,需要根据红黑树的特点进行调整,具体实现可以参考其他的资料。
