Unsaturated Polyesterimide Resin for Electrical Insulation Systems: XT-1607

INFUSED RESIN

► UNSATURATED POLYESTERIMIDE RESIN ► LOW ODOR, LOW VOLATILITY ► MAINTAINS GOOD MECHANICAL PROPERTIES AT HIGH TEMPERATURES ► EXCELLENT AND DURABLE ELECTRICAL PROPERTIES

Product Overview

A single-component, solvent-free unsaturated polyesterimide infused resin. It is a light yellow transparent infused resin with minimal volatiles during the curing process. After thermosetting, it exhibits good mechanical and electrical properties and can be used in electrical insulation systems up to Class C.

Applications

Suitable for insulation treatment of various industrial motors, special motors, new energy motors, and transformer coils. The cured resin has good mechanical and electrical properties as well as excellent aging resistance.

Molding Process

Infused resin XT-1607 can be used for various molding processes such as normal immersion, continuous immersion, drip immersion, roll immersion, vacuum impregnation (VI), and Vacuum Pressure Impregnation (VPI). The molding process parameters can be selected according to the type of motor or transformer.

To maintain the long-term stability of the resin in the tank, it is recommended to add approximately 10% new resin every month. If necessary, the viscosity and reactivity of the resin in the tank should be tested regularly.

Curing Conditions: 130℃/2h-3h or 150℃/1h-2h (all temperatures refer to the temperature of the copper wire). The resin should be protected from contamination and long-term exposure to high temperatures.

Packaging Specifications

20 kg drum 200 kg drum 1000 kg drum

Storage Conditions

Store in a sealed container away from light at a temperature of 23℃, with a minimum shelf life of six months. At a temperature of 15℃, the minimum shelf life is nine months. If the resin is stored in a paint can, it is recommended to store it under atmospheric pressure (dry air or nitrogen). It is beneficial for resin stability that the resin does not completely fill the entire container during storage.

Main Performance

| Unit | Value | Test Standard | |---|---|---| | | | Physical and Chemical Properties | | Appearance | Light yellow transparent liquid | Visual | | Viscosity (25℃) | mPa.s 900-1300 | Brookfield | | Gel Time (120℃) | min 4-8 | Gelnorm | | Thick layer curing capability | S1, U1, I2.1 uniform | GB/T1981.2-2009 | | Volatile Content during curing | % ≤2 | GB/T15022.2-2007 | | Shore Hardness D | 75-85 | ISO 868 | | | | Electrical Properties | | Electrical Strength (normal) | kV/mm ≥20 | GB/T1408.1-2006 | | Electrical Strength (after immersion for 24h) | kV/mm ≥18 | GB/T1408.1-2006 | | Volume Resistivity (normal) | Ω·m 1014 | GB/T1410-2006 | | Volume Resistivity (after immersion for 24h) | Ω·m 1014 | GB/T1410-2006 | | | | Mechanical Properties | | Bonding Strength (twisted coil, 23℃) | N ≥280 | IEC 61033 | | Bonding Strength (twisted coil, 155℃) | N ≥100 | IEC 61033 | | Bonding Strength (twisted coil, 180℃) | N ≥60 | IEC 61033 |

Safety and Health

Avoid contact with skin and eyes; work in a well-ventilated area away from open flames; wear safety gloves and goggles. Please refer to the Material Safety Data Sheet for complete information.

Disclaimer

The performance of the product described in this datasheet is based on testing results of typical materials produced by Voltshield, and some performance variations are typical. Any comments and suggestions related to other aspects, apart from performance, are only intended as reminders for end users and relevant personnel to pay attention to matters that need to be taken into account when making independent decisions regarding the use and/or application methods of the product. Voltshield does not claim or guarantee the completeness, accuracy, and effectiveness of the information provided in this datasheet regarding the results of product use described. Voltshield explicitly declares that it will not assume any liability for any damages, losses, injuries, or expenses caused directly or indirectly by relying on the information contained in this datasheet. The information contained in this datasheet does not constitute any statements or warranties regarding any event. Voltshield makes no express or implied warranties for any contents in this datasheet, including warranties of merchantability or fitness for a particular purpose. Voltshield shall not be liable for any incidental, consequential, punitive, or indirect damages.
