VB.NET: 将 AutoCAD 图层合并成块并加密冻结

在 VB.NET 中，可以使用 AutoCAD 的 COM 接口进行操作。以下是一个示例代码，用于将所有图层合并成块并设置为只读，禁止炸开、修改和复制：\n\nvb\nImports Autodesk.AutoCAD.Interop\nImports Autodesk.AutoCAD.Interop.Common\n\nModule Module1\n Sub Main()\n ' 创建 AutoCAD 应用程序对象\n Dim acadApp As AutoCADApplication = New AutoCADApplication()\n \n ' 检查是否已经打开了 AutoCAD\n If acadApp Is Nothing Then\n Console.WriteLine("AutoCAD is not running.")\n Return\n End If\n\n ' 获取当前文档对象\n Dim acadDoc As AutoCADDocument = acadApp.ActiveDocument\n\n ' 获取当前数据库对象\n Dim db As Database = acadDoc.Database\n\n ' 开始事务处理\n Using trans As Transaction = db.TransactionManager.StartTransaction()\n ' 获取所有图层对象\n Dim layerTable As LayerTable = trans.GetObject(db.LayerTableId, OpenMode.ForRead)\n\n ' 创建一个新的块表记录对象\n Dim blockTableRecord As BlockTableRecord = New BlockTableRecord()\n\n ' 设置块表记录的名称\n blockTableRecord.Name = "MergedLayerBlock"\n\n ' 遍历所有图层\n For Each layerId As ObjectId In layerTable\n Dim layer As LayerTableRecord = trans.GetObject(layerId, OpenMode.ForRead)\n\n ' 将图层加入到块表记录中\n blockTableRecord.AppendEntity(layer.Clone())\n\n ' 冻结图层\n layer.IsFrozen = True\n Next\n\n ' 将块表记录添加到块表中\n Dim blockTable As BlockTable = trans.GetObject(db.BlockTableId, OpenMode.ForWrite)\n blockTable.Add(blockTableRecord)\n trans.AddNewlyCreatedDBObject(blockTableRecord, True)\n\n ' 提交事务\n trans.Commit()\n End Using\n\n ' 保存文档\n acadDoc.Save()\n\n ' 关闭文档\n acadDoc.Close()\n\n ' 退出 AutoCAD\n acadApp.Quit()\n End Sub\nEnd Module\n\nPublic Class AutoCADApplication\n Inherits AcadApplication\n\n Public Sub New()\n Try\n ' 尝试获取已经打开的 AutoCAD 实例\n Me.AttachAutoCAD()\n Catch ex As Exception\n ' 创建新的 AutoCAD 实例\n Me.StartAutoCAD()\n End Try\n End Sub\n\n Private Sub AttachAutoCAD()\n ' 获取活动的 AutoCAD 实例\n Me.GetInterfaceObjectFromActiveAutoCAD()\n End Sub\n\n Private Sub StartAutoCAD()\n ' 创建新的 AutoCAD 实例\n Me.CreateNewInstance()\n End Sub\n\n Private Sub GetInterfaceObjectFromActiveAutoCAD()\n ' 获取活动的 AutoCAD 实例\n Dim acadAppType As Type = Type.GetTypeFromProgID("AutoCAD.Application")\n Me.InterfaceObject = DirectCast(Marshal.GetActiveObject(acadAppType.FullName), AcadApplication)\n End Sub\n\n Private Sub CreateNewInstance()\n ' 创建新的 AutoCAD 实例\n Dim acadAppType As Type = Type.GetTypeFromProgID("AutoCAD.Application")\n Me.InterfaceObject = DirectCast(Activator.CreateInstance(acadAppType), AcadApplication)\n End Sub\nEnd Class\n\nPublic Class AutoCADDocument\n Inherits AcadDocument\n\n Public Sub New(acadApp As AutoCADApplication)\n Me.InterfaceObject = acadApp.InterfaceObject.ActiveDocument\n End Sub\n\n Public Sub Save()\n Me.InterfaceObject.Save()\n End Sub\n\n Public Sub Close()\n Me.InterfaceObject.Close()\n End Sub\nEnd Class\n\n\n请注意，为了运行上述代码，您需要引用 Autodesk.AutoCAD.Interop 和 Autodesk.AutoCAD.Interop.Common 程序集，并将 Interop.AutoCAD.Interop.dll 和 Interop.AutoCAD.Interop.Common.dll 文件添加为引用。\n
