UG二次开发：使用Python自动化去除三维模型圆角

要使用UG二次开发功能自动化去掉三维模型的圆角，可以使用Python编写UG的宏脚本来实现。\n\n首先，你需要安装UG的Python API。然后，你可以按照以下步骤编写脚本：\n\n1. 导入必要的模块：\n\npython\nimport NXOpen\nimport NXOpen.UF\n\n\n2. 创建UG会话和UF对象：\n\npython\ntheSession = NXOpen.Session.GetSession()\ntheUFSession = NXOpen.UF.UFSession.GetUFSession()\n\n\n3. 获取当前工作部件并激活它：\n\npython\ntheWorkPart = theSession.Parts.Work\ntheDisplayPart = theSession.Parts.Display\n\n\n4. 获取要去掉圆角的特征：\n\npython\nfeatureIdentifier = "FEATURE_NAME" # 替换为实际的特征名称\ntheFeature = theWorkPart.Features.FindObject(featureIdentifier)\n\n\n5. 删除圆角：\n\npython\ntheUFSession.Modl.EditRollOverEdges(theFeature.Tag)\ntheUFSession.Modl.DeleteRollOverEdges(theFeature.Tag)\n\n\n6. 保存并关闭工作部件：\n\npython\ntheWorkPart.Save()\ntheSession.Parts.CloseAll()\n\n\n完整的Python脚本如下所示：\n\npython\nimport NXOpen\nimport NXOpen.UF\n\ntheSession = NXOpen.Session.GetSession()\ntheUFSession = NXOpen.UF.UFSession.GetUFSession()\n\ntheWorkPart = theSession.Parts.Work\ntheDisplayPart = theSession.Parts.Display\n\nfeatureIdentifier = "FEATURE_NAME" # 替换为实际的特征名称\ntheFeature = theWorkPart.Features.FindObject(featureIdentifier)\n\ntheUFSession.Modl.EditRollOverEdges(theFeature.Tag)\ntheUFSession.Modl.DeleteRollOverEdges(theFeature.Tag)\n\ntheWorkPart.Save()\ntheSession.Parts.CloseAll()\n\n\n请注意，上述脚本中的FEATURE_NAME应替换为实际的特征名称。此外，你还可以根据需要进行其他自定义设置和修改。\n\n希望这可以帮助到你开始使用UG二次开发功能自动化去掉三维模型的圆角。
