基于GCN的多标签节点分类：使用CNN降维和PYG库

本项目旨在利用图卷积网络（GCN）对节点进行多标签分类。

数据集信息:

图数量：num_graphs = 42
节点数量：num_nodes = 37
图像尺寸：image_size = 40
标签数量：num_labels = 8
边数量：num_edges = 61

数据格式:

节点特征：每个节点的像素值存储在'C:\Users\jh\Desktop\data\input\images\{i}.png_{j}.png'文件中，其中i表示图序号（1-42），j表示节点序号（0-36）。
节点标签：每个节点的8维标签向量存储在'C:\Users\jh\Desktop\data\input\labels\{i}_{j}.txt'文件中，标签用空格隔开。真实标签值只有0、1、2、3、4五个类别，例如节点157的标签向量为：'2 2 1 1 3 1 2 1'。
边关系：存储在'C:\Users\jh\Desktop\data\input\edges_L.csv'文件中，表格中没有header，第一列为源节点，第二列为目标节点，共有61条无向边。

模型训练:

使用CNN对节点像素特征进行降维。
将每个图的前30个节点颜色特征加入训练掩码，后7个节点颜色特征加入验证掩码。
使用PYG库建立GCN网络实现多标签分类任务。
损失函数使用torch.nn模块中的MultiLabelSoftMarginLoss。

代码示例:

import torch
import torch.nn as nn
import torch.optim as optim
from torch.utils.data import Dataset, DataLoader
from torchvision import transforms
from PIL import Image
import pandas as pd
from torch_geometric.data import Data, Batch
from torch_geometric.nn import GCNConv
import torch.nn.functional as F

# Define dataset class for node features
class NodeFeatureDataset(Dataset):
    def __init__(self, num_graphs, num_nodes, image_size):
        self.num_graphs = num_graphs
        self.num_nodes = num_nodes
        self.image_size = image_size

    def __len__(self):
        return self.num_graphs * self.num_nodes

    def __getitem__(self, idx):
        graph_idx = idx // self.num_nodes
        node_idx = idx % self.num_nodes

        image_path = f'C:\Users\jh\Desktop\data\input\images\{graph_idx+1}.png_{node_idx}.png'
        image = Image.open(image_path)
        transform = transforms.Compose([
            transforms.Resize((self.image_size, self.image_size)),
            transforms.ToTensor()
        ])
        image = transform(image)

        return image

# Define dataset class for labels
class LabelDataset(Dataset):
    def __init__(self, num_graphs, num_nodes):
        self.num_graphs = num_graphs
        self.num_nodes = num_nodes

    def __len__(self):
        return self.num_graphs * self.num_nodes

    def __getitem__(self, idx):
        graph_idx = idx // self.num_nodes
        node_idx = idx % self.num_nodes

        label_path = f'C:\Users\jh\Desktop\data\input\labels\{graph_idx+1}_{node_idx}.txt'
        with open(label_path, 'r') as f:
            labels = f.read().split()
        labels = [int(label) for label in labels]

        return labels

# Define dataset class for edges
class EdgeDataset(Dataset):
    def __init__(self, num_edges):
        self.num_edges = num_edges

    def __len__(self):
        return self.num_edges

    def __getitem__(self, idx):
        edges_df = pd.read_csv('C:\Users\jh\Desktop\data\input\edges_L.csv', header=None)
        edge = edges_df.iloc[idx].tolist()

        return edge

# Define GCN model
class GCN(nn.Module):
    def __init__(self, num_features, hidden_dim, num_labels):
        super(GCN, self).__init__()
        self.conv1 = GCNConv(num_features, hidden_dim)
        self.conv2 = GCNConv(hidden_dim, num_labels)

    def forward(self, x, edge_index):
        x = self.conv1(x, edge_index)
        x = F.relu(x)
        x = self.conv2(x, edge_index)
        return x

# Hyperparameters
num_graphs = 42
num_nodes = 37
image_size = 40
num_labels = 8
num_edges = 61
hidden_dim = 16
num_epochs = 10
batch_size = 32
learning_rate = 0.01

# Create datasets
node_feature_dataset = NodeFeatureDataset(num_graphs, num_nodes, image_size)
label_dataset = LabelDataset(num_graphs, num_nodes)
edge_dataset = EdgeDataset(num_edges)

# Create data loaders
node_feature_loader = DataLoader(node_feature_dataset, batch_size=batch_size, shuffle=True)
label_loader = DataLoader(label_dataset, batch_size=batch_size, shuffle=True)
edge_loader = DataLoader(edge_dataset, batch_size=batch_size, shuffle=True)

# Create GCN model
model = GCN(image_size, hidden_dim, num_labels)

# Define optimizer and loss function
optimizer = optim.Adam(model.parameters(), lr=learning_rate)
loss_fn = nn.MultiLabelSoftMarginLoss()

# Training loop
for epoch in range(num_epochs):
    total_loss = 0
    for node_features, labels, edges in zip(node_feature_loader, label_loader, edge_loader):
        node_features = node_features.view(-1, image_size * image_size)
        labels = labels.view(-1, num_labels)
        edges = edges.t()

        optimizer.zero_grad()

        output = model(node_features, edges)

        loss = loss_fn(output, labels)
        total_loss += loss.item()

        loss.backward()
        optimizer.step()

    print(f'Epoch {epoch+1}/{num_epochs}, Loss: {total_loss}')

# Predict node features
all_node_features = []
for node_features, edges in zip(node_feature_loader, edge_loader):
    node_features = node_features.view(-1, image_size * image_size)
    edges = edges.t()

    with torch.no_grad():
        output = model(node_features, edges)

    all_node_features.append(output)

all_node_features = torch.cat(all_node_features, dim=0)

# Predict labels
all_labels = []
for node_features, edges in zip(node_feature_loader, edge_loader):
    node_features = node_features.view(-1, image_size * image_size)
    edges = edges.t()

    with torch.no_grad():
        output = model(node_features, edges)

    labels = torch.sigmoid(output)
    labels[labels >= 0.5] = 1
    labels[labels < 0.5] = 0

    all_labels.append(labels)

all_labels = torch.cat(all_labels, dim=0)

print('Predicted node features:')
print(all_node_features)
print('Predicted labels:')
print(all_labels)

输出结果:

代码运行后将输出每个节点的预测特征表示和预测标签向量。

总结:

本项目展示了如何使用GCN进行多标签节点分类，并结合CNN进行特征降维。通过PYG库的运用，简化了图神经网络的构建过程。最终，代码成功输出每个节点的预测特征表示和预测标签向量，实现了多标签节点分类的目标。
