Verilog 计数器实现特定范围拉高输出
module counter ( input wire clk, input wire reset, output wire out );
reg [7:0] count;
always @(posedge clk or posedge reset) begin
if (reset)
count <= 0;
else if (count >= 10 && count <= 12)
count <= count + 1;
else if (count >= 60 && count <= 80)
count <= count + 1;
else if (count >= 120 && count <= 159)
count <= count + 1;
else
count <= 0;
end
assign out = (count >= 10 && count <= 12) || (count >= 60 && count <= 80) || (count >= 120 && count <= 159);
endmodule
