小程序一行展示两个环形图:使用 echarts 和 `<canvas>`
在小程序上一行展示两个环形图可以使用两个 <canvas> 元素并将它们放在同一行。以下是一个示例代码:
<view class='chart-row'>
<canvas canvas-id='chart1' class='chart'></canvas>
<canvas canvas-id='chart2' class='chart'></canvas>
</view>
然后,在对应的小程序页面的 JS 文件中,你可以使用 <chart> 组件来绘制环形图。以下是一个示例代码:
import * as echarts from '../../components/ec-canvas/echarts';
Page({
onReady: function () {
this.initChart1();
this.initChart2();
},
initChart1: function () {
this.selectComponent('#chart1').init((canvas, width, height) => {
const chart = echarts.init(canvas, null, {
width: width,
height: height
});
// 绘制环形图1的数据和配置
const option = {
series: [{
type: 'pie',
data: [{
value: 335,
name: '数据1'
}, {
value: 310,
name: '数据2'
}],
radius: ['40%', '70%']
}]
};
chart.setOption(option);
return chart;
});
},
initChart2: function () {
this.selectComponent('#chart2').init((canvas, width, height) => {
const chart = echarts.init(canvas, null, {
width: width,
height: height
});
// 绘制环形图2的数据和配置
const option = {
series: [{
type: 'pie',
data: [{
value: 500,
name: '数据3'
}, {
value: 200,
name: '数据4'
}],
radius: ['40%', '70%']
}]
};
chart.setOption(option);
return chart;
});
}
});
在上面的示例代码中,initChart1 和 initChart2 函数分别初始化了两个 <canvas> 元素,并使用了第三方图表库 echarts 来绘制环形图。你需要根据自己的数据和配置,修改 initChart1 和 initChart2 函数中的 option 对象。
最后,你可以使用 CSS 来控制 <canvas> 元素的样式,使它们在一行中展示。以下是一个示例 CSS 代码:
.chart-row {
display: flex;
justify-content: space-between;
margin-top: 20px;
}
.chart {
width: 45%;
height: 300px;
}
在上面的示例 CSS 代码中,.chart-row 类用于将两个 <canvas> 元素放在同一行,并使用了 flex 布局和 space-between 属性来实现它们之间的间距。.chart 类用于设置每个 <canvas> 元素的宽度和高度。
通过以上的代码,你可以在小程序上一行展示两个环形图。你可以根据自己的需求修改和调整代码。
