服装图像分类模型训练与可视化 - TensorFlow Keras

# 导入必要的库
import os
import numpy as np
import matplotlib.pyplot as plt
import tensorflow as tf
from tensorflow import keras
from tensorflow.keras import layers

# 定义训练集和测试集路径
train_dir = 'C:/Users/28938/Desktop/shengdu/Data/train'
test_dir = 'C:/Users/28938/Desktop/shengdu/Data/test'

# 定义类别标签
class_names = ['MEN_Coats', 'MEN_Hood', 'MEN_Suits', 'WOMEN_Dress', 'WOMEN_Hood']

# 定义图像尺寸和批次大小
img_height = 224
img_width = 224
batch_size = 32

# 从目录中读取训练集和测试集
train_ds = keras.preprocessing.image_dataset_from_directory(
    train_dir,
    validation_split=0.2,
    subset='training',
    seed=42,
    image_size=(img_height, img_width),
    batch_size=batch_size
)
val_ds = keras.preprocessing.image_dataset_from_directory(
    train_dir,
    validation_split=0.2,
    subset='validation',
    seed=42,
    image_size=(img_height, img_width),
    batch_size=batch_size
)
test_ds = keras.preprocessing.image_dataset_from_directory(
    test_dir,
    seed=42,
    image_size=(img_height, img_width),
    batch_size=batch_size
)

# 定义数据增强器
data_augmentation = keras.Sequential(
    [
        layers.experimental.preprocessing.RandomFlip('horizontal', input_shape=(img_height, img_width, 3)),
        layers.experimental.preprocessing.RandomRotation(0.1),
        layers.experimental.preprocessing.RandomZoom(0.1),
        layers.experimental.preprocessing.RandomContrast(0.1),
        layers.experimental.preprocessing.RandomBrightness(0.1),
    ]
)

# 定义模型输入
input_shape = (img_height, img_width, 3)

# 建立模型
model = keras.Sequential([
    data_augmentation,
    layers.experimental.preprocessing.Rescaling(1./255),
    layers.Conv2D(32, 3, padding='same', activation='relu', input_shape=input_shape),
    layers.BatchNormalization(),
    layers.Conv2D(32, 3, padding='same', activation='relu'),
    layers.BatchNormalization(),
    layers.MaxPooling2D(),
    layers.Conv2D(64, 3, padding='same', activation='relu'),
    layers.BatchNormalization(),
    layers.Conv2D(64, 3, padding='same', activation='relu'),
    layers.BatchNormalization(),
    layers.MaxPooling2D(),
    layers.Conv2D(128, 3, padding='same', activation='relu'),
    layers.BatchNormalization(),
    layers.Conv2D(128, 3, padding='same', activation='relu'),
    layers.BatchNormalization(),
    layers.MaxPooling2D(),
    layers.Dropout(0.5),
    layers.Flatten(),
    layers.Dense(256, activation='relu'),
    layers.Dropout(0.5),
    layers.Dense(len(class_names))
])

# 学习率衰减策略
initial_learning_rate = 0.001
lr_schedule = keras.optimizers.schedules.ExponentialDecay(
    initial_learning_rate, decay_steps=100000, decay_rate=0.96, staircase=True
)

# 编译模型
model.compile(optimizer=keras.optimizers.Adam(learning_rate=lr_schedule),
              loss=tf.keras.losses.SparseCategoricalCrossentropy(from_logits=True),
              metrics=['accuracy'])

# 打印模型结构
model.summary()

# 设定训练参数
epochs = 20

# 开始训练模型
history = model.fit(train_ds, validation_data=val_ds, epochs=epochs, batch_size=batch_size)

# 对模型进行评估
test_loss, test_acc = model.evaluate(test_ds)
print('Test accuracy:', test_acc)

# 对模型进行预测
predictions = model.predict(test_ds)

# 绘制模型准确度和损失随时间变化的曲线
acc = history.history['accuracy']
val_acc = history.history['val_accuracy']
loss = history.history['loss']
val_loss = history.history['val_loss']
epochs_range = range(epochs)
plt.figure(figsize=(8, 8))
plt.subplot(2, 1, 1)
plt.plot(epochs_range, acc, label='Training Accuracy')
plt.plot(epochs_range, val_acc, label='Validation Accuracy')
plt.legend(loc='lower right')
plt.title('Training and Validation Accuracy')
plt.subplot(2, 1, 2)
plt.plot(epochs_range, loss, label='Training Loss')
plt.plot(epochs_range, val_loss, label='Validation Loss')
plt.legend(loc='upper right')
plt.title('Training and Validation Loss')
plt.show()

# 显示前5张图像
plt.figure(figsize=(10, 10))
for images, labels in train_ds.take(1):
    for i in range(5):
        ax = plt.subplot(5, 5, i + 1)
        plt.imshow(images[i].numpy().astype('uint8'))
        plt.title(class_names[labels[i]])
        plt.axis('off')
plt.show()
