InternImage: A High-Performance Image Classification Model

InternImage for Image Classification

This folder contains the implementation of the InternImage for image classification.

Usage

Install

Clone this repo:

git clone https://github.com/OpenGVLab/InternImage.git
cd InternImage

Create a conda virtual environment and activate it:

conda create -n internimage python=3.7 -y
conda activate internimage

Install CUDA>=10.2 with cudnn>=7 following the official installation instructions
Install PyTorch>=1.10.0 and torchvision>=0.9.0 with CUDA>=10.2:

For examples, to install torch==1.11 with CUDA==11.3:

pip install torch==1.11.0+cu113 torchvision==0.12.0+cu113  -f https://download.pytorch.org/whl/torch_stable.html

Install timm==0.6.11 and mmcv-full==1.5.0:

pip install -U openmim
mim install mmcv-full==1.5.0
pip install timm==0.6.11 mmdet==2.28.1

Install other requirements:

pip install opencv-python termcolor yacs pyyaml scipy

Compiling CUDA operators

cd ./ops_dcnv3
sh ./make.sh
# unit test (should see all checking is True)
python test.py

You can also install the operator using .whl files DCNv3-1.0-whl

Data Preparation

We use standard ImageNet dataset, you can download it from http://image-net.org/. We provide the following two ways to load data:

For standard folder dataset, move validation images to labeled sub-folders. The file structure should look like:
```
$ tree data
```

imaginet ├── train │ ├── class1 │ │ ├── img1.jpeg │ │ ├── img2.jpeg │ │ └── ... │ ├── class2 │ │ ├── img3.jpeg │ │ └── ... │ └── ... └── val ├── class1 │ ├── img4.jpeg │ ├── img5.jpeg │ └── ... ├── class2 │ ├── img6.jpeg │ └── ... └── ...

- To boost the slow speed when reading images from massive small files, we also support zipped ImageNet, which includes
four files:
  - `train.zip`, `val.zip`: which store the zipped folder for train and validate splits.
  - `train.txt`, `val.txt`: which store the relative path in the corresponding zip file and ground truth
    label. Make sure the data folder looks like this:

```bash
$ tree data
data
└── ImageNet-Zip
    ├── train_map.txt
    ├── train.zip
    ├── val_map.txt
    └── val.zip

$ head -n 5 meta_data/val.txt
ILSVRC2012_val_00000001.JPEG	65
ILSVRC2012_val_00000002.JPEG	970
ILSVRC2012_val_00000003.JPEG	230
ILSVRC2012_val_00000004.JPEG	809
ILSVRC2012_val_00000005.JPEG	516

$ head -n 5 meta_data/train.txt
n01440764/n01440764_10026.JPEG	0
n01440764/n01440764_10027.JPEG	0
n01440764/n01440764_10029.JPEG	0
n01440764/n01440764_10040.JPEG	0
n01440764/n01440764_10042.JPEG	0

For ImageNet-22K dataset, make a folder named fall11_whole and move all images to labeled sub-folders in this folder. Then download the train-val split file (ILSVRC2011fall_whole_map_train.txt & ILSVRC2011fall_whole_map_val.txt) , and put them in the parent directory of fall11_whole. The file structure should look like:
```
  $ tree imagenet22k/
```

imaginet22k/ └── fall11_whole ├── n00004475 ├── n00005787 ├── n00006024 ├── n00006484 └── ...


#### Evaluation

To evaluate a pretrained `InternImage` on ImageNet val, run:

```bash
python -m torch.distributed.launch --nproc_per_node <num-of-gpus-to-use> --master_port 12345 main.py --eval \
--cfg <config-file> --resume <checkpoint> --data-path <imagenet-path>

For example, to evaluate the InternImage-B with a single GPU:

python -m torch.distributed.launch --nproc_per_node 1 --master_port 12345 main.py --eval \
--cfg configs/internimage_b_1k_224.yaml --resume internimage_b_1k_224.pth --data-path <imagenet-path>

Training from Scratch on ImageNet-1K

The paper results were obtained from models trained with configs in configs/without_lr_decay.

To train an InternImage on ImageNet from scratch, run:

python -m torch.distributed.launch --nproc_per_node <num-of-gpus-to-use> --master_port 12345  main.py \
--cfg <config-file> --data-path <imagenet-path> [--batch-size <batch-size-per-gpu> --output <output-directory> --tag <job-tag>]

Important: When using multiple GPUs, you need to specify the --local-rank argument for each GPU. For example, if you're using 4 GPUs, you would run the following command for each GPU:

python -m torch.distributed.launch --nproc_per_node 4 --master_port 12345 main.py \
--cfg configs/internimage_b_1k_224.yaml --data-path <imagenet-path> --local-rank <gpu-rank>

Replace <gpu-rank> with 0, 1, 2, or 3 for each of the 4 GPUs.

Manage Jobs with Slurm.

For example, to train InternImage with 8 GPU on a single node for 300 epochs, run:

InternImage-T:

GPUS=8 sh train_in1k.sh <partition> <job-name> configs/internimage_t_1k_224.yaml --resume internimage_t_1k_224.pth --eval

InternImage-S:

GPUS=8 sh train_in1k.sh <partition> <job-name> configs/internimage_s_1k_224.yaml --resume internimage_s_1k_224.pth --eval

InternImage-XL:

GPUS=8 sh train_in1k.sh <partition> <job-name> configs/internimage_xl_22kto1k_384.pth --resume internimage_xl_22kto1k_384.pth --eval

Training with Deepspeed

We support utilizing Deepspeed to reduce memory costs for training large-scale models, e.g. InternImage-H with over 1 billion parameters. To use it, first install the requirements as

pip install deepspeed==0.8.3

Then you could launch the training in a slurm system with 8 GPUs as follows (tiny and huge as examples). The default zero stage is 1 and it could config via command line args --zero-stage.

GPUS=8 GPUS_PER_NODE=8 sh train_in1k_deepspeed.sh vc_research_4 train configs/internimage_t_1k_224.yaml --batch-size 128 --accumulation-steps 4
GPUS=8 GPUS_PER_NODE=8 sh train_in1k_deepspeed.sh vc_research_4 train configs/internimage_t_1k_224.yaml --batch-size 128 --accumulation-steps 4 --eval --resume ckpt.pth
GPUS=8 GPUS_PER_NODE=8 sh train_in1k_deepspeed.sh vc_research_4 train configs/internimage_t_1k_224.yaml --batch-size 128 --accumulation-steps 4 --eval --resume deepspeed_ckpt_dir
GPUS=8 GPUS_PER_NODE=8 sh train_in1k_deepspeed.sh vc_research_4 train configs/internimage_h_22kto1k_640.yaml --batch-size 16 --accumulation-steps 4 --pretrained ckpt/internimage_h_jointto22k_384.pth
GPUS=8 GPUS_PER_NODE=8 sh train_in1k_deepspeed.sh vc_research_4 train configs/internimage_h_22kto1k_640.yaml --batch-size 16 --accumulation-steps 4 --pretrained ckpt/internimage_h_jointto22k_384.pth --zero-stage 3

🤗 Huggingface Accelerate Integration of Deepspeed

Optionally, you could use our Huggingface accelerate integration to use deepspeed.

pip install accelerate==0.18.0

accelerate launch --config_file configs/accelerate/dist_8gpus_zero3_wo_loss_scale.yaml main_accelerate.py  --cfg configs/internimage_h_22kto1k_640.yaml --data-path /mnt/lustre/share/images --batch-size 16 --pretrained ckpt/internimage_h_jointto22k_384.pth --accumulation-steps 4
accelerate launch --config_file configs/accelerate/dist_8gpus_zero3_offload.yaml main_accelerate.py  --cfg configs/internimage_t_1k_224.yaml --data-path /mnt/lustre/share/images --batch-size 128 --accumulation-steps 4 --output output_zero3_offload
accelerate launch --config_file configs/accelerate/dist_8gpus_zero1.yaml main_accelerate.py  --cfg configs/internimage_t_1k_224.yaml --data-path /mnt/lustre/share/images --batch-size 128 --accumulation-steps 4

Memory Costs

Here is the reference GPU memory cost for InternImage-H with 8 GPUs.

total batch size = 512, 16 batch size for each GPU, gradient accumulation steps = 4.

| Resolution | Deepspeed | Cpu offloading | Memory | | --- | --- | --- | --- | | 640 | zero1 | False | 22572 | | 640 | zero3 | False | 20000 | | 640 | zero3 | True | 19144 | | 384 | zero1 | False | 16000 | | 384 | zero3 | True | 11928 |

Convert Checkpoints

To convert deepspeed checkpoints to pytorch fp32 checkpoint, you could use the following snippet.

from deepspeed.utils.zero_to_fp32 import convert_zero_checkpoint_to_fp32_state_dict
convert_zero_checkpoint_to_fp32_state_dict(checkpoint_dir, 'best.pth', tag='best')

Then, you could use best.pth as usual, e.g., model.load_state_dict(torch.load('best.pth'))

Due to the lack of computational resources, the deepspeed training scripts are currently only verified for the first few epochs. Please fire an issue if you have problems for reproducing the whole training.

Extracting Intermediate Features

To extract the features of an intermediate layer, you could use extract_feature.py.

For example, extract features of b.png from layers patch_embed and levels.0.downsample and save them to 'b.pth'.

python extract_feature.py --cfg configs/internimage_t_1k_224.yaml --img b.png --keys patch_embed levels.0.downsample --save --resume internimage_t_1k_224.pth

Export

To export InternImage-T from PyTorch to ONNX, run:

python export.py --model_name internimage_t_1k_224 --ckpt_dir /path/to/ckpt/dir --onnx

To export InternImage-T from PyTorch to TensorRT, run:

python export.py --model_name internimage_t_1k_224 --ckpt_dir /path/to/ckpt/dir --trt
