Arduino 开发板尺寸列表 - 完整尺寸指南

Arduino M0 Pro - 68.6mm x 53.4mm Arduino MKR 1000 - 67.64mm x 25.0mm Arduino MKR FOX 1200 - 67.64mm x 25.0mm Arduino MKR GSM 1400 - 67.64mm x 25.0mm Arduino MKR NB 1500 - 67.64mm x 25.0mm Arduino MKR Vidor 4000 - 60.0mm x 25.0mm Arduino MKR WAN 1300 - 67.64mm x 25.0mm Arduino MKR WAN 1310 - 67.64mm x 25.0mm Arduino MKR WiFi 1010 - 67.64mm x 25.0mm Arduino MKR Zero - 61.5mm x 25.0mm Arduino Mega ADK - 101.52mm x 53.3mm Arduino Mega or Mega 2560 - 101.52mm x 53.3mm Arduino Micro - 48.0mm x 18.0mm Arduino Mini - 30.5mm x 18.0mm Arduino NG or older - N/A Arduino Nano - 18.0mm x 45.0mm Arduino Nano 33 BLE - 45.0mm x 18.0mm Arduino Nano 33 BLE Sense - 45.0mm x 18.0mm Arduino Nano 33 IoT - 45.0mm x 18.0mm Arduino Nano Every - 45.0mm x 18.0mm Arduino Nano RP2040 Connect - 45.0mm x 18.0mm Arduino Nicla Sense ME - 50.0mm x 25.0mm Arduino Nicla Vision - 50.0mm x 25.0mm Arduino Portenta H7 - 100.0mm x 72.0mm Arduino Portenta X8 - N/A Arduino Primo - 68.6mm x 53.4mm Arduino Pro or Pro Mini - 33.0mm x 18.0mm Arduino Robot Control - N/A Arduino Robot Motor - N/A Arduino Tian - 68.6mm x 53.4mm Arduino UNO WiFi Rev2 - 68.6mm x 53.4mm Arduino Uno - 68.6mm x 53.4mm Arduino Uno Mini - N/A Arduino Uno WiFi - 68.6mm x 53.4mm Arduino Yún - 75.0mm x 53.4mm Arduino Yún Mini - N/A Arduino Zero - 68.6mm x 53.4mm BPI-BIT - 38.0mm x 38.0mm BPI-Leaf-S3 - N/A Bee Motion - N/A Bee Motion Mini - N/A Bee Motion S3 - N/A Bee S3 - N/A CNRS AW2ETH - N/A Connaxio's Espoir - N/A Crabik Slot ESP32-S3 - N/A Cytron Maker Feather AIoT S3 - N/A D-duino-32 - N/A DFRobot Beetle ESP32-C3 - N/A DFRobot Firebeetle 2 ESP32-S3 - N/A DOIT ESP32 DEVKIT V1 - N/A DOIT ESPduino32 - N/A DPU ESP32 - N/A Deneyap Kart - N/A Deneyap Kart 1A - N/A Deneyap Kart 1A v2 - N/A Deneyap Kart G - N/A Deneyap Mini - N/A Deneyap Mini v2 - N/A Denky - N/A Department of Alchemy MiniMain ESP32-S2 - N/A Dongsen Tech Pocket 32 - N/A EMoRo 2560 - 100.0mm x 80.0mm ESP-C3-M1-I-Kit - N/A ESP32 Dev Module - N/A ESP32 FM DevKit - N/A ESP32 PICO-D4 - N/A ESP32 Wrover Kit (all versions) - N/A ESP32 Wrover Module - N/A ESP32-S3-Box - N/A ESP32-S3-USB-OTG - N/A ESP32-WROOM-DA Module - N/A ESP32C3 Dev Module - N/A ESP32S2 Dev Module - N/A ESP32S2 Native USB - N/A ESP32S3 CAM LCD - N/A ESP32S3 Dev Module - N/A ESP32vn IoT Uno - N/A ESPea32 - N/A ESPectro32 - N/A ET-Board - N/A Edgebox-ESP-100 - N/A Edison - N/A Electronic SweetPeas - ESP320 - N/A FireBeetle 2 ESP32-E - N/A FireBeetle-ESP32 - N/A Franzininho WiFi - N/A Franzininho WiFi MSC - N/A Frog Board ESP32 - N/A Galileo - N/A HONEYLemon - N/A Heltec WiFi Kit 32 - N/A Heltec WiFi Kit 32(V3) - N/A Heltec WiFi LoRa 32 - N/A Heltec WiFi LoRa 32(V2) - N/A Heltec WiFi LoRa 32(V3) / Wireless shell(V3) / Wireless stick lite (V3) - N/A Heltec Wireless Stick - N/A Heltec Wireless Stick Lite - N/A Hornbill ESP32 Dev - N/A Hornbill ESP32 Minima - N/A IMBRIOS LOGSENS_V1P1 - N/A INEX OpenKB - N/A Industruino D21G - N/A IntoRobot Fig - N/A KB32-FT - N/A KITS ESP32 EDU - N/A LOLIN C3 Mini - N/A LOLIN D32 - N/A LOLIN D32 PRO - N/A LOLIN S2 Mini - N/A LOLIN S2 PICO - N/A LOLIN S3 - N/A Labplus mPython - N/A LilyGo T-Display-S3 - N/A LilyPad Arduino - N/A LilyPad Arduino USB - N/A Linino One - N/A Lion:Bit Dev Board - N/A LoPy - N/A LoPy4 - N/A M5Stack-ATOM - N/A M5Stack-ATOMS3 - N/A M5Stack-Core-ESP32 - N/A M5Stack-Core2 - N/A M5Stack-CoreInk - N/A M5Stack-FIRE - N/A M5Stack-Station - N/A M5Stack-Timer-CAM - N/A M5Stick-C - N/A MGBOT IOTIK 32A - N/A MGBOT IOTIK 32B - N/A MH ET LIVE ESP32DevKIT - N/A MH ET LIVE ESP32MiniKit - N/A MagicBit - N/A Metro ESP-32 - N/A Microduino-CoreESP32 - N/A Nano32 - N/A Nicla Sense ME - 50.0mm x 25.0mm Nicla Vision - 50.0mm x 25.0mm Nicla Voice - N/A Node32s - N/A NodeMCU-32S - N/A Noduino Quantum - N/A ODROID ESP32 - N/A OLIMEX ESP32-DevKit-LiPo - N/A OLIMEX ESP32-EVB - N/A OLIMEX ESP32-GATEWAY - N/A OLIMEX ESP32-PoE - N/A OLIMEX ESP32-PoE-ISO - N/A OROCA EduBot - N/A Onehorse ESP32 Dev Module - N/A Piranha ESP-32 - N/A ProtoCentral HealthyPi 4 - N/A Pycom GPy - N/A RL78/G22 Fast Prototyping Board - N/A RL78/G23-64p Fast Prototyping Board - N/A Raspberry Pi Pico - N/A RedPill(+) ESP32-S3 - N/A RoboHeart Hercules - N/A S.ODI Ultra v1 - N/A Senses's WEIZEN - N/A Silicognition wESP32 - N/A SmartEverything Dragonfly - N/A SmartEverything Fox - N/A SmartEverything Fox3 - N/A SmartEverything Lion - N/A SmartTutto - N/A Sonoff DUALR3 - N/A SparkFun ESP32 IoT RedBoard - N/A SparkFun ESP32 MicroMod - N/A SparkFun ESP32 Thing - N/A SparkFun ESP32 Thing Plus - N/A SparkFun ESP32 Thing Plus C - N/A SparkFun ESP32-S2 Thing Plus - N/A SparkFun LoRa Gateway 1-Channel - N/A T-Beam - N/A TAMC Termod S3 - N/A TTGO LoRa32-OLED - N/A TTGO T-OI PLUS RISC-V ESP32-C3 - N/A TTGO T-Watch - N/A TTGO T1 - N/A TTGO T7 V1.3 Mini32 - N/A TTGO T7 V1.4 Mini32 - N/A ThaiEasyElec's ESPino32 - N/A Trueverit ESP32 Universal IoT Driver - N/A Trueverit ESP32 Universal IoT Driver MK II - N/A Turta IoT Node - N/A UM FeatherS2 - N/A UM FeatherS2 Neo - N/A UM FeatherS3 - N/A UM PROS3 - N/A UM RMP - N/A UM TinyPICO - N/A UM TinyS2 - N/A UM TinyS3 - N/A VALTRACK_V4_MFW_ESP32_C3 - N/A VALTRACK_V4_VTS_ESP32_C3 - N/A VintLabs ESP32 Devkit - N/A WEMOS D1 MINI ESP32 - N/A WEMOS D1 R32 - N/A WEMOS LOLIN32 - N/A WEMOS LOLIN32 Lite - N/A WT32-ETH01 Ethernet Module - N/A Watchy - N/A WeMos WiFi&Bluetooth Battery - N/A WiFiduino32 - N/A WiFiduino32S3 - N/A WiFiduinoV2 - N/A WiPy 3.0 - N/A Widora AIR - N/A Windows 10 IoT Core - N/A XIAO_ESP32C3 - N/A XinaBox CW02 - N/A atmega168pb-xmini - N/A atmega328p-xmini - N/A atmega328pb-xmini - N/A littleBits w6 Arduino module - N/A microS2 - N/A u-blox NINA-W10 series (ESP32) - N/A u-blox NORA-W10 series (ESP32-S3) - N/A uPesy ESP32 Wroom DevKit - N/A uPesy ESP32 Wrover DevKit - N/A unPhone 7 - N/A unPhone 8 - N/A unPhone 9 - N/A
