# %% import packages
import numpy as np
import os
from glob import glob
import pandas as pd

join = os.path.join
from skimage import transform, io, segmentation
from tqdm import tqdm
import torch
from segment_anything import sam_model_registry
from segment_anything.utils.transforms import ResizeLongestSide
import argparse

# set up the parser
parser = argparse.ArgumentParser(description='preprocess grey and RGB images')

# add arguments to the parser
parser.add_argument(
    '-i',
    '--img_path',
    type=str,
    default='C:/Users/lenovo/Desktop/息肉/Train/Image',
    help='path to the images',
)
parser.add_argument(
    '-gt',
    '--gt_path',
    type=str,
    default='C:/Users/lenovo/Desktop/息肉/Train/Mask',
    help='path to the ground truth (gt)',
)

parser.add_argument(
    '--csv',
    type=str,
    default=None,
    help='path to the csv file',
)

parser.add_argument(
    '-o',
    '--npz_path',
    type=str,
    default='C:/Users/lenovo/Desktop/息肉/Train/demo2D',
    help='path to save the npz files',
)
parser.add_argument(
    '--data_name',
    type=str,
    default='demo2d',
    help='dataset name; used to name the final npz file, e.g., demo2d.npz',
)
parser.add_argument('--image_size', type=int, default=256, help='image size')
parser.add_argument(
    '--img_name_suffix', type=str, default='.jpg', help='image name suffix'
)
parser.add_argument('--label_id', type=int, default=255, help='label id')
parser.add_argument('--model_type', type=str, default='vit_b', help='model type')
parser.add_argument(
    '--checkpoint',
    type=str,
    default='C:/Users/lenovo/Desktop/SAM/sam_vit_b_01ec64.pth',
    help='checkpoint',
)
parser.add_argument('--device', type=str, default='cuda:0', help='device')
parser.add_argument('--seed', type=int, default=2023, help='random seed')

# parse the arguments
args = parser.parse_args()

# convert 2d grey or rgb images to npz file
imgs = []
gts = []
img_embeddings = []

# set up the model
# get the model from sam_model_registry using the model_type argument
# and load it with checkpoint argument
# download save the SAM checkpoint.
# [https://dl.fbaipublicfiles.com/segment_anything/sam_vit_b_01ec64.pth](VIT-B SAM model)

sam_model = sam_model_registry[args.model_type](checkpoint=args.checkpoint).to(
    args.device
)


def process(gt_name: str, image_name: str):
    if image_name == None:
        image_name = gt_name.split('.')[0] + args.img_name_suffix
    gt_data = io.imread(join(args.gt_path, gt_name))
    # if it is rgb, select the first channel
    if len(gt_data.shape) == 3:
        gt_data = gt_data[:, :, 0]
    assert len(gt_data.shape) == 2, 'ground truth should be 2D'

    # resize ground truch image
    gt_data = transform.resize(
        gt_data == args.label_id,
        (args.image_size, args.image_size),
        order=0,
        preserve_range=True,
        mode='constant',
    )
    # convert to uint8
    gt_data = np.uint8(gt_data)

    if np.sum(gt_data) > 100:  # exclude tiny objects
        '''Optional binary thresholding can be added'''
        assert (
            np.max(gt_data) == 1 and np.unique(gt_data).shape[0] == 2
        ), 'ground truth should be binary'

        image_data = io.imread(join(args.img_path, image_name))
        # Remove any alpha channel if present.
        if image_data.shape[-1] > 3 and len(image_data.shape) == 3:
            image_data = image_data[:, :, :3]
        # If image is grayscale, then repeat the last channel to convert to rgb
        if len(image_data.shape) == 2:
            image_data = np.repeat(image_data[:, :, None], 3, axis=-1)
        # nii preprocess start
        lower_bound, upper_bound = np.percentile(image_data, 0.5), np.percentile(
            image_data, 99.5
        )
        image_data_pre = np.clip(image_data, lower_bound, upper_bound)
        # min-max normalize and scale
        image_data_pre = (
            (image_data_pre - np.min(image_data_pre))
            / (np.max(image_data_pre) - np.min(image_data_pre))
            * 255.0
        )
        image_data_pre[image_data == 0] = 0

        image_data_pre = transform.resize(
            image_data_pre,
            (args.image_size, args.image_size),
            order=3,
            preserve_range=True,
            mode='constant',
            anti_aliasing=True,
        )
        image_data_pre = np.uint8(image_data_pre)

        imgs.append(image_data_pre)

        assert np.sum(gt_data) > 100, 'ground truth should have more than 100 pixels'

        gts.append(gt_data)

        # resize image to 3*1024*1024
        sam_transform = ResizeLongestSide(sam_model.image_encoder.img_size)
        resize_img = sam_transform.apply_image(image_data_pre)
        resize_img_tensor = torch.as_tensor(resize_img.transpose(2, 0, 1)).to(
            args.device
        )
        input_image = sam_model.preprocess(
            resize_img_tensor[None, :, :, :]
        )  # (1, 3, 1024, 1024)
        assert input_image.shape == (
            1,
            3,
            sam_model.image_encoder.img_size,
            sam_model.image_encoder.img_size,
        ), 'input image should be resized to 1024*1024'
        # pre-compute the image embedding
        with torch.no_grad():
            embedding = sam_model.image_encoder(input_image)
            img_embeddings.append(embedding.cpu().numpy()[0])


if args.csv != None:
    # if data is presented in csv format
    # columns must be named image_filename and mask_filename respectively
    try:
        os.path.exists(args.csv)
    except FileNotFoundError as e:
        print(f'File {args.csv} not found!!')

    df = pd.read_csv(args.csv)
    bar = tqdm(df.iterrows(), total=len(df))
    for idx, row in bar:
        process(row.mask_filename, row.image_filename)

else:
    # get all the names of the images in the ground truth folder
    names = sorted(os.listdir(args.gt_path))
    # print the number of images found in the ground truth folder
    print('image number:', len(names))
    for gt_name in tqdm(names):
        process(gt_name, None)

# create a directory to save the npz files
save_path = args.npz_path + '_' + args.model_type
os.makedirs(save_path, exist_ok=True)


# save all 2D images as one npz file: ori_imgs, ori_gts, img_embeddings
# stack the list to array
print('Num. of images:', len(imgs))
if len(imgs) > 1:
    imgs = np.stack(imgs, axis=0)  # (n, 256, 256, 3)
    gts = np.stack(gts, axis=0)  # (n, 256, 256)
    img_embeddings = np.stack(img_embeddings, axis=0)  # (n, 1, 256, 64, 64)
    np.savez_compressed(
        join(save_path, args.data_name + '.npz'),
        imgs=imgs,
        gts=gts,
        img_embeddings=img_embeddings,
    )
    # save an example image for sanity check
    idx = np.random.randint(imgs.shape[0])
    img_idx = imgs[idx, :, :, :]
    gt_idx = gts[idx, :, :]
    bd = segmentation.find_boundaries(gt_idx, mode='inner')
    img_idx[bd, :] = [255, 0, 0]
    io.imsave(save_path + '.png', img_idx, check_contrast=False)
else:
    print(
        'Do not find image and ground-truth pairs. Please check your dataset and argument settings'
    )

上述代码的所需要文件的输入地址和所得到的文件的输出地址是什么，请详细说一下内容： 输入地址：

  • img_path: 原始图像所在文件夹的路径。
  • gt_path: ground truth（标注图像）所在文件夹的路径。
  • csv: 以CSV格式给出所有图像和标注图像的文件名和路径的CSV文件的路径。如果不提供CSV文件，则程序将在img_path和gt_path中查找所有图像和标注图像的文件名。
  • checkpoint: 预训练模型的路径。

输出地址：

  • npz_path: 将预处理后的图像和标注保存为 .npz 格式的文件所在文件夹的路径。每个.npz文件包含三个 numpy 数组：imgs、gts 和 img_embeddings。
  • save_path: 在 npz_path 后添加 _model_type 后缀的路径，用于保存使用不同模型预处理得到的 .npz 文件。
  • data_name: .npz 文件的名称，用于标识数据集名称。
  • save_path + '.png': 为了检查预处理的结果是否正确，程序会随机选择一个图像，并将其保存为 .png 格式的文件。
图像预处理：将 2D 灰度或 RGB 图像转换为 .npz 文件
