房间通风设备监测控制系统设计

本文将介绍一个简单的房间通风设备监测控制系统的程序,该系统使用STM32F103C8T6微控制器和LCD1602液晶显示屏。

系统功能:

  • 实时显示送风机出口温度* 设置按键选择通风和冷气两种状态* 显示电磁阀、送风机的工作状态* 对电机运行故障进行报警

系统原理:

新风通过过滤器和盘管,利用送风机送入房间通风管路。

  • 通风模式: 送风机工作,电磁阀关闭,送入房间通风管路。* 冷气模式: 送风机工作,电磁阀打开,高压冷水冷却进风,实现输送冷气的目的。

系统需要检测送风机出口温度(范围10~60℃)和主管路过滤器后新风流量。当风机运行且流量过小(流量值自设)时,报警指示过滤器阻塞。

程序实现:

以下代码使用Keil uVision4编写,并注释说明:c#define FAN_ON 0#define FAN_OFF 1#define COOL_ON 0#define COOL_OFF 1#define VALVE_ON 1#define VALVE_OFF 0#define TEMP_MIN 10#define TEMP_MAX 60#define FLOW_MIN 100#define FLOW_MAX 1000

int mode = FAN_OFF; // 当前模式,FAN_OFF代表通风,COOL_OFF代表冷气int fan_state = FAN_OFF; // 送风机状态,FAN_OFF代表关闭,FAN_ON代表开启int cool_state = COOL_OFF; // 冷气状态,COOL_OFF代表关闭,COOL_ON代表开启int valve_state = VALVE_OFF; // 电磁阀状态,VALVE_OFF代表关闭,VALVE_ON代表开启int temp = 0; // 送风机出口温度int flow = 0; // 新风流量int temp_pin = 0; // 温度传感器引脚int flow_pin = 1; // 流量传感器引脚

// 读取温度传感器int read_temp() { int temp_raw = analogRead(temp_pin); return map(temp_raw, 0, 1023, 0, 100);}

// 读取流量传感器int read_flow() { int flow_raw = analogRead(flow_pin); return map(flow_raw, 0, 1023, 0, 1000);}

// 控制电磁阀void control_valve(int state) { digitalWrite(valve_pin, state);}

// 控制送风机void control_fan(int state) { digitalWrite(fan_pin, state);}

// 显示温度void display_temp() { lcd.setCursor(0, 0); lcd.print('Temp: '); lcd.print(temp); lcd.print('C');}

// 显示模式void display_mode() { lcd.setCursor(0, 1); if (mode == FAN_ON) { lcd.print('Mode: Fan'); } else if (mode == COOL_ON) { lcd.print('Mode: Cool'); }}

// 显示状态void display_state() { lcd.setCursor(10, 1); if (fan_state == FAN_ON) { lcd.print('F'); } else { lcd.print('-'); } if (cool_state == COOL_ON) { lcd.print('C'); } else { lcd.print('-'); } if (valve_state == VALVE_ON) { lcd.print('V'); } else { lcd.print('-'); }}

void setup() { lcd.begin(16, 2); pinMode(valve_pin, OUTPUT); pinMode(fan_pin, OUTPUT);}

void loop() { temp = read_temp(); flow = read_flow();

if (mode == FAN_ON) { // 通风模式 if (flow < FLOW_MIN) { // 流量过小,报警过滤器阻塞 lcd.clear(); lcd.print('Filter blocked!'); control_fan(FAN_OFF); fan_state = FAN_OFF; } else { control_fan(FAN_ON); fan_state = FAN_ON; } } else if (mode == COOL_ON) { // 冷气模式 if (temp > TEMP_MAX) { // 温度过高,开启冷气 control_fan(FAN_ON); control_valve(VALVE_ON); fan_state = FAN_ON; cool_state = COOL_ON; valve_state = VALVE_ON; } else if (temp < TEMP_MIN) { // 温度过低,关闭冷气 control_fan(FAN_OFF); control_valve(VALVE_OFF); fan_state = FAN_OFF; cool_state = COOL_OFF; valve_state = VALVE_OFF; } }

display_temp(); display_mode(); display_state();

delay(1000);}

注意:

  • 以上代码仅供参考,实际应用中需要根据具体情况进行修改和完善。* 需根据实际情况配置温度传感器、流量传感器和LCD显示屏的引脚,以及相关库函数。* 可以根据需要添加更多的传感器和控制设备,如湿度传感器、空气净化器等,提高室内环境的质量。

下一步:

  • 完善系统功能,例如添加按键控制模式切换、添加电机故障报警等。* 对程序进行优化,例如提高代码可读性和效率,优化系统响应速度等。* 测试系统性能,验证系统功能的可靠性和稳定性。

总结:

本文介绍了一个简单的房间通风设备监测控制系统设计,并给出了基于STM32F103C8T6微控制器的程序实现。该系统能够满足基本的通风和制冷控制需求,并提供温度、流量和状态显示,以及故障报警功能。希望本文能够对读者设计类似的系统有所帮助
