定义一个卷积层

class ConvLayer(nn.Module): '定义一个卷积层' def init(self, net_depth, dim, kernel_size=3, gate_act=nn.Sigmoid): '初始化卷积层' super().init() self.dim = dim '网络深度' self.net_depth = net_depth '卷积核大小' self.kernel_size = kernel_size # 两个卷积层 self.Wv = nn.Sequential( '第一个卷积层，将输入通道数映射到输出通道数' nn.Conv2d(dim, dim, 1), '第二个卷积层，使用分组卷积，卷积核大小为kernel_size，padding为kernel_size//2，padding_mode为reflect' nn.Conv2d(dim, dim, kernel_size=kernel_size, padding=kernel_size//2, groups=dim, padding_mode='reflect') ) self.Wg = nn.Sequential( '第一个卷积层，将输入通道数映射到输出通道数' nn.Conv2d(dim, dim, 1), # 激活函数 '使用指定的激活函数，如果gate_act为Sigmoid或Tanh，则直接使用gate_act()，否则使用gate_act(inplace=True)' gate_act() if gate_act in [nn.Sigmoid, nn.Tanh] else gate_act(inplace=True) ) # 一个卷积层 self.proj = nn.Conv2d(dim, dim, 1) # 初始化权重 self.apply(self._init_weights)

def _init_weights(self, m):
    '初始化卷积层的权重'
    if isinstance(m, nn.Conv2d):
        # 计算gain
        gain = (8 * self.net_depth) ** (-1/4)
        # 计算fan_in和fan_out
        fan_in, fan_out = _calculate_fan_in_and_fan_out(m.weight)
        # 计算标准差
        std = gain * math.sqrt(2.0 / float(fan_in + fan_out))
        # 初始化权重
        trunc_normal_(m.weight, std=std)

        if m.bias is not None:
            nn.init.constant_(m.bias, 0)

def forward(self, X):
    '卷积层的前向传播'
    # 输出
    out = self.Wv(X) * self.Wg(X)
    out = self.proj(out)
    return out

定义一个基本块

class BasicBlock(nn.Module): '定义一个基本块，包含一个归一化层和一个卷积层' def init(self, net_depth, dim, kernel_size=3, conv_layer=ConvLayer, norm_layer=nn.BatchNorm2d, gate_act=nn.Sigmoid): super().init() # 归一化层 self.norm = norm_layer(dim) # 卷积层 self.conv = conv_layer(net_depth, dim, kernel_size, gate_act) def forward(self, x): '基本块的前向传播' identity = x x = self.norm(x) x = self.conv(x) x = identity + x return x

定义一个基本层

class BasicLayer(nn.Module): '定义一个基本层，包含多个基本块' def init(self, net_depth, dim, depth, kernel_size=3, conv_layer=ConvLayer, norm_layer=nn.BatchNorm2d, gate_act=nn.Sigmoid): super().init() self.dim = dim self.depth = depth # 建立基本块 self.blocks = nn.ModuleList([ '建立一个包含depth个基本块的列表' BasicBlock(net_depth, dim, kernel_size, conv_layer, norm_layer, gate_act) for i in range(depth)])

def forward(self, x):
    '基本层的前向传播'
    for blk in self.blocks:
        x = blk(x)
    return x

定义一个patch embedding层

class PatchEmbed(nn.Module): '定义一个patch embedding层，将输入图像划分为patch，并将其映射到一个更高维度的特征空间' def init(self, patch_size=4, in_chans=3, embed_dim=96, kernel_size=None): super().init() self.in_chans = in_chans self.embed_dim = embed_dim if kernel_size is None: kernel_size = patch_size # 卷积层 self.proj = nn.Conv2d(in_chans, embed_dim, kernel_size=kernel_size, stride=patch_size, padding=(kernel_size-patch_size+1)//2, padding_mode='reflect')

def forward(self, x):
    'patch embedding层的前向传播'
    x = self.proj(x)
    return x

定义一个patch unembedding层

class PatchUnEmbed(nn.Module): '定义一个patch unembedding层，将高维度的特征空间映射回原始的图像空间' def init(self, patch_size=4, out_chans=3, embed_dim=96, kernel_size=None): super().init() self.out_chans = out_chans self.embed_dim = embed_dim if kernel_size is None: kernel_size = 1 # 两个卷积层 self.proj = nn.Sequential( '第一个卷积层，将输入通道数映射到输出通道数' nn.Conv2d(embed_dim, out_chans*patch_size**2, kernel_size=kernel_size, padding=kernel_size//2, padding_mode='reflect'), '第二个卷积层，使用PixelShuffle，将特征图上采样到原始图像大小' nn.PixelShuffle(patch_size) )

def forward(self, x):
    'patch unembedding层的前向传播'
    x = self.proj(x)
    return x

SK融合层

class SKFusion(nn.Module): '定义一个SK融合层，用于融合来自不同尺度的特征图' def init(self, dim, height=2, reduction=8): super(SKFusion, self).init() self.height = height d = max(int(dim/reduction), 4) # MLP网络 self.mlp = nn.Sequential( '全局平均池化层，将特征图缩减为1x1大小' nn.AdaptiveAvgPool2d(1), '第一个卷积层，将输入通道数映射到d个通道' nn.Conv2d(dim, d, 1, bias=False), 'ReLU激活函数' nn.ReLU(True), '第二个卷积层，将输入通道数映射到dimheight个通道' nn.Conv2d(d, dimheight, 1, bias=False) ) # softmax函数 self.softmax = nn.Softmax(dim=1)

def forward(self, in_feats):
    'SK融合层的前向传播'
    B, C, H, W = in_feats[0].shape
    in_feats = torch.cat(in_feats, dim=1)
    in_feats = in_feats.view(B, self.height, C, H, W)
    feats_sum = torch.sum(in_feats, dim=1)
    attn = self.mlp(feats_sum)
    attn = self.softmax(attn.view(B, self.height, C, 1, 1))
    out = torch.sum(in_feats*attn, dim=1)
    return out

定义一个gUNet模型

class gUNet(nn.Module): '定义一个gUNet模型，用于图像去噪' def init(self, kernel_size=5, base_dim=32, depths=[4, 4, 4, 4, 4, 4, 4], conv_layer=ConvLayer, norm_layer=nn.BatchNorm2d, gate_act=nn.Sigmoid, fusion_layer=SKFusion): super(gUNet, self).init() # setting assert len(depths) % 2 == 1 stage_num = len(depths) half_num = stage_num // 2 net_depth = sum(depths) embed_dims = [2i*base_dim for i in range(half_num)] embed_dims = embed_dims + [2half_num*base_dim] + embed_dims[::-1]

    self.patch_size = 2 ** (stage_num // 2)
    self.stage_num = stage_num
    self.half_num = half_num

    # input convolution
    # 输入卷积层
    self.inconv = PatchEmbed(patch_size=1, in_chans=3, embed_dim=embed_dims[0], kernel_size=3)

    # backbone
    # 基础层列表
    self.layers = nn.ModuleList()
    # patch embedding层列表
    self.downs = nn.ModuleList()
    # patch unembedding层列表
    self.ups = nn.ModuleList()
    # 卷积层列表
    self.skips = nn.ModuleList()
    # SK融合层列表
    self.fusions = nn.ModuleList()

    for i in range(self.stage_num):
        # 建立一层基本层
        self.layers.append(BasicLayer(dim=embed_dims[i], depth=depths[i], net_depth=net_depth, kernel_size=kernel_size,
                                      conv_layer=conv_layer, norm_layer=norm_layer, gate_act=gate_act))

    for i in range(self.half_num):
        # 建立patch embedding层
        self.downs.append(PatchEmbed(patch_size=2, in_chans=embed_dims[i], embed_dim=embed_dims[i+1]))
        # 建立patch unembedding层
        self.ups.append(PatchUnEmbed(patch_size=2, out_chans=embed_dims[i], embed_dim=embed_dims[i+1]))
        # 建立卷积层
        self.skips.append(nn.Conv2d(embed_dims[i], embed_dims[i], 1))
        # 建立SK融合层
        self.fusions.append(fusion_layer(embed_dims[i]))

    # output convolution
    # 输出卷积层
    self.outconv = PatchUnEmbed(patch_size=1, out_chans=3, embed_dim=embed_dims[-1], kernel_size=3)


def forward(self, x):
    'gUNet模型的前向传播'
    # 输入卷积层
    feat = self.inconv(x)

    skips = []

    # 前半段
    for i in range(self.half_num):
        feat = self.layers[i](feat)
        skips.append(self.skips[i](feat))
        feat = self.downs[i](feat)

    # 后半段
    for i in range(self.half_num-1, -1, -1):
        feat = self.ups[i](feat)
        feat = self.fusions[i]([feat, skips[i]])
        feat = self.layers[self.stage_num-i-1](feat)

    x = self.outconv(feat) + x

    return x

all = ['gUNet', 'gunet_t', 'gunet_s', 'gunet_b', 'gunet_d']

Normalization batch size of 16~32 may be good

def gunet_t(): # 4 cards 2080Ti return gUNet(kernel_size=5, base_dim=24, depths=[2, 2, 2, 4, 2, 2, 2], conv_layer=ConvLayer, norm_layer=nn.BatchNorm2d, gate_act=nn.Sigmoid, fusion_layer=SKFusion)

def gunet_s(): # 4 cards 3090 return gUNet(kernel_size=5, base_dim=24, depths=[4, 4, 4, 8, 4, 4, 4], conv_layer=ConvLayer, norm_layer=nn.BatchNorm2d, gate_act=nn.Sigmoid, fusion_layer=SKFusion)

def gunet_b(): # 4 cards 3090 return gUNet(kernel_size=5, base_dim=24, depths=[8, 8, 8, 16, 8, 8, 8], conv_layer=ConvLayer, norm_layer=nn.BatchNorm2d, gate_act=nn.Sigmoid, fusion_layer=SKFusion)

def gunet_d(): # 4 cards 3090 return gUNet(kernel_size=5, base_dim=24, depths=[16, 16, 16, 32, 16, 16, 16], conv_layer=ConvLayer, norm_layer=nn.BatchNorm2d, gate_act=nn.Sigmoid, fusion_layer=SKFusion)

gUNet模型代码详解：每一行代码的注释
