Audio Waveform Recovery from Spectrogram: Python Implementation

The code provides a set of functions for recovering audio waveform from a spectrogram. It takes as input a predicted magnitude spectrogram, the ground truth complex spectrogram, the overlap size, and the window function used to create the spectrogram. It returns the recovered audio waveform.

The 'recover_wav' function first recovers the complex spectrogram from the predicted magnitude spectrogram and the ground truth complex spectrogram, then recovers the whole spectrogram from the half spectrogram, and finally recovers the audio waveform from the whole spectrogram using the overlap-add procedure. If a specific length of waveform is required, it pads or truncates the output accordingly.

The 'real_to_complex' function takes as input the predicted magnitude spectrogram and the ground truth complex spectrogram, and returns the complex spectrogram by replacing the phase of the ground truth with that of the predicted magnitude.

The 'half_to_whole' function takes as input the half spectrogram and returns the whole spectrogram by concatenating it with its complex conjugate.

The 'ifft_to_wav' function takes as input the whole spectrogram and returns the audio waveform by performing an inverse Fourier transform.

The 'pad_or_trunc' function takes as input the recovered waveform and the desired length of the output waveform, and returns the waveform padded with zeros or truncated accordingly.

The 'recover_gt_wav' function takes as input the ground truth complex spectrogram, the overlap size, and the window function, and returns the corresponding waveform using the same procedure as 'recover_wav'.

The 'deframesig' function performs the overlap-add procedure to recover the waveform from the frames. It takes as input the frames, the desired length of the output waveform, the frame length, the frame step, and the window function used to create the frames.

import numpy as np
import numpy
import decimal

def recover_wav(pd_abs_x, gt_x, n_overlap, winfunc, wav_len=None):
    'Recover wave from spectrogram.
    If you are using scipy.signal.spectrogram, you may need to multipy a scaler
    to the recovered audio after using this function. For example,
    recover_scaler = np.sqrt((ham_win**2).sum())

    Args:
      pd_abs_x: 2d array, (n_time, n_freq)
      gt_x: 2d complex array, (n_time, n_freq)
      n_overlap: integar.
      winfunc: func, the analysis window to apply to each frame.
      wav_len: integer. Pad or trunc to wav_len with zero.

    Returns:
      1d array.
    '
    x = real_to_complex(pd_abs_x, gt_x)
    x = half_to_whole(x)
    frames = ifft_to_wav(x)
    (n_frames, n_window) = frames.shape
    s = deframesig(frames=frames, siglen=0, frame_len=n_window,
                   frame_step=n_window-n_overlap, winfunc=winfunc)
    if wav_len:
        s = pad_or_trunc(s, wav_len)
    return s

def real_to_complex(pd_abs_x, gt_x):
    'Recover pred spectrogram's phase from ground truth's phase.

    Args:
      pd_abs_x: 2d array, (n_time, n_freq)
      gt_x: 2d complex array, (n_time, n_freq)

    Returns:
      2d complex array, (n_time, n_freq)
    '
    theta = np.angle(gt_x)
    cmplx = pd_abs_x * np.exp(1j * theta)
    return cmplx

def half_to_whole(x):
    'Recover whole spectrogram from half spectrogram.
    '
    return np.concatenate((x, np.fliplr(np.conj(x[:, 1:-1]))), axis=1)

def ifft_to_wav(x):
    'Recover wav from whole spectrogram'
    return np.real(np.fft.ifft(x))

def pad_or_trunc(s, wav_len):
    if len(s) >= wav_len:
        s = s[0 : wav_len]
    else:
        s = np.concatenate((s, np.zeros(wav_len - len(s))))
    return s

def recover_gt_wav(x, n_overlap, winfunc, wav_len=None):
    'Recover ground truth wav.
    '
    x = half_to_whole(x)
    frames = ifft_to_wav(x)
    (n_frames, n_window) = frames.shape
    s = deframesig(frames=frames, siglen=0, frame_len=n_window,
                   frame_step=n_window-n_overlap, winfunc=winfunc)
    if wav_len:
        s = pad_or_trunc(s, wav_len)
    return s

def deframesig(frames,siglen,frame_len,frame_step,winfunc=lambda x:numpy.ones((x,))):
    'Does overlap-add procedure to undo the action of framesig.
    Ref: From https://github.com/jameslyons/python_speech_features

    :param frames: the array of frames.
    :param siglen: the length of the desired signal, use 0 if unknown. Output will be truncated to siglen samples.
    :param frame_len: length of each frame measured in samples.
    :param frame_step: number of samples after the start of the previous frame that the next frame should begin.
    :param winfunc: the analysis window to apply to each frame. By default no window is applied.
    :returns: a 1-D signal.
    '
    frame_len = round_half_up(frame_len)
    frame_step = round_half_up(frame_step)
    numframes = numpy.shape(frames)[0]
    assert numpy.shape(frames)[1] == frame_len, ''frames' matrix is wrong size, 2nd dim is not equal to frame_len'

    indices = numpy.tile(numpy.arange(0,frame_len),(numframes,1)) + numpy.tile(numpy.arange(0,numframes*frame_step,frame_step),(frame_len,1)).T
    indices = numpy.array(indices,dtype=numpy.int32)
    padlen = (numframes-1)*frame_step + frame_len

    if siglen <= 0: siglen = padlen

    rec_signal = numpy.zeros((padlen,))
    window_correction = numpy.zeros((padlen,))
    win = winfunc(frame_len)

    for i in range(0,numframes):
        window_correction[indices[i,:]] = window_correction[indices[i,:]] + win + 1e-15 #add a little bit so it is never zero
        rec_signal[indices[i,:]] = rec_signal[indices[i,:]] + frames[i,:]

    rec_signal = rec_signal/window_correction
    return rec_signal[0:siglen]

def round_half_up(number):
    return int(decimal.Decimal(number).quantize(decimal.Decimal('1'), rounding=decimal.ROUND_HALF_UP))
