Python音频信号恢复库：从频谱图重建音频

import numpy as np
import numpy
import decimal

def recover_wav(pd_abs_x, gt_x, n_overlap, winfunc, wav_len=None):
    'Recover wave from spectrogram.
    If you are using scipy.signal.spectrogram, you may need to multipy a scaler
    to the recovered audio after using this function. For example,
    recover_scaler = np.sqrt((ham_win**2).sum())

    Args:
      pd_abs_x: 2d array, (n_time, n_freq)
      gt_x: 2d complex array, (n_time, n_freq)
      n_overlap: integar.
      winfunc: func, the analysis window to apply to each frame.
      wav_len: integer. Pad or trunc to wav_len with zero.

    Returns:
      1d array.
    '
    x = real_to_complex(pd_abs_x, gt_x)
    x = half_to_whole(x)
    frames = ifft_to_wav(x)
    (n_frames, n_window) = frames.shape
    s = deframesig(frames=frames, siglen=0, frame_len=n_window,
                   frame_step=n_window-n_overlap, winfunc=winfunc)
    if wav_len:
        s = pad_or_trunc(s, wav_len)
    return s

def real_to_complex(pd_abs_x, gt_x):
    'Recover pred spectrogram's phase from ground truth's phase.

    Args:
      pd_abs_x: 2d array, (n_time, n_freq)
      gt_x: 2d complex array, (n_time, n_freq)

    Returns:
      2d complex array, (n_time, n_freq)
    '
    theta = np.angle(gt_x)
    cmplx = pd_abs_x * np.exp(1j * theta)
    return cmplx

def half_to_whole(x):
    'Recover whole spectrogram from half spectrogram.
    '
    return np.concatenate((x, np.fliplr(np.conj(x[:, 1:-1]))), axis=1)

def ifft_to_wav(x):
    'Recover wav from whole spectrogram'
    return np.real(np.fft.ifft(x))

def pad_or_trunc(s, wav_len):
    if len(s) >= wav_len:
        s = s[0 : wav_len]
    else:
        s = np.concatenate((s, np.zeros(wav_len - len(s))))
    return s

def recover_gt_wav(x, n_overlap, winfunc, wav_len=None):
    'Recover ground truth wav.
    '
    x = half_to_whole(x)
    frames = ifft_to_wav(x)
    (n_frames, n_window) = frames.shape
    s = deframesig(frames=frames, siglen=0, frame_len=n_window,
                   frame_step=n_window-n_overlap, winfunc=winfunc)
    if wav_len:
        s = pad_or_trunc(s, wav_len)
    return s

def deframesig(frames,siglen,frame_len,frame_step,winfunc=lambda x:numpy.ones((x,))):
    'Does overlap-add procedure to undo the action of framesig.
    Ref: From https://github.com/jameslyons/python_speech_features

    :param frames: the array of frames.
    :param siglen: the length of the desired signal, use 0 if unknown. Output will be truncated to siglen samples.
    :param frame_len: length of each frame measured in samples.
    :param frame_step: number of samples after the start of the previous frame that the next frame should begin.
    :param winfunc: the analysis window to apply to each frame. By default no window is applied.
    :returns: a 1-D signal.
    '
    frame_len = round_half_up(frame_len)
    frame_step = round_half_up(frame_step)
    numframes = numpy.shape(frames)[0]
    assert numpy.shape(frames)[1] == frame_len, ''frames' matrix is wrong size, 2nd dim is not equal to frame_len'

    indices = numpy.tile(numpy.arange(0,frame_len),(numframes,1)) + numpy.tile(numpy.arange(0,numframes*frame_step,frame_step),(frame_len,1)).T
    indices = numpy.array(indices,dtype=numpy.int32)
    padlen = (numframes-1)*frame_step + frame_len

    if siglen <= 0: siglen = padlen

    rec_signal = numpy.zeros((padlen,))
    window_correction = numpy.zeros((padlen,))
    win = winfunc(frame_len)

    for i in range(0,numframes):
        window_correction[indices[i,:]] = window_correction[indices[i,:]] + win + 1e-15 #add a little bit so it is never zero
        rec_signal[indices[i,:]] = rec_signal[indices[i,:]] + frames[i,:]

    rec_signal = rec_signal/window_correction
    return rec_signal[0:siglen]

def round_half_up(number):
    return int(decimal.Decimal(number).quantize(decimal.Decimal('1'), rounding=decimal.ROUND_HALF_UP))
代码详细解释内容：本代码实现了从频谱图中恢复原始音频信号的功能。具体来说，给定预测的频谱图和真实的频谱图，以及其他一些参数，比如重叠长度、窗函数等，可以通过本代码实现从频谱图中恢复出音频信号。

具体实现过程包括以下几个函数：

1. recover_wav(pd_abs_x, gt_x, n_overlap, winfunc, wav_len=None)

该函数接受四个参数：预测的频谱图pd_abs_x、真实的频谱图gt_x、重叠长度n_overlap、窗函数winfunc，以及可选参数wav_len。该函数首先将预测的频谱图的相位信息恢复为真实的相位信息，然后将半频谱图转换为全频谱图，接着将全频谱图进行逆傅里叶变换，得到音频的帧序列，最后使用重叠加法将音频帧序列合并成一个完整的音频信号，并根据可选参数wav_len对音频信号进行截断或填充。

2. real_to_complex(pd_abs_x, gt_x)

该函数接受两个参数：预测的频谱图pd_abs_x和真实的频谱图gt_x，返回一个复数形式的频谱图，其中预测的频谱图的相位信息被替换为真实的相位信息。

3. half_to_whole(x)

该函数接受一个半频谱图x，返回一个全频谱图，即将半频谱图的右半部分（除去第一列和最后一列）通过共轭反转对称到左侧。

4. ifft_to_wav(x)

该函数接受一个全频谱图x，返回一个音频帧序列，即将全频谱图进行逆傅里叶变换。

5. pad_or_trunc(s, wav_len)

该函数接受一个音频信号s和可选参数wav_len，根据wav_len对音频信号进行截断或填充。

6. recover_gt_wav(x, n_overlap, winfunc, wav_len=None)

该函数与recover_wav函数类似，但不需要提供预测的频谱图pd_abs_x，而是直接使用真实的频谱图gt_x进行恢复。

7. deframesig(frames,siglen,frame_len,frame_step,winfunc=lambda x:numpy.ones((x,)))

该函数实现了重叠加法，将音频帧序列合并成一个完整的音频信号。该函数接受五个参数：音频帧序列frames、期望的音频信号长度siglen、帧长度frame_len、帧间隔frame_step、以及窗函数winfunc。该函数首先将各个帧按照重叠加法的方式合并，然后通过窗函数对合并后的结果进行加权平均，最后根据siglen对结果进行截断。

8. round_half_up(number)

该函数用于将一个浮点数四舍五入为整数。
