CSS3 动画实现动态圆形时钟 - HTML、CSS 和 JavaScript 代码示例
这是一个比较复杂的任务,需要使用 HTML、CSS 和 JavaScript 来实现。
首先,我们需要创建一个圆形的表盘。可以使用 CSS 中的 border-radius 属性来创建圆形,然后使用 CSS 中的 transform 属性来将其旋转到合适的位置。
接下来,我们需要添加刻度和时针、分针、秒针。可以使用 CSS 中的伪元素::before 和::after 来创建刻度和指针。需要注意的是,指针需要使用 transform-origin 属性来设置旋转中心,并使用 transform 属性来旋转到正确的位置。
最后,我们需要使用 JavaScript 来获取当前时间,并使用 CSS 中的 animation 属性来让时针、分针、秒针按时间转动起来。可以使用 setInterval 函数每秒钟更新一次指针的位置。
以下是一个示例代码:
HTML:
<div class='clock'>
<div class='hour-hand'></div>
<div class='minute-hand'></div>
<div class='second-hand'></div>
<div class='face'>
<div class='mark hour-1'></div>
<div class='mark hour-2'></div>
<div class='mark hour-3'></div>
<div class='mark hour-4'></div>
<div class='mark hour-5'></div>
<div class='mark hour-6'></div>
<div class='mark hour-7'></div>
<div class='mark hour-8'></div>
<div class='mark hour-9'></div>
<div class='mark hour-10'></div>
<div class='mark hour-11'></div>
<div class='mark hour-12'></div>
</div>
</div>
CSS:
.clock {
position: relative;
display: inline-block;
width: 200px;
height: 200px;
border-radius: 50%;
background-color: white;
transform: rotate(-90deg);
}
.face {
position: absolute;
top: 0;
left: 0;
width: 100%;
height: 100%;
}
.mark {
position: absolute;
top: 50%;
left: 50%;
width: 4px;
height: 10px;
margin-top: -5px;
margin-left: -2px;
background-color: black;
transform-origin: bottom center;
}
.hour-1 {
transform: rotate(30deg);
}
.hour-2 {
transform: rotate(60deg);
}
.hour-3 {
transform: rotate(90deg);
}
.hour-4 {
transform: rotate(120deg);
}
.hour-5 {
transform: rotate(150deg);
}
.hour-6 {
transform: rotate(180deg);
}
.hour-7 {
transform: rotate(210deg);
}
.hour-8 {
transform: rotate(240deg);
}
.hour-9 {
transform: rotate(270deg);
}
.hour-10 {
transform: rotate(300deg);
}
.hour-11 {
transform: rotate(330deg);
}
.hour-12 {
transform: rotate(0deg);
}
.hour-hand {
position: absolute;
top: 50%;
left: 50%;
width: 4px;
height: 40px;
margin-top: -20px;
margin-left: -2px;
background-color: black;
transform-origin: bottom center;
animation: hour-hand 43200s linear infinite;
}
.minute-hand {
position: absolute;
top: 50%;
left: 50%;
width: 4px;
height: 60px;
margin-top: -30px;
margin-left: -2px;
background-color: black;
transform-origin: bottom center;
animation: minute-hand 3600s linear infinite;
}
.second-hand {
position: absolute;
top: 50%;
left: 50%;
width: 2px;
height: 70px;
margin-top: -35px;
margin-left: -1px;
background-color: red;
transform-origin: bottom center;
animation: second-hand 60s linear infinite;
}
@keyframes hour-hand {
from {
transform: rotate(0deg);
}
to {
transform: rotate(360deg);
}
}
@keyframes minute-hand {
from {
transform: rotate(0deg);
}
to {
transform: rotate(360deg);
}
}
@keyframes second-hand {
from {
transform: rotate(0deg);
}
to {
transform: rotate(360deg);
}
}
JavaScript:
function updateClock() {
const now = new Date();
const hour = now.getHours() % 12;
const minute = now.getMinutes();
const second = now.getSeconds();
const hourHand = document.querySelector('.hour-hand');
const minuteHand = document.querySelector('.minute-hand');
const secondHand = document.querySelector('.second-hand');
const hourRotation = (hour * 30) + (minute * 0.5);
const minuteRotation = (minute * 6) + (second * 0.1);
const secondRotation = second * 6;
hourHand.style.transform = `rotate(${hourRotation}deg)`;
minuteHand.style.transform = `rotate(${minuteRotation}deg)`;
secondHand.style.transform = `rotate(${secondRotation}deg)`;
}
setInterval(updateClock, 1000);
