BQ27441电池管理芯片I2C通信函数实现

/************************************************************************

LOCAL FUNCTIONS */ void I2CTransfer(uint16_t deviceAddr, uint8_t cmdArray[], uint8_t dataArray[], uint16_t cmdLen, uint16_t dataLen, uint16_t flag) { // Õâ¸öº¯ÊýÓÉi2cReadRegister/i2cWriteRegisterµ÷ÓÃ£¬ÊÇ×î»ù±¾µÄI2C´«Êäº¯Êý¡£ // ÏÈ¼ì²éflag£¬Õâ´Î´«ÊäÊÇ¶Á»¹ÊÇÐ´ // È»ºó¼ì²é¶ÁÐ´µÄ×Ö½ÚÊý£¬¶ÔÕÕBQ27441Ð¾Æ¬ÊÖ²á

deviceAddr = BQ27441_G1_ADDR;

//¼ì²éflag if(flag==I2C_FLAG_WRITE_READ) { uint8_t Value = 0x00; /* 1.I2CÍâÉè¿ÕÏÐ. */ while(LL_I2C_IsActiveFlag_BUSY(I2C_Handle));
```
 LL_I2C_IsEnabled(I2C_Handle);
 LL_I2C_EnableBitPOS(I2C_Handle);

 /* 2.STARTÐÅºÅ */
```
LL_I2C_AcknowledgeNextData(I2C_Handle, LL_I2C_ACK); LL_I2C_GenerateStartCondition(I2C_Handle); while(!LL_I2C_IsActiveFlag_SB(I2C_Handle));
```
 /* 2.Ð´Æ÷¼þµØÖ· */
```
LL_I2C_TransmitData8(I2C_Handle, deviceAddr); while(!LL_I2C_IsActiveFlag_ADDR(I2C_Handle));

LL_I2C_ClearFlag_ADDR(I2C_Handle); /* 3.µØÖ·Î». */ while(!LL_I2C_IsActiveFlag_TXE(I2C_Handle));
```
 /* 4.·¢ËÍÆ÷¼þ¼Ä´æÆ÷µØÖ·. */
```
LL_I2C_TransmitData8(I2C_Handle, BQ27441_G1_STATE_OF_CHARGE_CMD); while(!LL_I2C_IsActiveFlag_TXE(I2C_Handle));
```
 /* 5.RESTARTÐÅºÅ. */
```
//LL_I2C_GenerateStopCondition(I2C_Handle); LL_I2C_GenerateStartCondition(I2C_Handle); while(!LL_I2C_IsActiveFlag_SB(I2C_Handle));
```
 /* 6.ÖØÐÂ·¢ËÍ. */
```
LL_I2C_TransmitData8(I2C_Handle, deviceAddr<<1); while(!LL_I2C_IsActiveFlag_ADDR(I2C_Handle));
```
 	if((dataLen == 2))
 	{
 /* 7.STOP. */
```
LL_I2C_AcknowledgeNextData(I2C_Handle, LL_I2C_NACK); LL_I2C_ClearFlag_ADDR(I2C_Handle); LL_I2C_GenerateStopCondition(I2C_Handle); while(!LL_I2C_IsActiveFlag_RXNE(I2C_Handle));
```
 	}
 /* 8.Êý¾Ý¶ÁÈ¡. */
```
Value = LL_I2C_ReceiveData8(I2C_Handle); return ;

volatile uint16_t temp = 0; while(1) { temp = BQ27441_G1_GetChecksum(&bq27441_g1); } } else if (flag==I2C_FLAG_WRITE_WRITE) {

} }

static uint16_t i2cReadRegister(uint16_t addr,uint8_t regOffset) { uint16_t result = 0x00;

uint8_t cmdArray[1];
uint8_t dataArray[2];

cmdArray[0] = regOffset;
I2CTransfer(addr << 1, cmdArray, dataArray, 1, 2, I2C_FLAG_WRITE_READ );

result = (dataArray[1] << 8) | (dataArray[0]);
return result;
return dataArray[0];

}

static void i2cWriteRegister(uint16_t addr,uint8_t regOffset, uint8_t writeData) { uint8_t cmdArray[1]; uint8_t dataArray[2];

cmdArray[0] = regOffset;
dataArray[0] = writeData;
I2CTransfer(addr << 1, cmdArray, dataArray, 1, 2, I2C_FLAG_WRITE_WRITE );

}

/************************************************************************

FUNCTIONS */

//BQ27441³õÊ¼»¯ bq27441_g1_t* BQ27441_Init() { /* ³õÊ¼»¯Í¨ÐÅ½Ó¿Ú */ LL_I2C_Enable(I2C_Handle);

/* ³õÊ¼»¯BQ27441 */ bq27441_g1.Read = i2cReadRegister; bq27441_g1.Write = i2cWriteRegister;

/* ³õÊ¼»¯³õÊ¼»¯BQ27441¼Ä´æÆ÷ */

return &bq27441_g1;

如何在main函数完成相关函数的添加内容：在main函数中，可以先调用BQ27441_Init函数进行初始化，然后调用BQ27441的其他函数进行操作。例如：

int main(void) { // 初始化BQ27441 bq27441_g1_t* bq = BQ27441_Init();

// 读取电池电量百分比 uint16_t soc = bq->Read(BQ27441_G1_ADDR, BQ27441_G1_STATE_OF_CHARGE_CMD);

// 设置电池充电模式 bq->Write(BQ27441_G1_ADDR, BQ27441_G1_SET_CHARGING_ENABLE_CMD, 0x01);

// 循环等待 while (1) { // ... } }
