本代码实现了读取DICOM格式的医学影像文件并显示图像的功能。

具体功能实现如下：

  1. 打开DICOM文件，判断是否为DICOM格式文件。

  2. 解析DICOM文件头信息，获取文件中像素数据的起始位置、像素数据的长度、图像的宽度、高度、通道数、像素类型等信息。

  3. 根据像素类型、图像宽度、高度等信息，读取像素数据。

  4. 根据窗位、窗宽等信息对像素数据进行线性变换。

  5. 将像素数据转换为OpenCV支持的Mat格式。

  6. 根据通道数，将Mat格式的图像转换为灰度图或彩色图。

  7. 显示图像并等待用户按键退出。

// DICOM医学影像文件读取与显示代码

//#include <opencv2/opencv.hpp>
#include 'highgui.h'
/*#pragma comment(lib, "opencv_core2411d.lib")
#pragma comment(lib, "opencv_imgproc2411d.lib")
#pragma comment(lib, "opencv_highgui2411d.lib")*/
using namespace cv;
using namespace std;
struct TagValue
{
	unsigned short tag1;
	unsigned short tag2;
};

// 原始象素类型
enum E_SourcePixelType
{
	ESourcePixelType_U16,		// USHORT
	ESourcePixelType_I16,		// SHORT
};


int main()
{
	bool isVR=true;
	bool isLitteEndian=true;
	int file_length=0;
	char VR[3];

	unsigned int pixDataLen=0;
	unsigned int pixDataOffset=0;
	unsigned short channle=0;
	unsigned short rows=0;
	unsigned short cols=0;
	unsigned short dataLen=0;
	unsigned short validLen=0;

	E_SourcePixelType pixelType;

	int windowsWidth=0;
	int windowsCenter=0;

	bool ZeroIsBlack=true;
	float RescaleSlope =0.06;
	float RescaleIntercept=0;

	FILE *fp;
	fp=fopen('11.dcm','rb');
	if(fp==NULL)
	{
		printf('can not open file!');
		return 0;
	}

	fseek(fp,0,SEEK_END);
	file_length=ftell(fp);
	fseek(fp,0,SEEK_SET);

	fseek(fp,128,SEEK_SET);

	char headchar[5];
	memset(headchar,0,5);
	int read_num = fread(headchar,1,4,fp);
	if(read_num!=4)
	{
		fclose(fp);
		return 0;
	}

	if(strcmp(headchar,'DICM'))
	{
		fclose(fp);
		printf('File is not DICM');
		return 0;
	}

	while(ftell(fp)+6<file_length)
	{
		TagValue tag;
		unsigned int len;
		memset(VR,0,3);
		fread(&tag,sizeof(TagValue),1,fp);
		int index=ftell(fp);

		if(tag.tag1==0x02)
		{
			fread(VR,1,2,fp);
			if(!strcmp(VR,'OB')||!strcmp(VR,'OW')||!strcmp(VR,'SQ'))
			{
				fseek(fp,2,SEEK_CUR);
				fread(&len,sizeof(unsigned int),1,fp);
			}
			else
			{
				unsigned short l;
				int ss = fread(&l,sizeof(unsigned short),1,fp);
				int a=ftell(fp);
				len =(unsigned int)l ;
			}
		}
		else if(tag.tag1==0xfffe)
		{
			if(tag.tag2==0xe000||tag.tag2==0xe00d||tag.tag2==0xe0dd)
			{
				fread(&len,sizeof(unsigned int),1,fp);
			}
		}
		else if(isVR==true)
		{
			fread(VR,1,2,fp);
			int a= ftell(fp);
			if(!strcmp(VR,'OB')||!strcmp(VR,'OW')||!strcmp(VR,'SQ'))
			{
				fseek(fp,2,SEEK_CUR);
				fread(&len,sizeof(unsigned int),1,fp);
			}
			else
			{
				unsigned short l;
				l=sizeof(unsigned short);
				fread(&l,sizeof(unsigned short),1,fp);
				a= ftell(fp);
				len =(unsigned int)l ;
			}
		}
		else if(isVR==false)
		{
			fread(&len,sizeof(unsigned int),1,fp);
		}

		if(tag.tag1==0x02&&tag.tag2==0x10)
		{
			char msg[124];
			memset(msg,0,124);
			fread(msg,1,len,fp);

			if(!strcmp(msg,'1.2.840.10008.1.2.1'))
			{
				isLitteEndian=true;
				isVR=true;
			}
			else if(!strcmp(msg,'1.2.840.10008.1.2.2'))
			{
				isLitteEndian=false;
				isVR=true;
			}
			else if(!strcmp(msg,'1.2.840.10008.1.2'))
			{
				isLitteEndian=true;
				isVR=false;
			}
		}
		else if(tag.tag1 ==0x28 && tag.tag2==0x103)
		{
			unsigned short m;
			fread(&m,sizeof(unsigned short),1,fp);
			if(m==0)
			{
				pixelType = ESourcePixelType_U16;
			}
			else if(m ==1)
			{
				pixelType = ESourcePixelType_I16;
			}
		}
		else if(tag.tag1==0x7fe0&&tag.tag2==0x10)
		{
			pixDataLen=len;
			pixDataOffset=ftell(fp);
			fseek(fp,len,SEEK_CUR);

		}
		else if(tag.tag1==0x28&&tag.tag2==0x10)
		{
			fread(&rows,sizeof(unsigned short),1,fp);
		}
		else if(tag.tag1==0x28&&tag.tag2==0x11)
		{
			fread(&cols,sizeof(unsigned short),1,fp);
		}
		else if(tag.tag1==0x28&&tag.tag2==0x02)
		{
			fread(&channle,sizeof(unsigned short),1,fp);
		}
		else if(tag.tag1==0x28&&tag.tag2==0x101)
		{
			fread(&validLen,sizeof(unsigned short),1,fp);
		}
		else if(tag.tag1==0x28&&tag.tag2==0x100)
		{
			fread(&dataLen,sizeof(unsigned short),1,fp);
		}
		else if(tag.tag1==0x28&&tag.tag2==0x1050)
		{
			char msg[11];
			memset(msg,0,11);
			fread(msg,1,len,fp);
			windowsCenter=atoi(msg);

		}
		else if(tag.tag1==0x28,tag.tag2==0x1051)
		{
			//fseek(fp,len,SEEK_CUR);
			char msg[40];
			memset(msg,0,40);
			fread(msg,1,len,fp);
			windowsWidth=atoi(msg);
		}
		else if(tag.tag1==0x0028&&tag.tag2==0x0004)
		{
			char msg[40];
			memset(msg,0,40);
			fread(msg,1,len,fp);
			if(!strcmp(msg,'MONOCHROME1 '))
			{
				ZeroIsBlack=false;
			}
			else if(!strcmp(msg,'MONOCHROME2 '))
			{
				ZeroIsBlack=true;
			}
		}
		else if(tag.tag1==0x0028&&tag.tag2==0x1052)
		{
			char msg[40];
			memset(msg,0,40);
			fread(msg,1,len,fp);
			RescaleIntercept=atof(msg);
		}
		else if(tag.tag1==0x0028&&tag.tag2==0x1053)
		{
			char msg[40];
			memset(msg,0,40);
			fread(msg,1,len,fp);
			RescaleSlope =atof(msg);
		}
		else
		{
			char msg[1024];
			memset(msg,0,1024);
			fread(msg,1,len,fp);


		}
	}

	fseek(fp,pixDataOffset,SEEK_SET);
	if(windowsCenter==0&&windowsWidth==0)
	{
		windowsWidth = 1 << validLen;
		windowsCenter = windowsWidth / 2;
	}

	//int min_value,max_value;
	//min_value=windowsCenter-windowsWidth/2.0+0.5;
	//max_value=windowsCenter+windowsWidth/2.0+0.5;
	//double pers = 255.0/(max_value-min_value);

	Mat src;
	Mat src2;

	int nPixel= 0;

	double fCtA = 0;
	double fCtB = 0;
	fCtA = (double)256 /windowsWidth;
	fCtB = 128 - 256 * (double)windowsCenter / windowsWidth;
	if (fCtB < 0)
	{
		fCtB = 0;
	}
	if (fCtB > 255)
	{
		fCtB = 255;
	}

	if(channle==1)
	{
		src.create((int)rows,(int)cols,CV_8UC1);

		src2.create((int)rows,(int)cols, CV_16SC1);
		for (int i = 0;i<rows;i++)
		{
			for(int j=0;j<cols;j++)
			{
				unsigned short   gray=0;
				short gray2 = 0;
				unsigned char pix[2];
				fread(pix,1,2,fp);
				if(pixelType == ESourcePixelType_U16)
				{
					if(validLen<=8)
					{
						if(isLitteEndian)
						{
							gray=pix[0];
						}
						else
						{
							gray=pix[1];
						}

					}
					else
					{
						long temp = 0;
						if(isLitteEndian)
						{
							gray=*(unsigned short*)pix;

							if(gray > 32767)
							{
								gray = 32767;
							}
							temp =gray*RescaleSlope+RescaleIntercept;
							temp = temp * fCtA + fCtB;
						}
						else
						{
							gray=pix[1]+pix[0]*256;
                            temp =gray*RescaleSlope+RescaleIntercept;
							temp = temp * fCtA + fCtB;
						}

						int nValue = (int)temp;
						if(nValue>0xff)
						{
							nValue=0xff;
						}
						else if(nValue<0)
						{
							nValue=0;

						}
						nPixel = nValue;
					}
				}
				else if(pixelType ==ESourcePixelType_I16)
				{
					if(validLen<=8)
					{
						if(isLitteEndian)
						{
							gray2=pix[0];
						}
						else
						{
							gray2=pix[1];
						}

					}
					else
					{
						long temp = 0;
						if(isLitteEndian)
						{
							gray2=*(short*)pix;

							if(gray2 > 32767)
							{
								gray2 = 32767;
							}
							if(gray2 < -32767)
							{
								gray2 = -32767;
							}
							temp =gray2*RescaleSlope+RescaleIntercept;
							temp = temp * fCtA + fCtB;
						}
						else
						{
							gray2=pix[1]+pix[0]*256;
                            temp =gray2*RescaleSlope+RescaleIntercept;
							temp = temp * fCtA + fCtB;
						}

						int nValue = (int)temp;
						if(nValue>0xff)
						{
							nValue=0xff;
						}
						else if(nValue<0)
						{
							nValue=0;

						}
						nPixel = nValue;
					}
				}


				if(!ZeroIsBlack)
				{
					nPixel=255-nPixel;
				}

				src.at<uchar>(i,j)=nPixel;

			}
			//std::cout<<std::endl;
		}

	}
	else if(channle==3)
	{
		src.create((int)rows,(int)cols,CV_8UC3);
		for (int i = 0;i<rows;i++)
		{
			for(int j=0;j<cols;j++)
			{
				unsigned char pix[3];
				fread(pix,1,3,fp);
				src.at<Vec3b>(i,j)[0]=pix[2];
				src.at<Vec3b>(i,j)[1]=pix[1];
				src.at<Vec3b>(i,j)[2]=pix[0];
			}
		}
	}

	fclose(fp);
	cvNamedWindow('Dicomimage',0);
	imshow('Dicomimage',src);

	cvWaitKey(0);
	return 0;
}
