Fast Descriptors and Correspondence Propagation for Robust Global Point Cloud Registration: Efficient Matlab Implementation

This code is a Matlab implementation of the paper, 'Fast Descriptors and Correspondence Propagation for Robust Global Point Cloud Registration,' published in IEEE Transactions on Image Processing, 2017. It provides a fast and robust approach for point cloud registration. This code is intended for academic research purposes only. Any other use requires explicit authorization from the author. If you encounter any issues or have suggestions for improvement, please contact Huan LEI at hlei.ziyan@gmail.com.

Parameter Configuration for FLANN Search

params.algorithm = 'kdtree';
params.trees = 8;
params.checks = 64;

Data Preparation

srcData = srcCloud.Location';
tarData = tarCloud.Location';
radii = (0.5:0.5:2)*gridStep;

srcCloudDown = pcdownsample(srcCloud, 'gridAverage', Rho);
tarCloudDown = pcdownsample(tarCloud, 'gridAverage', Rho);
srcSeed = srcCloudDown.Location';
tarSeed = tarCloudDown.Location';

Descriptor Computation for Seed Points in the Source Cloud

K = length(radii);
srcIdx = rangesearch(srcData',srcSeed',radii(1));
idxSz = cellfun(@length,srcIdx,'uni',true);
srcIdx = srcIdx(idxSz>10);
srcSeed = srcSeed(:,idxSz>10);
M = sum(idxSz>10);
idx = num2cell((1:M)');
[s,n] = cellfun(@(x,y)svdCov(x,y,srcData,srcSeed),srcIdx,idx,'uni',false);
s = cell2mat(s);
n = cell2mat(n);
for k = 2:K
    srcIdx = rangesearch(srcData',srcSeed',radii(k));
    [sk,nk] = cellfun(@(x,y)svdCov(x,y,srcData,srcSeed),srcIdx,idx,'uni',false);
    s = [s cell2mat(sk)];
    n = [n cell2mat(nk)];
end
s = s';
ds = diff(s);
srcDesp = reshape(ds,3*(K-1),[]);
n = mat2cell(n,3*ones(M,1),K);
srcNorm = cellfun(@(x)reshape(x,[],1),n','uni',false);
srcNorm = cell2mat(srcNorm);

Descriptor Computation for Seed Points in the Target Cloud

tarIdx = rangesearch(tarData',tarSeed',radii(1));
idxSz = cellfun(@length,tarIdx,'uni',true);
tarIdx = tarIdx(idxSz>10);
tarSeed = tarSeed(:,idxSz>10);
N = sum(idxSz>10);
idx = num2cell((1:N)');
[s,n] = cellfun(@(x,y)svdCov(x,y,tarData,tarSeed),tarIdx,idx,'uni',false);
s = cell2mat(s);
n = cell2mat(n);
for k = 2:K
    tarIdx = rangesearch(tarData',tarSeed',radii(k));
    [sk,nk] = cellfun(@(x,y)svdCov(x,y,tarData,tarSeed),tarIdx,idx,'uni',false);
    s = [s cell2mat(sk)];
    n = [n cell2mat(nk)];
end
s = s';
ds = diff(s);
tarDesp = reshape(ds,3*(K-1),[]);
n = mat2cell(n,3*ones(N,1),K);
tarNorm = cellfun(@(x)reshape(x,[],1),n','uni',false);
tarNorm = cell2mat(tarNorm);

Descriptor Matching with FLANN

[srcIdx,dist] = flann_search(srcDesp,tarDesp,1,params); % match with descriptors

Correspondence Aggregation and Best Match Selection

M = size(srcSeed,2);
N = size(tarSeed,2);
seedIdx = srcIdx;
Err = inf(N,1);
tform = cell(1,N);
ovNum = ceil(overlap*N);
distThr = 0.2/4*length(radii);
thetaThr = 10;
threshold = gridStep*gridStep;
for n = 1:N
    seed = srcSeed(:,seedIdx(n));
    seedNorm = srcNorm(:,seedIdx(n));

    % source point cloud
    d = bsxfun(@minus,srcSeed,seed);
    d = sqrt(sum(d.^2,1)); % distance
    inProd = bsxfun(@times,srcNorm,seedNorm);
    inProd = inProd(1:3:end,:) + inProd(2:3:end,:) + inProd(3:3:end,:);
    theta = real(acosd(inProd));  % inner product

    % target point cloud
    r = bsxfun(@minus,tarSeed,tarSeed(:,n));
    r = sqrt(sum(r.^2,1)); % distance
    inProd = bsxfun(@times,tarNorm,tarNorm(:,n));
    inProd = inProd(1:3:end,:) + inProd(2:3:end,:) + inProd(3:3:end,:);
    alpha = real(acosd(inProd));  % inner product

    IDX = rangesearch(r',d',gridStep/2,'distance','cityblock');

    matches = [seedIdx(n) n];
    for m = [1:seedIdx(n)-1 seedIdx(n)+1:M]
        idx = IDX{m};%find(abs(r-d(m))<gridStep/2);%
        if(isempty(idx))
            continue;
        end
        dTheta = bsxfun(@minus,alpha(:,idx),theta(:,m));
        dTheta = abs(dTheta);
        Tab = dTheta<thetaThr;
        Tab = sum(Tab,1);
        if(all(Tab<size(theta,1)))
            continue;
        end
        sim = mean(dTheta,1);
        sim(Tab<size(theta,1)) = inf;
        [minSim,ol] = min(sim);
        R = norm(srcDesp(:,m)-tarDesp(:,idx(ol)));
        if(minSim<thetaThr && R<distThr)
            matches = [matches; m idx(ol)];
        end
    end

    if(size(matches,1)>10)
        match_srcSeed = srcSeed(:,matches(:,1));
        match_tarSeed = tarSeed(:,matches(:,2));
        CS = ransac(double(match_srcSeed),double(match_tarSeed),threshold);

        if(sum(CS)<3)
            continue;
        end

        match_srcSeed = match_srcSeed(:,CS);
        match_tarSeed = match_tarSeed(:,CS);
        [T, Eps] = estimateRigidTransform(match_tarSeed, match_srcSeed);
        tarEst = T*[srcSeed;ones(1,M)];
        tarEst = tarEst(1:3,:);
        tform{n} = T;

        [index,dist] = flann_search(tarEst,tarSeed,1,params);
        [dist,ind] = sort(dist);
        Err(n) = sum(sum((tarEst(:,index(ind(1:ovNum)))-tarSeed(:,ind(1:ovNum))).^2));
    end
end
[v,idx] = min(Err);
T = tform{idx};
tarEst = T*[srcData;ones(1,length(srcData))];
tarEst = tarEst(1:3,:);

Trimmed ICP Refinement

%--------------------------------------------------------------------------
% [index,dist] = flann_search(tarEst,tarData,1,params);
% [dist,ind] = sort(dist);
% ovNum = ceil(overlap*length(dist));
% tmp = mean(sum((tarEst(:,index(ind(1:ovNum)))-tarData(:,ind(1:ovNum))).^2));
% rmsE(1) = sqrt(tmp);
%
% match_srcData = srcData(:,index(ind(1:ovNum)));
% match_tarData = tarData(:,ind(1:ovNum));
%
% maxIter = 100; dE = inf; iter = 1;
% errThr = 1e-4; rmseThr = 0.001;
% while(dE>errThr && iter<maxIter && rmsE(iter)>rmseThr)
%     [T, Eps] = estimateRigidTransform(match_tarData, match_srcData);
%     tarEst = T*[srcData;ones(1,length(srcData))];
%     tarEst = tarEst(1:3,:);
%
%     iter = iter + 1;
%
%     [index,dist] = flann_search(tarEst,tarData,1,params);
%     [dist,ind] = sort(dist);
%     tmp = mean(sum((tarEst(:,index(ind(1:ovNum)))-tarData(:,ind(1:ovNum))).^2));
%     rmsE(iter) = sqrt(tmp);
%
%     match_srcData = srcData(:,index(ind(1:ovNum)));
%     match_tarData = tarData(:,ind(1:ovNum));
%     dE = rmsE(iter - 1) - rmsE(iter);
% end
%--------------------------------------------------------------------------

src2tarEst = tarEst;

This implementation utilizes various Matlab functions for efficient processing, including pcdownsample, rangesearch, svdCov, flann_search, ransac, and estimateRigidTransform. It leverages these functions for tasks such as downsampling, nearest neighbor search, covariance matrix computation, descriptor matching, and rigid transformation estimation.

Note: This code is written in Matlab and relies on specific functions available in the Matlab environment. You may need to adjust or rewrite parts of the code if you aim to implement it in another programming language. Please consult the documentation of the functions used to understand their specific behaviors and how to replace them with equivalent functions in other languages. Also, ensure you have the necessary libraries and packages installed for proper functionality. For instance, FLANN (Fast Library for Approximate Nearest Neighbors) is used for efficient nearest neighbor search. You might need to install and configure it appropriately based on your chosen programming language and environment.
