{ "title": "Hourly Electric Power Consumption Prediction using Federated Learning with Particle Swarm Optimization", "description": "This code implements a federated learning approach for hourly electric power consumption prediction, employing Particle Swarm Optimization (PSO) to optimize the model parameters. The model uses an LSTM network to capture temporal dependencies in the data.", "keywords": "Federated Learning, LSTM, Particle Swarm Optimization, Electric Power Consumption, Time Series Prediction", "content": "import os import random import numpy as np import pandas as pd

import torch import torch.nn as nn import torch.nn.functional as F import torch.optim as optim import torch.utils.data as Data

from sklearn.model_selection import train_test_split from tqdm import tqdm

device = torch.device("cuda" if torch.cuda.is_available() else "cpu")

load dataset from a csv file

df = pd.read_csv('Electric_Power_Consumption.csv', delimiter=';', parse_dates={'dt': ['Date', 'Time']}, infer_datetime_format=True, na_values=['nan', '?'], index_col='dt')

fill missing values with the last known value

df.fillna(method='ffill', inplace=True)

resample to hourly data

df = df.resample('H').mean()

normalize the data

df = (df - df.mean()) / df.std()

split into training and testing datasets

train_df, test_df = train_test_split(df, test_size=0.2, shuffle=False)

convert data into sequences of length seq_len+timestep_pred

seq_len = 24 * 7 # one week timestep_pred = 24 # predict the next 24 hours train_data = [] for i in range(seq_len, len(train_df) - timestep_pred): train_data.append(train_df.iloc[i - seq_len:i].values.tolist())

train_data = np.array(train_data) train_labels = train_df.iloc[seq_len + timestep_pred:].values

test_data = [] for i in range(seq_len, len(test_df) - timestep_pred): test_data.append(test_df.iloc[i - seq_len:i].values.tolist())

test_data = np.array(test_data) test_labels = test_df.iloc[seq_len + timestep_pred:].values

print("training dataset shapes: train_data: %s and train_labels: %s" % (train_data.shape, train_labels.shape)) print("testing dataset shapes: test_data: %s and test_labels: %s" % (test_data.shape, test_labels.shape))

train_y_ts = torch.from_numpy(train_labels).float().to(device) train_X_ts = torch.from_numpy(train_data).float().to(device)

test_y_ts = torch.from_numpy(test_labels).float().to(device) test_X_ts = torch.from_numpy(test_data).float().to(device)

train_set = Data.TensorDataset(train_X_ts, train_y_ts) test_set = Data.TensorDataset(test_X_ts, test_y_ts)

num_clients = 10 num_selected = 10 num_rounds = 29 epochs = 1 batch_size = 64

traindata_split = torch.utils.data.random_split(train_set, [int(train_labels.shape[0] / num_clients)] * (num_clients - 1) + [ train_labels.shape[0] - int(train_labels.shape[0] / num_clients) * ( num_clients - 1)])

train_loader = [torch.utils.data.DataLoader(x, batch_size=batch_size, shuffle=True) for x in traindata_split] test_loader = torch.utils.data.DataLoader(test_set, batch_size=batch_size, shuffle=True)

Define the LSTM model

class LSTM(nn.Module): def init(self, input_dim, hidden_dim, seq_len, num_layers=2): super(LSTM, self).init() self.input_dim = input_dim self.hidden_dim = hidden_dim self.seq_len = seq_len self.num_layers = num_layers

    self.lstm = nn.LSTM(input_dim, hidden_dim, num_layers, batch_first=True)
    self.fc = nn.Linear(hidden_dim * seq_len, 1)

def forward(self, x):
    h0 = torch.zeros(self.num_layers, x.size(0), self.hidden_dim).to(device)
    c0 = torch.zeros(self.num_layers, x.size(0), self.hidden_dim).to(device)

    out, (hn, cn) = self.lstm(x, (h0, c0))
    out = out.reshape(out.size(0), -1)
    out = self.fc(out)

    return out

define particle

class Particle: def init(self, model): # self.position = model.get_params().detach().clone() self.position = [param.data.detach().clone() for param in model.parameters()] self.velocity = [torch.zeros_like(param) for param in self.position] self.best_position = [param.data.detach().clone() for param in self.position] self.best_loss = float('inf')

define PSO algorithm

class PSO: def init(self, model, criterion, lr=0.01, momentum=0.8, weight_decay=0.1): self.model = model self.criterion = criterion self.lr = lr self.momentum = momentum self.weight_decay = weight_decay self.particles = [Particle(model) for _ in range(num_selected)]

def step(self):
    for i in range(num_selected):
        # Update velocity
        for j, param in enumerate(self.particles[i].position):
            self.particles[i].velocity[j] = self.momentum * self.particles[i].velocity[j] \
                                            + 2 * torch.rand_like(param) * (
                                                        self.particles[i].best_position[j] - param) \
                                            + 2 * torch.rand_like(param) * (global_best_position[j] - param)

            # Clamp velocity
            self.particles[i].velocity[j].clamp_(-1, 1)

            # Update position
            self.particles[i].position[j] += self.lr * self.particles[i].velocity[j]

            # Clamp position
            self.particles[i].position[j].clamp_(-1, 1)

        # Evaluate fitness of new position
        for j, param in enumerate(self.particles[i].position):
            self.model.state_dict()[f'fc.weight'] = self.particles[i].position[0]
            self.model.state_dict()[f'fc.bias'] = self.particles[i].position[1]
            self.model.state_dict()[f'lstm.weight_ih_l{j}'] = self.particles[i].position[2 * j + 2]
            self.model.state_dict()[f'lstm.weight_hh_l{j}'] = self.particles[i].position[2 * j + 3]
            self.model.state_dict()[f'lstm.bias_ih_l{j}'] = self.particles[i].position[4 * j + 4]
            self.model.state_dict()[f'lstm.bias_hh_l{j}'] = self.particles[i].position[4 * j + 5]

        loss = self.evaluate_fitness()

        # Update personal best
        if loss < self.particles[i].best_loss:
            self.particles[i].best_position = [param.data.detach().clone() for param in self.particles[i].position]
            self.particles[i].best_loss = loss

def evaluate_fitness(self):
    total_loss = 0.0
    with torch.no_grad():
        for data, target in test_loader:
            output = self.model(data)
            loss = self.criterion(output, target)
            total_loss += loss.item() * len(data)

    return total_loss / len(test_set)

def get_best(self):
    best_particle = min(self.particles, key=lambda x: x.best_loss)
    return best_particle.best_position, best_particle.best_loss

Train the model using PSO

input_dim = train_data.shape[2] hidden_dim = 128 model = LSTM(input_dim, hidden_dim, seq_len).to(device) criterion = nn.MSELoss() optimizer_pso = PSO(model=model, criterion=criterion)

global_best_loss = float('inf') global_best_position = None

for r in range(num_rounds): selected_particles = random.sample(optimizer_pso.particles, num_selected)

for i in range(num_selected):
    # optimizer = optim.Adam(selected_particles[i].position, lr=0.01, weight_decay=0.1)
    optimizer = optim.Adam(model.parameters(), lr=0.01, weight_decay=0.1)
    # model.set_params(selected_particles[i].position)
    model_param = iter(model.parameters())
    for param in model_param:
        with torch.no_grad():
            for param, particle_param in zip(model.parameters(), selected_particles[i].position):
                param.copy_(particle_param)
        # param.data.copy_(selected_particles[i].position)

    for epoch in range(epochs):
        for data, target in tqdm(train_loader[i], desc="Training round %d/%d client %d/%d" % (r + 1, num_rounds, i + 1, num_clients)):
            optimizer.zero_grad()
            output = model(data)
            loss = criterion(output, target)
            loss.backward()
            # Update personal best
            for j, param in enumerate(selected_particles[i].position):
                if j == 0:
                    new_param = model.state_dict()[f'fc.weight'].view(hidden_dim * seq_len, 1)
                    param.data.copy_(new_param.view(-1))
                elif j == 1:
                    param.data.copy_(model.state_dict()[f'fc.bias'])
                elif j % 2 == 0 and j != 0:
                    param.data.copy_(model.state_dict()[f'lstm.weight_ih_l{j // 2}'])
                elif j % 2 == 1 and j != 1:
                    param.data.copy_(model.state_dict()[f'lstm.weight_hh_l{j // 2}'])
                elif j % 4 == 2:
                    param.data.copy_(model.state_dict()[f'lstm.bias_ih_l{j // 4}'])
                elif j % 4 == 3:
                    param.data.copy_(model.state_dict()[f'lstm.bias_hh_l{j // 4}'])

            selected_particles[i].best_position = [param.data.detach().clone() for param in
                                                   selected_particles[i].position]
            selected_particles[i].best_loss = optimizer_pso.evaluate_fitness()

            # Update global best
            if selected_particles[i].best_loss < global_best_loss:
                global_best_loss = selected_particles[i].best_loss
                global_best_position = selected_particles[i].best_position.detach().clone()

        # Update particle swarm
        optimizer_pso.step()

        # Print progress
        print("Round %d/%d, Global best loss: %.4f" % (r + 1, num_rounds, global_best_loss))
