Federated Learning with Particle Swarm Optimization for Electric Power Consumption Forecasting

import os
import random
import numpy as np
import pandas as pd

import torch
import torch.nn as nn
import torch.nn.functional as F
import torch.optim as optim
import torch.utils.data as Data

from sklearn.model_selection import train_test_split
from tqdm import tqdm

device = torch.device("cuda" if torch.cuda.is_available() else "cpu")

# Load dataset from a CSV file
df = pd.read_csv('Electric_Power_Consumption.csv', delimiter=';',
                 parse_dates={'dt' : ['Date', 'Time']}, infer_datetime_format=True,
                 na_values=['nan','?'], index_col='dt')

# Fill missing values with the last known value
df.fillna(method='ffill', inplace=True)

# Resample to hourly data
df = df.resample('H').mean()

# Normalize the data
df = (df - df.mean()) / df.std()

# Split into training and testing datasets
train_df, test_df = train_test_split(df, test_size=0.2, shuffle=False)

# Convert data into sequences of length seq_len+timestep_pred
seq_len = 24*7 # one week
timestep_pred = 24 # predict the next 24 hours
train_data = []
for i in range(seq_len, len(train_df) - timestep_pred):
    train_data.append(train_df.iloc[i-seq_len:i].values.tolist())

train_data = np.array(train_data)
train_labels = train_df.iloc[seq_len+timestep_pred:].values

test_data = []
for i in range(seq_len, len(test_df) - timestep_pred):
    test_data.append(test_df.iloc[i-seq_len:i].values.tolist())

test_data = np.array(test_data)
test_labels = test_df.iloc[seq_len+timestep_pred:].values

print("training dataset shapes: train_data: %s and train_labels: %s" % (train_data.shape, train_labels.shape))
print("testing dataset shapes: test_data: %s and test_labels: %s" % (test_data.shape, test_labels.shape))

train_y_ts = torch.from_numpy(train_labels).float().to(device)
train_X_ts = torch.from_numpy(train_data).float().to(device)

test_y_ts = torch.from_numpy(test_labels).float().to(device)
test_X_ts = torch.from_numpy(test_data).float().to(device)

train_set = Data.TensorDataset(train_X_ts, train_y_ts)
test_set = Data.TensorDataset(test_X_ts, test_y_ts)

num_clients = 10
num_selected = 10
num_rounds = 29
epochs = 1
batch_size = 64

traindata_split = torch.utils.data.random_split(train_set, [int(train_labels.shape[0] / num_clients)] * (num_clients - 1) + [train_labels.shape[0] - int(train_labels.shape[0] / num_clients) * (num_clients - 1)])

train_loader = [torch.utils.data.DataLoader(x, batch_size=batch_size, shuffle=True) for x in traindata_split]
test_loader = torch.utils.data.DataLoader(test_set, batch_size=batch_size, shuffle=True)


# Define the LSTM model
class LSTM(nn.Module):
    def __init__(self, input_dim, hidden_dim, seq_len, num_layers=2):
        super(LSTM, self).__init__()
        self.input_dim = input_dim
        self.hidden_dim = hidden_dim
        self.seq_len = seq_len
        self.num_layers = num_layers

        self.lstm = nn.LSTM(input_dim, hidden_dim, num_layers, batch_first=True)
        self.fc = nn.Linear(hidden_dim*seq_len, 1)

    def forward(self, x):
        h0 = torch.zeros(self.num_layers, x.size(0), self.hidden_dim).to(device)
        c0 = torch.zeros(self.num_layers, x.size(0), self.hidden_dim).to(device)

        out, (hn, cn) = self.lstm(x, (h0,c0))
        out = out.reshape(out.size(0), -1)
        out = self.fc(out)

        return out

# define particle
class Particle:
    def __init__(self, model):
        # self.position = model.get_params().detach().clone()
        self.position = model.parameters().__next__().data.detach().clone()
        self.velocity = torch.zeros_like(self.position)
        self.best_position = self.position.detach().clone()
        self.best_loss = float('inf')

# define PSO algorithm
class PSO:
    def __init__(self, model, criterion, lr=0.01, momentum=0.8, weight_decay=0.1):
        self.model = model
        self.criterion = criterion
        self.lr = lr
        self.momentum = momentum
        self.weight_decay = weight_decay
        self.particles = [Particle(model) for _ in range(num_selected)]

    def step(self):
        for i in range(num_selected):
            # Update velocity
            self.particles[i].velocity = self.momentum * self.particles[i].velocity \
                                         + 2 * torch.rand_like(self.particles[i].position) * (
                                                     self.particles[i].best_position - self.particles[i].position) \
                                         + 2 * torch.rand_like(self.particles[i].position) * (
                                                     global_best_position - self.particles[i].position)

            # Clamp velocity
            self.particles[i].velocity.clamp_(-1, 1)

            # Update position
            self.particles[i].position += self.lr * self.particles[i].velocity

            # Clamp position
            self.particles[i].position.clamp_(-1, 1)

            # Evaluate fitness of new position
            self.model.set_params(self.particles[i].position)
            # loss = self.evaluate_fitness()
            # model_param = iter(self.model.parameters())
            # for param in model_param:
            #     param.data.copy_(selected_particles[i].position)
            loss = self.evaluate_fitness()

            # Update personal best
            if loss < self.particles[i].best_loss:
                self.particles[i].best_position = self.particles[i].position.detach().clone()
                self.particles[i].best_loss = loss

    def evaluate_fitness(self):
        total_loss = 0.0
        with torch.no_grad():
            for data, target in test_loader:
                output = self.model(data)
                loss = self.criterion(output, target)
                total_loss += loss.item() * len(data)

        return total_loss / len(test_set)

    def get_best(self):
        best_particle = min(self.particles, key=lambda x: x.best_loss)
        return best_particle.best_position, best_particle.best_loss

# Train the model using PSO
input_dim = train_data.shape[2]
hidden_dim = 128
model = LSTM(input_dim, hidden_dim, seq_len).to(device)
criterion = nn.MSELoss()
optimizer_pso = PSO(model=model, criterion=criterion)

global_best_loss = float('inf')
global_best_position = None

for r in range(num_rounds):
    selected_particles = random.sample(optimizer_pso.particles, num_selected)

    for i in range(num_selected):
        # optimizer = optim.Adam(selected_particles[i].position, lr=0.01, weight_decay=0.1)
        optimizer = optim.Adam(model.parameters(), lr=0.01, weight_decay=0.1)
        # model.set_params(selected_particles[i].position)
        model_param = iter(model.parameters())
        for param in model_param:
            with torch.no_grad():
                for param, particle_param in zip(model.parameters(), selected_particles[i].position):
                    param.copy_(particle_param)
            # param.data.copy_(selected_particles[i].position)

        for epoch in range(epochs):
            for data, target in tqdm(train_loader[i],desc="Training round %d/%d client %d/%d" % (r + 1, num_rounds, i + 1, num_clients)):
                optimizer.zero_grad()
                output = model(data)
                loss = criterion(output, target)
                loss.backward()
                # Update personal best
                selected_particles[i].best_position = selected_particles[i].position.detach().clone()
                selected_particles[i].best_loss = optimizer_pso.evaluate_fitness()

                # Update global best
                if selected_particles[i].best_loss < global_best_loss:
                    global_best_loss = selected_particles[i].best_loss
                    global_best_position = selected_particles[i].best_position.detach().clone()

                optimizer.step()
                # Update personal best
                selected_particles[i].best_position = selected_particles[i].position.detach().clone()
                selected_particles[i].best_loss = optimizer_pso.evaluate_fitness()

                # Update global best
                if selected_particles[i].best_loss < global_best_loss:
                    global_best_loss = selected_particles[i].best_loss
                    global_best_position = selected_particles[i].best_position.detach().clone()

            # Update particle swarm
            optimizer_pso.step()

            # Print progress
            print("Round %d/%d, Global best loss: %.4f" % (r + 1, num_rounds, global_best_loss))
