ECG-17 数据集上的二值化神经网络训练

import itertools
import torch
import torch.nn as nn
import torch.optim as optim
import os
import scipy.io as scio
from matplotlib import pyplot as plt
from prettytable import PrettyTable

# from My_Basic_Net.utils.OP import WeightOperation
from My_Basic_Net.utils.OP import Bn_bin_conv_pool
from sklearn.model_selection import train_test_split
from torch.utils.data import Dataset, DataLoader
import numpy as np
import random

device = torch.device('cuda:0' if torch.cuda.is_available() else 'cpu')
classes_num = 17
batch_size = 64
lr = 0.002


########################################读数据##############################################
# 读取出来的data是字典格式
dataset_path = '../ECG_Dataset/ECG-17'
classes = ['NSR', 'APB', 'AFL', 'AFIB', 'SVTA', 'WPW', 'PVC', 'Bigeminy',
                   'Trigeminy', 'VT', 'IVR', 'VFL', 'Fusion', 'LBBBB', 'RBBBB', 'SDHB', 'PR']
len_classes = len(classes)
X = list()
y = list()

for root, dirs, files in os.walk(dataset_path, topdown=False):
            for name in files:
                data_train = scio.loadmat(
                    os.path.join(root, name))  # 取出字典里的value

                # arr -> list
                data_arr = data_train.get('val')
                data_list = data_arr.tolist()
                # append() 方法用于在列表的末尾追加元素，该方法的语法格式如下：
                # listname.append(obj)

                X.append(data_list[0])  # [[……]] -> [ ]
                y.append(int(os.path.basename(root)[0:2]) - 1)# 标签0和1位，name -> num

X = torch.tensor(X, dtype=torch.float32)
y = torch.tensor(y, dtype=torch.long)

X_mean = torch.mean(X, dim=1, keepdim=True)
X_std = torch.std(X, dim=1, keepdim=True)
X = (X - X_mean) / X_std                ##数据归一化，减均值除以方差

X = X.reshape((1000, 1, 3600)).to(device) # [1,3600]
y = y.reshape((1000)).to(device)
X_train, X_test, y_train, y_test = train_test_split(X, y, test_size=0.2)

########################################训练集##############################################
class TrainDatasets(Dataset):
    def __init__(self, x_train, y_train):
        self.len = x_train.size(0) # 取第0元素：长度
        self.x_train = x_train
        self.y_train = y_train

    def __getitem__(self, index):
        return self.x_train[index], self.y_train[index] # 返回对应样本即可

    def __len__(self):
        return self.len

class TestDatasets(Dataset):
    def __init__(self, x_test, y_test):
        self.len = x_test.size(0)
        self.x_test = x_test
        self.y_test = y_test

    def __getitem__(self, index):
        return self.x_test[index], self.y_test[index]

    def __len__(self):
        return self.len

########################################封装dataloader######################################
train_dataset = TrainDatasets(X_train, y_train)
test_dataset = TestDatasets(X_test, y_test)
train_loader = DataLoader(dataset=train_dataset, batch_size=batch_size, shuffle=True)
test_loader = DataLoader(dataset=test_dataset, batch_size=batch_size, shuffle=False)

########################################定义网络##############################################
class ECG_Bin(nn.Module):
    def __init__(self, device):
        super(ECG_Bin, self).__init__()
        self.name = 'Bin_ECG'
        self.device = device
        self.classifier = nn.Sequential(
# input_channels, output_channels, kernel_size, stride, padding, pad_value, pool_size, pool_stride
            Bn_bin_conv_pool( 1, 8, 9, 3, 7, 1,
                              5, 2),
            Bn_bin_conv_pool( 8, 16, 9, 1, 7, 1,
                              5, 2),
            Bn_bin_conv_pool( 16, 32, 9, 1, 7, 1,
                              5, 2),
            Bn_bin_conv_pool( 32, 32, 9, 1, 7, 1,
                              5, 2),
            Bn_bin_conv_pool( 32, classes_num, 9, 1, 7, 1,
                              5, 2)
        )
        self.dropout = nn.Dropout(p=0.5) # 防止过拟合

    def forward(self, batch_data):
        batch_data = batch_data.clone().detach().requires_grad_(True).to(self.device)
        batch_data = self.classifier(batch_data)

        batch_data = self.dropout(batch_data)
        batch_data = batch_data.mean(dim=2) # 去掉一个维度

        return batch_data

model = ECG_Bin(device=device).to(device)
#####################################损失函数：交叉熵#########################################
loss_fn = nn.CrossEntropyLoss().to(device)

########################################优化器##############################################
optimizer = optim.Adam(model.parameters(), lr=lr)
print(device)

####################################模型参数汇总#######################################
from torchinfo import summary

summary(model=model,
        input_size=(batch_size, 1, 3600),  # make sure this is "input_size", not "input_shape"
        col_names=["input_size", "output_size", "num_params", "trainable"],
        col_width=20,
        row_settings=["var_names"])



# weightOperation = WeightOperation(model)

epochs = 1000
seed = 110
torch.manual_seed(seed)
torch.cuda.manual_seed_all(seed)
np.random.seed(seed)
random.seed(seed)
results = {"train_loss": [],
               "train_acc": [],
               "test_loss": [],
               "test_acc": []
               }
best_test_acc = 0.0
best_train_acc = 0.0
best_test_epoch = 0
best_train_epoch = 0

# Make sure model on target device
model.to(device)

#################################学习率梯度衰减#################################
# 1. 带预热的余弦退火
lr_scheduler=torch.optim.lr_scheduler.CosineAnnealingWarmRestarts(optimizer,epochs,1,0.02)
# 2. 余弦退火：T_max指一次学习率周期的迭代次数，即T_max个epoch后重置学习率。eta_min指最小学习率，即一个周期后学习率最小会下降到的值
lr_scheduler = torch.optim.lr_scheduler.CosineAnnealingLR(optimizer, T_max=epochs, eta_min=0.05,last_epoch=-1)
# 3. 指数衰减
# torch.optim.lr_scheduler.ExponentialLR(optimizer, 0.0002*1000, last_epoch=-1)



train_losses = []
train_acces = []
eval_losses = []
eval_acces = []

for epoch in range(epochs):
    ##################################开始训练########################################
    train_acc = 0
    train_loss= 0
    model.train() # 将模型改为训练模式
    correct, total = 0, 0
    for X, y in train_loader:
        X, y = X.to(device), y.to(device)
        # 前向传播，得到损失
        y_pred = model(X)
        loss = loss_fn(y_pred, y)
        # 反向传播，将上一次的梯度清0，反向传播，并且step更新相应的参数
        optimizer.zero_grad()
        loss.backward()
        optimizer.step()
        # 记录误差
        train_loss += loss.item()
        # 计算分类的准确率
        _, predicted = torch.max(y_pred.data, dim=1) # 取出预测的最大值
        correct += (predicted == y).sum().cpu().item() # 判断预测是否正确
        total += len(y)

    train_loss = train_loss / len(train_loader)
    train_acc = correct/total
    train_losses.append(train_loss / len(train_loader))
    train_acces.append(correct / total)

    ##########################每进行一次迭代，就去测试一次##################################
    model.eval()
    test_loss, test_acc = 0, 0
    correct, total = 0, 0

    with torch.inference_mode():
        for (X, y) in test_loader:

            X, y = X.to(device), y.to(device)
            test_pred_logits = model(X)

            loss = loss_fn(test_pred_logits, y)

            test_loss += loss.item()

            _, predicted = torch.max(test_pred_logits.data, dim=1) # 输出概率最大的标签
            total += len(y)
            correct += (predicted == y).sum().cpu().item() # 判断是否预测准确

    test_loss = test_loss / len(test_loader)
    test_acc = correct/total
    eval_losses.append(test_loss / len(train_loader))
    eval_acces.append(correct / total)

    # 更新学习率
    lr_scheduler.step()

    if test_acc > best_test_acc:
            best_test_acc = test_acc
            best_test_epoch = epoch + 1
            acc_str = "{:.2f}".format(best_test_acc * 100) + '%'

    if train_acc > best_train_acc:
            best_train_acc = train_acc
            best_train_epoch = epoch + 1
            acc_str = "{:.2f}".format(best_test_acc * 100) + '%'

    print(
        f"Epoch: {epoch + 1} | "
        f"train_loss: {train_loss:.4f} | "
        f"train_acc: {train_acc:.4f} | "
        f"test_loss: {test_loss:.4f} | "
        f"test_acc: {test_acc:.4f} | "
        f"lr: {lr_scheduler.get_last_lr()[0]:.6f}"
    )


    results["train_loss"].append(train_loss)
    results["train_acc"].append(train_acc)
    results["test_loss"].append(test_loss)
    results["test_acc"].append(test_acc)

##################################
# weightOperation.WeightBinarize()
# print(model.state_dict())
print('best_test_acc: ', "{:.2f}".format(best_test_acc * 100) + '%', '	 epoch: ', best_test_epoch)
print('best_train_acc: ', "{:.2f}".format(best_train_acc * 100) + '%', '	 epoch: ', best_train_epoch)
print("-" * 50 + "\n")

plt.plot(np.arange(len(train_losses)), train_losses,label = "train loss")
plt.plot(np.arange(len(train_acces)), train_acces,label = "train acc")
plt.plot(np.arange(len(eval_losses)), eval_losses,label = "test loss")
plt.plot(np.arange(len(eval_acces)), eval_acces,label = "test acc")
plt.legend()
plt.xlabel('epoches')
plt.title('Model loss & accuracy')
plt.show()
