电池SOC估计：基于EKF和安时积分法的比较

% EKF + 安时积分法

T=1;%采样时间为1s N=20042/T;%总步长 x=zeros(3,N);%定义状态向量x,定义一个3行N列的零矩阵。 x(:,1)=[0;0;0.8];%状态向量x初值设定 global P; %global 声明全局变量 P=eye(3);%定义协方差 EKF,生成一个3行3列的单位矩阵 Q=0.1;R=0.1; global Q_1;

%% %ii(1,:)=I;uu(1,:)=Ub;soc(1,:)=SOC;%输入参数 i = xlsread('i.xlsx'); %读取电流数据 u = xlsread('v.xlsx'); %读取电压数据 soc1 = xlsread('soc.xlsx'); %读取soc数据 ii = i'; %将电流数据变成行向量 uu = u'; %将电压数据变成行向量 soc = soc1'; %将soc数据变成行向量 I = ii(1,:);Ub = uu(1,:);SOC = soc(1,:); %访问数组第一行的所有元素？？？ Cn=24;%电池容量 %% %通过数据拟合方法，基于Matlab的曲线拟合工具箱cftool结合hppc辨识出来的参数。 for i=2:N R1=0.03023x(3,i-1)^6-0.1141x(3,i-1)^5+0.1689x(3,i-1)^4-0.1243x(3,i-1)^3+0.04728x(3,i-1)^2-0.008527x(3,i-1)+0.0006967; R2=0.003971x(3,i-1)^6-0.005341x(3,i-1)^5-0.006872x(3,i-1)^4+0.01435x(3,i-1)^3-0.007282x(3,i-1)^2+0.001231x(3,i-1)+0.0002082; C1=510100x(3,i-1)^6-1276000x(3,i-1)^5+1031000x(3,i-1)^3-176300x(3,i-1)^2+69310x(3,i-1)+909; C2=-12940000x(3,i-1)^6+39640000x(3,i-1)^5-45050000x(3,i-1)^4+23320000x(3,i-1)^3-5467000x(3,i-1)^2+523200x(3,i-1)+52340; A=[1-(1/(R1C1)) 0 0;0 1-(1/(R2C2)) 0;0 0 1];%系数矩阵A 3行3列 B=[1/C1 1/C2 1/(3600Cn)]';%系数矩阵B 3行1列 H=(66.48+54.18ii(1,i-1))x(3,i-1)^5-(127.9+196.8ii(1,i-1))x(3,i-1)^4+(70.16+262.88ii(1,i-1))x(3,i-1)^3-(3.48-163.38ii(1,i-1))x(3,i-1)^2.... -(4.58-48.42ii(1,i-1))x(3,i-1)-5.77ii(1,i-1)+1.26; %求一阶泰勒近似 C=[1,1,H];%系数矩阵C 1行3列 if ii(1,:)>=0 %R0区分充放电来拟合，也是关于SOC的函数 R0=(-0.1313x(3,i-1)^3+0.4812x(3,i-1)^2-0.5452x(3,i-1)+2.96)/1000;%充电时欧姆内阻三阶拟合,除1000表示毫Ω化Ω else R0=(9.033x(3,i-1)^6-39.36x(3,i-1)^5+65.72x(3,i-1)^4-54.46x(3,i-1)^3+24.21x(3,i-1)^2 -5.774x(3,i-1)+2.58)/1000;%放电时欧姆内阻6阶拟合 除1000表示毫Ω化Ω end Ppre=APA'+eye(3)Q;%协方差预测更新 3行3列
xpre(:,i-1)=Ax(:,i-1)+Bii(1,i-1);%状态x的预测更新 3行1列 第一行为U1,；第二行为U2；第三行为SOC Usoc=11.08xpre(3,i-1)^6-25.58xpre(3,i-1)^5+17.54xpre(3,i-1)^4-1.159xpre(3,i-1)^3-2.386xpre(3,i-1)^2.... +1.263xpre(3,i-1)+3.422;%开路电压Usoc是关于SOC的函数 K(:,i-1)=PpreC'inv(CPpre*C'+R);%卡尔曼增益更新 Um(1,i-1)=Usoc+xpre(1,i-1)+xpre(2,i-1)+ii(1,i-1)*R0;%预测的电池端电压 e(1,i-1)=uu(1,i-1)-Um(1,i-1);%新息 x(:,i)=xpre(:,i-1)+K(:,i-1)*e(1,i-1);%状态的后验估计 / 状态估计测量更新 P=(eye(3)-K(:,i-1)*C)*Ppre;%协方差更新

end

% 安时积分法 Q_1 = 0; for j = 2:N Q_1 = Q_1 + ((I(j-1)+I(j))/2)*(T/3600); x(3,j) = Q_1/Cn; end

figure hold on;box on; plot(x(3,:),'r','Linewidth',5); plot(soc(1,:),'b','Linewidth',5); xlabel('time s'); ylabel('SOC'); legend('EKF + 安时积分法', '真实SOC');

figure hold on;box on; plot(soc(1,:)-x(3,:),'c','Linewidth',3); xlabel('time s'); ylabel('soc误差'); legend('EKF + 安时积分法误差');
