MindSpore ResNet模型训练代码解析和错误解决

该错误提示缺少必需的参数'out_channels'，是因为在ResidualBlock类的初始化函数中没有传递该参数。可以检查代码中创建ResidualBlock对象时是否传递了正确的参数。例如：

layers.append(block(self.in_channels, out_channels, out_channels, stride, downsample))

另外，还需要检查ResNet类的构造函数中传递给make_layer函数的参数是否正确。例如：

self.layer1 = self.make_layer(block, 64, layers[0], stride=1)

通过检查并传递正确的参数，可以解决该错误。

代码解析

本代码使用MindSpore框架训练ResNet模型，主要包括以下几个部分：

1. 数据加载: 使用TrainDatasetGenerator类加载训练和验证数据，并进行数据预处理。
2. 模型定义: 使用ResidualBlock和ResNet类定义ResNet模型。
3. 模型训练: 使用Model类训练ResNet模型，并使用LossMonitor, TimeMonitor, ModelCheckpoint等回调函数记录训练过程信息。
4. 模型评估: 使用Model类的eval方法评估模型在验证集上的性能。

代码示例

import numpy as np
import mindspore.dataset as ds
import cv2
import mindspore.nn as nn
import os
from mindspore import context, ops
from mindspore.train.callback import ModelCheckpoint, CheckpointConfig, LossMonitor, TimeMonitor
from mindspore.train import Model
from mindspore.nn.metrics import Accuracy
np.random.seed(58)


class ResidualBlock(nn.Cell):
    expansion = 1
    def __init__(self, in_channels, out_channels, stride=1, downsample=None):
        super(ResidualBlock, self).__init__()
        self.conv1 = nn.Conv2d(in_channels, out_channels, kernel_size=3, stride=stride,   pad_mode='same')
        self.bn1 = nn.BatchNorm2d(out_channels)
        self.relu = nn.ReLU()
        self.conv2 = nn.Conv2d(out_channels, out_channels, kernel_size=3, stride=1,   pad_mode='same')
        self.bn2 = nn.BatchNorm2d(out_channels)
        self.downsample = downsample
        self.stride = stride

    def construct(self, x):
        identity = x

        out = self.conv1(x)
        out = self.bn1(out)
        out = self.relu(out)

        out = self.conv2(out)
        out = self.bn2(out)

        if self.downsample is not None:
            identity = self.downsample(x)
        out += identity
        out = self.relu(out)

        return out

class ResNet(nn.Cell):
    def __init__(self, block, layers, num_classes=34):
        super(ResNet, self).__init__()
        self.in_channels = 64

        self.conv1 = nn.Conv2d(1, 64, kernel_size=7, stride=2,   pad_mode='valid')
        self.bn1 = nn.BatchNorm2d(64)
        self.relu = nn.ReLU()
        self.maxpool = nn.MaxPool2d(kernel_size=3, stride=2,   pad_mode='valid')

        self.layer1 = self.make_layer(block, 64, layers[0])
        self.layer2 = self.make_layer(block, 128, layers[1], stride=2)
        self.layer3 = self.make_layer(block, 256, layers[2], stride=2)
        self.layer4 = self.make_layer(block, 512, layers[3], stride=2)

        self.avgpool = nn.AvgPool2d(kernel_size=3, stride=1,   pad_mode='valid')
        self.fc = nn.Dense(512 * block.expansion, num_classes)

    def make_layer(self, block, out_channels, blocks, stride=1):
        downsample = None
        if (stride != 1) or (self.in_channels != out_channels * block.expansion):
            downsample = nn.SequentialCell([
                nn.Conv2d(self.in_channels, out_channels * block.expansion, kernel_size=1, stride=stride),
                nn.BatchNorm2d(out_channels * block.expansion)
            ])
        layers = []
        layers.append(block(self.in_channels, out_channels, out_channels, stride, downsample))
        self.in_channels = out_channels * block.expansion
        for _ in range(1, blocks):
            layers.append(block(self.in_channels, out_channels))
        return nn.SequentialCell(layers)

    def construct(self, x):
        x = self.conv1(x)
        x = self.bn1(x)
        x = self.relu(x)
        x = self.maxpool(x)

        x = self.layer1(x)
        x = self.layer2(x)
        x = self.layer3(x)
        x = self.layer4(x)

        x = self.avgpool(x)
        x = ops.Reshape()(x, (ops.Shape()(x)[0], -1))
        x = self.fc(x)

        return x


class TrainDatasetGenerator:
    def __init__(self, file_path):
        self.file_path = file_path
        self.img_names = os.listdir(file_path)

    def __getitem__(self, index=0):
        data = cv2.imread(os.path.join(self.file_path, self.img_names[index]))
        label = int(self.img_names[index].split('-')[0])
        data = cv2.cvtColor(data,cv2.COLOR_BGR2RGB)
        data = cv2.resize(data,(224,224))
        # label = np.array([label])
        data = data.transpose().astype(np.float32) / 255.
        # data = np.expand_dims(data, axis=0)
        # data = Tensor(data)
        # label = Tensor(label)
        return data, label
        #data = np.expand_dims(data, axis=0)
        #data = Tensor(data)
        #label = Tensor(label)
        return data, label

    def __len__(self):
        return len(self.img_names)


def train_resnet():
    context.set_context(mode=context.GRAPH_MODE, device_target='CPU')
    train_dataset_generator = TrainDatasetGenerator('D:/pythonproject2/digital_mindspore/dataset')
    ds_train = ds.GeneratorDataset(train_dataset_generator, ['data', 'label'], shuffle=True)
    ds_train = ds_train.shuffle(buffer_size=10)
    ds_train = ds_train.batch(batch_size=4, drop_remainder=True)
    valid_dataset_generator = TrainDatasetGenerator('D:/pythonproject2/test1')
    ds_valid = ds.GeneratorDataset(valid_dataset_generator, ['data', 'label'], shuffle=True)
    ds_valid = ds_valid.batch(batch_size=4, drop_remainder=True)
    network = ResNet(ResidualBlock,[2,2,2,2])
    net_loss = nn.SoftmaxCrossEntropyWithLogits(sparse=True, reduction='mean')
    net_opt = nn.Momentum(network.trainable_params(), learning_rate=0.01, momentum=0.9)
    time_cb = TimeMonitor(data_size=ds_train.get_dataset_size())
    config_ck = CheckpointConfig(save_checkpoint_steps=10,
                                 keep_checkpoint_max=10)
    config_ckpt_path = 'D:/pythonproject2/ckpt/'
    ckpoint_cb = ModelCheckpoint(prefix='checkpoint_resnet', directory=config_ckpt_path, config=config_ck)


    model = Model(network, net_loss, net_opt, metrics={'Accuracy': Accuracy()})
    epoch_size = 10
    print('============== Starting Training =============')
    model.train(epoch_size, ds_train, callbacks=[time_cb, ckpoint_cb, LossMonitor()])

    acc = model.eval(ds_valid)
    print('============== {} ============='.format(acc))
    epoch_size = 10
    print('============== Starting Training =============')
    model.train(epoch_size, ds_train, callbacks=[time_cb, ckpoint_cb, LossMonitor()])

    acc = model.eval(ds_valid)
    print('============== {} ============='.format(acc))
    epoch_size = 10
    print('============== Starting Training =============')
    model.train(epoch_size, ds_train, callbacks=[time_cb, ckpoint_cb, LossMonitor()])

    acc = model.eval(ds_valid)
    print('============== {} ============='.format(acc))

if __name__ == '__main__':
    train_resnet()

总结

本代码演示了使用MindSpore框架训练ResNet模型的过程，并提供了一些代码解析和错误解决方法。希望对您理解和使用MindSpore框架有所帮助。
