基于基因表达量预测患者患病状态的 DNN 神经网络模型

本项目使用 Python 和 PyTorch 框架构建深度神经网络模型，根据基因表达量预测患者是否患病。模型包含两个子网络，分别进行多分类和二分类，并使用贝叶斯优化方法调整模型参数，以提升预测准确率。

导入所需库

import torch
import pandas as pd
import numpy as np
from sklearn.preprocessing import StandardScaler
from torch import nn
from torch.utils.data import Dataset, DataLoader
from skopt import gp_minimize
from skopt.space import Real, Integer
from skopt.utils import use_named_args

定义数据集类

class GeneDataset(Dataset):
    def __init__(self, data, transform=None):
        self.data = data
        self.transform = transform

    def __len__(self):
        return len(self.data)

    def __getitem__(self, idx):
        x = self.data.iloc[idx, 1:].values.astype(float)  # 提取基因表达量数据
        y = self.data.iloc[idx, 0]  # 提取患者状态标志数据
        if self.transform:
            x = self.transform(x)
        return x, y

定义神经网络模型

模型 1: 多分类模型

class Model1(nn.Module):
    def __init__(self, input_size, hidden_size, output_size, dropout_rate):
        super(Model1, self).__init__()
        self.fc1 = nn.Linear(input_size, hidden_size)
        self.relu = nn.ReLU()
        self.dropout = nn.Dropout(dropout_rate)
        self.fc2 = nn.Linear(hidden_size, output_size)

    def forward(self, x):
        out = self.fc1(x)
        out = self.relu(out)
        out = self.dropout(out)
        out = self.fc2(out)
        return out

模型 2: 二分类模型

class Model2(nn.Module):
    def __init__(self, input_size, hidden_size, output_size, dropout_rate):
        super(Model2, self).__init__()
        self.fc1 = nn.Linear(input_size, hidden_size)
        self.relu = nn.ReLU()
        self.dropout = nn.Dropout(dropout_rate)
        self.fc2 = nn.Linear(hidden_size, output_size)
        self.sigmoid = nn.Sigmoid()

    def forward(self, x):
        out = self.fc1(x)
        out = self.relu(out)
        out = self.dropout(out)
        out = self.fc2(out)
        out = self.sigmoid(out)
        return out

定义数据预处理函数

def transform(x):
    scaler = StandardScaler()
    x = scaler.fit_transform(x.reshape(1, -1))
    return x.reshape(-1)

定义模型训练和测试函数

模型 1 训练和测试函数

def train_and_test_model1(model, dataloader, criterion, optimizer):
    total_loss = 0
    total_correct = 0
    total_samples = 0
    model.train()
    for i, (inputs, labels) in enumerate(dataloader):
        optimizer.zero_grad()
        outputs = model(inputs.float())
        loss = criterion(outputs, labels.long())
        loss.backward()
        optimizer.step()
        total_loss += loss.item()
        _, predicted = torch.max(outputs.data, 1)
        total_correct += (predicted == labels).sum().item()
        total_samples += labels.size(0)
    train_loss = total_loss / total_samples
    train_acc = total_correct / total_samples
    return train_loss, train_acc

模型 2 训练和测试函数

def train_and_test_model2(model, dataloader, criterion, optimizer):
    total_loss = 0
    total_correct = 0
    total_samples = 0
    model.train()
    for i, (inputs, labels) in enumerate(dataloader):
        optimizer.zero_grad()
        outputs = model(inputs.float())
        loss = criterion(outputs, labels.float())
        loss.backward()
        optimizer.step()
        total_loss += loss.item()
        predicted = torch.round(outputs.data)
        total_correct += (predicted == labels).sum().item()
        total_samples += labels.size(0)
    train_loss = total_loss / total_samples
    train_acc = total_correct / total_samples
    return train_loss, train_acc

定义模型训练函数

def train_models(model1, model2, trainloader, criterion1, criterion2, optimizer1, optimizer2):
    train_loss1, train_acc1, train_loss2, train_acc2 = 0, 0, 0, 0
    train_loss1, train_acc1 = train_and_test_model1(model1, trainloader, criterion1, optimizer1)
    train_inputs = torch.zeros(len(trainloader), 4)
    train_labels = torch.zeros(len(trainloader), 1)
    for i, (inputs, labels) in enumerate(trainloader):
        train_inputs[i] = model1(inputs.float())
        train_labels[i] = labels
    train_dataset = torch.utils.data.TensorDataset(train_inputs, train_labels)
    trainloader2 = DataLoader(train_dataset, batch_size=32, shuffle=True)
    train_loss2, train_acc2 = train_and_test_model2(model2, trainloader2, criterion2, optimizer2)
    return train_loss1, train_acc1, train_loss2, train_acc2

加载并预处理数据

filename = 'C:\Users\lenovo\Desktop\HIV\GSE6740GSE50011基因降低\output_data.xlsx'
data = pd.read_excel(filename, sheet_name='Sheet1')

data.iloc[:, 1:] = data.iloc[:, 1:].apply(lambda x: transform(x))

train_data = data

定义超参数空间

space = [Integer(10, 100, name='hidden_size'),
         Real(0.01, 0.5, name='dropout_rate'),
         Integer(10, 100, name='hidden_size2'),
         Real(0.01, 0.5, name='dropout_rate2'),
         Real(0.001, 0.01, name='lr'),
         Real(0.001, 0.01, name='lr2')]

定义模型训练函数（用于贝叶斯优化）

@use_named_args(space)
def train_model(hidden_size, dropout_rate, hidden_size2, dropout_rate2, lr, lr2):
    # 定义模型
    model1 = Model1(71, hidden_size, 4, dropout_rate)
    model2 = Model2(4, hidden_size2, 1, dropout_rate2)

    # 定义损失函数和优化器
    criterion1 = nn.CrossEntropyLoss()
    criterion2 = nn.BCELoss()
    optimizer1 = torch.optim.Adam(model1.parameters(), lr=lr)
    optimizer2 = torch.optim.Adam(model2.parameters(), lr=lr2)

    # 定义数据集和数据加载器
    train_dataset = GeneDataset(train_data, transform=transform)
    trainloader = DataLoader(train_dataset, batch_size=32, shuffle=True)

    # 训练模型
    train_loss1, train_acc1, train_loss2, train_acc2 = train_models(model1, model2, trainloader, criterion1, criterion2, optimizer1, optimizer2)

    # 输出训练结果
    print('hidden_size:', hidden_size)
    print('dropout_rate:', dropout_rate)
    print('hidden_size2:', hidden_size2)
    print('dropout_rate2:', dropout_rate2)
    print('lr:', lr)
    print('lr2:', lr2)
    print('train_loss1:', train_loss1)
    print('train_acc1:', train_acc1)
    print('train_loss2:', train_loss2)
    print('train_acc2:', train_acc2)

    # 返回损失值
    return train_loss2

进行贝叶斯优化

res_gp = gp_minimize(train_model, space, n_calls=50, random_state=0)

# 输出最优超参数
print("Best: %f" % res_gp.fun)
print("Best parameters: " + str(res_gp.x))

代码说明

1. 数据加载与预处理: 从 Excel 文件中读取数据，并将基因表达量进行标准化处理。
2. 模型定义: 定义两个神经网络模型，分别用于多分类和二分类。
3. 训练函数: 定义训练和测试模型的函数，分别用于模型 1 和模型 2 的训练和测试。
4. 模型训练函数: 定义训练两个模型的函数，将模型 1 的输出作为模型 2 的输入，进行串联训练。
5. 超参数空间定义: 定义贝叶斯优化搜索的超参数空间，包括隐藏层神经元数量、Dropout 率和学习率。
6. 贝叶斯优化: 使用 gp_minimize 函数进行贝叶斯优化，以找到最佳的超参数组合，使模型的损失值最小。
7. 输出结果: 输出最优的超参数组合以及对应的损失值。

总结

本项目构建了一个基于基因表达量预测患者患病状态的 DNN 神经网络模型，并使用贝叶斯优化方法调整模型参数，以提升预测准确率。模型包含两个子网络，分别进行多分类和二分类，能够有效地识别和预测患者的患病状态。该项目提供了一个使用深度学习方法分析基因表达量数据的案例，为相关领域的研究提供参考。
