ResNet-50 模型实现：使用 MindSpore 构建图像分类模型

ResNet-50 模型实现

本篇代码演示了如何使用 MindSpore 实现 ResNet-50 模型，包括定义 ResNet-50 的网络结构、加载预训练模型、构建数据集、训练和测试模型等步骤。

定义 ResNet-50 网络结构

import mindspore.nn as nn
import mindspore.ops as ops

class ConvBlock(nn.Cell):
    def __init__(self, in_channels, out_channels, kernel_size=3, stride=1, padding=1):
        super(ConvBlock, self).__init__()
        self.conv = nn.Conv2d(in_channels, out_channels, kernel_size, stride, padding, has_bias=False)
        self.bn = nn.BatchNorm2d(out_channels)
        self.relu = nn.ReLU()

    def construct(self, x):
        x = self.conv(x)
        x = self.bn(x)
        x = self.relu(x)
        return x

class ResBlock(nn.Cell):
    def __init__(self, in_channels, out_channels, stride=1):
        super(ResBlock, self).__init__()
        self.conv1 = ConvBlock(in_channels, out_channels, stride=stride)
        self.conv2 = ConvBlock(out_channels, out_channels, kernel_size=3, stride=1, padding=1)
        self.downsample = nn.SequentialCell([nn.Conv2d(in_channels, out_channels, kernel_size=1, stride=stride, has_bias=False), nn.BatchNorm2d(out_channels)])
        self.relu = nn.ReLU()

    def construct(self, x):
        identity = x
        x = self.conv1(x)
        x = self.conv2(x)
        if self.downsample is not None:
            identity = self.downsample(identity)
        x = x + identity
        x = self.relu(x)
        return x

class ResNet(nn.Cell):
    def __init__(self, block, layers, num_classes=1000):
        super(ResNet, self).__init__()
        self.in_channels = 64
        self.conv1 = ConvBlock(3, 64, kernel_size=7, stride=2, padding=3)
        self.maxpool = nn.MaxPool2d(kernel_size=3, stride=2, pad_mode='same')
        self.layer1 = self._make_layer(block, 64, layers[0])
        self.layer2 = self._make_layer(block, 128, layers[1], stride=2)
        self.layer3 = self._make_layer(block, 256, layers[2], stride=2)
        self.layer4 = self._make_layer(block, 512, layers[3], stride=2)
        self.avgpool = nn.AvgPool2d(7, 1)
        self.dropout = nn.Dropout(0.4)
        self.fc = nn.Dense(512 * block.expansion, num_classes)

    def _make_layer(self, block, out_channels, blocks, stride=1):
        downsample = None
        if stride != 1 or self.in_channels != out_channels * block.expansion:
            downsample = nn.SequentialCell([nn.Conv2d(self.in_channels, out_channels * block.expansion, kernel_size=1, stride=stride, has_bias=False), nn.BatchNorm2d(out_channels * block.expansion)])
        layers = []
        layers.append(block(self.in_channels, out_channels, stride, downsample))
        self.in_channels = out_channels * block.expansion
        for i in range(1, blocks):
            layers.append(block(self.in_channels, out_channels))
        return nn.SequentialCell(layers)

    def construct(self, x):
        x = self.conv1(x)
        x = self.maxpool(x)
        x = self.layer1(x)
        x = self.layer2(x)
        x = self.layer3(x)
        x = self.layer4(x)
        x = self.avgpool(x)
        x = self.dropout(x)
        x = ops.Reshape()(x, (-1, 512 * 1 * 1))
        x = self.fc(x)
        return x

def resnet50():
    return ResNet(ResBlock, [3, 4, 6, 3])

加载预训练模型

from mindspore import load_checkpoint, load_param_into_net

pretrained_model = 'resnet50.ckpt'
net = resnet50()
param_dict = load_checkpoint(pretrained_model)
load_param_into_net(net, param_dict)

构建数据集

import os
import numpy as np
from mindspore import Tensor
from PIL import Image
from mindspore.dataset import vision

def load_dataset(data_path):
    images = []
    labels = []
    for subdir in os.listdir(data_path):
        subpath = os.path.join(data_path, subdir)
        for filename in os.listdir(subpath):
            imgpath = os.path.join(subpath, filename)
            img = Image.open(imgpath)
            img = img.resize((224, 224))
            img = np.array(img).astype(np.float32)
            img = img.transpose((2, 0, 1))
            images.append(img)
            labels.append(int(subdir))
    images = np.array(images)
    labels = np.array(labels)
    return Tensor(images), Tensor(labels)

train_path = 'train/'
test_path = 'test/'
train_data = vision.ImageFolderDataset(train_path, num_parallel_workers=8, shuffle=True)
train_data = train_data.map(operations=vision.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]))
train_data = train_data.map(operations=vision.HWC2CHW())
train_data = train_data.batch(batch_size=32, drop_remainder=True)
test_data = vision.ImageFolderDataset(test_path, num_parallel_workers=8, shuffle=False)
test_data = test_data.map(operations=vision.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]))
test_data = test_data.map(operations=vision.HWC2CHW())
test_data = test_data.batch(batch_size=32, drop_remainder=True)

训练和测试模型

from mindspore import Model
from mindspore.nn.metrics import Accuracy
from mindspore.train.callback import LossMonitor

net_loss = nn.SoftmaxCrossEntropyWithLogits(sparse=True)
lr = 0.01
momentum = 0.9
net_opt = nn.Momentum(net.trainable_params(), lr, momentum)
model = Model(net, net_loss, net_opt, metrics={'accuracy': Accuracy()})

loss_cb = LossMonitor(per_print_times=train_data.get_dataset_size())
# 训练模型
model.train(3, train_data, loss_cb) # 训练3个epoch
model.eval(test_data)
