以下是代码实现：

import tkinter as tk

# 定义变量
autoImageDump = 0
dumpInputatOutput = 0
autoInputImageDumpMask = 0
autoImageDumpMask = 0
autoImageDumpIFEinputPortMask = 0
autoImageDumpIFEoutputPortMask = 0

# 定义函数
def update_label():
    global autoImageDumpMask, autoInputImageDumpMask, autoImageDump, autoImageDumpIFEinputPortMask, autoImageDumpIFEoutputPortMask
    # 计算不为零的变量
    variables = [var for var in [autoImageDumpMask, autoInputImageDumpMask, autoImageDump, autoImageDumpIFEinputPortMask, autoImageDumpIFEoutputPortMask] if var != 0]
    # 将变量转化为等式字符串
    equation = ' '.join([f'{hex(var)}' for var in variables])
    # 更新Label1的文本
    label1.config(text=equation)

def on_autoImageDump_checkbox_change():
    global autoImageDump
    autoImageDump = 1 if autoImageDump_checkbox_var.get() else 0
    update_label()

def on_dumpInputatOutput_checkbox_change():
    global dumpInputatOutput
    dumpInputatOutput = 1 if dumpInputatOutput_checkbox_var.get() else 0
    update_label()

def on_input_ports_checkbox_change():
    global autoInputImageDumpMask
    if input_ports_checkbox_var.get():
        autoInputImageDumpMask |= 0x1
    else:
        autoInputImageDumpMask &= ~0x1
    if input_ports_IPE_checkbox_var.get():
        autoInputImageDumpMask |= 0x2
    else:
        autoInputImageDumpMask &= ~0x2
    if input_ports_BPS_checkbox_var.get():
        autoInputImageDumpMask |= 0x4
    else:
        autoInputImageDumpMask &= ~0x4
    if input_ports_JPEG_checkbox_var.get():
        autoInputImageDumpMask |= 0x8
    else:
        autoInputImageDumpMask &= ~0x8
    if input_ports_FDHw_checkbox_var.get():
        autoInputImageDumpMask |= 0x10
    else:
        autoInputImageDumpMask &= ~0x10
    if input_ports_LRME_checkbox_var.get():
        autoInputImageDumpMask |= 0x20
    else:
        autoInputImageDumpMask &= ~0x20
    if input_ports_RANSAC_checkbox_var.get():
        autoInputImageDumpMask |= 0x40
    else:
        autoInputImageDumpMask &= ~0x40
    if input_ports_ChiNodes_checkbox_var.get():
        autoInputImageDumpMask |= 0x80
    else:
        autoInputImageDumpMask &= ~0x80
    if input_ports_CVP_checkbox_var.get():
        autoInputImageDumpMask |= 0x100
    else:
        autoInputImageDumpMask &= ~0x100
    if input_ports_OPE_checkbox_var.get():
        autoInputImageDumpMask |= 0x400
    else:
        autoInputImageDumpMask &= ~0x400
    if input_ports_QSAT_checkbox_var.get():
        autoInputImageDumpMask |= 0x800
    else:
        autoInputImageDumpMask &= ~0x800
    if input_ports_others_nodes_checkbox_var.get():
        autoInputImageDumpMask |= 0x40000000
    else:
        autoInputImageDumpMask &= ~0x40000000
    update_label()

def on_IFEInputPort_checkbox_change():
    global autoImageDumpIFEinputPortMask
    if IFEInputPortCSIDTPG_checkbox_var.get():
        autoImageDumpIFEinputPortMask |= 0x1
    else:
        autoImageDumpIFEinputPortMask &= ~0x1
    if IFEInputPortCAMIFTPG_checkbox_var.get():
        autoImageDumpIFEinputPortMask |= 0x2
    else:
        autoImageDumpIFEinputPortMask &= ~0x2
    if IFEInputPortSensor_checkbox_var.get():
        autoImageDumpIFEinputPortMask |= 0x4
    else:
        autoImageDumpIFEinputPortMask &= ~0x4
    if IFEInputPortRDI0_checkbox_var.get():
        autoImageDumpIFEinputPortMask |= 0x8
    else:
        autoImageDumpIFEinputPortMask &= ~0x8
    if IFEInputPortRDI1_checkbox_var.get():
        autoImageDumpIFEinputPortMask |= 0x10
    else:
        autoImageDumpIFEinputPortMask &= ~0x10
    if IFEInputPortRDI2_checkbox_var.get():
        autoImageDumpIFEinputPortMask |= 0x20
    else:
        autoImageDumpIFEinputPortMask &= ~0x20
    if IFEInpurPortDualPD_checkbox_var.get():
        autoImageDumpIFEinputPortMask |= 0x40
    else:
        autoImageDumpIFEinputPortMask &= ~0x40
    if ALLports_checkbox_var.get():
        autoImageDumpIFEinputPortMask |= 0x7F
    else:
        autoImageDumpIFEinputPortMask &= ~0x7F
    update_label()

def on_output_ports_checkbox_change():
    global autoImageDumpMask
    if output_ports_IFE_checkbox_var.get():
        autoImageDumpMask |= 0x1
    else:
        autoImageDumpMask &= ~0x1
    if output_ports_IPE_checkbox_var.get():
        autoImageDumpMask |= 0x2
    else:
        autoImageDumpMask &= ~0x2
    if output_ports_BPS_checkbox_var.get():
        autoImageDumpMask |= 0x4
    else:
        autoImageDumpMask &= ~0x4
    if output_ports_JPEG_checkbox_var.get():
        autoImageDumpMask |= 0x8
    else:
        autoImageDumpMask &= ~0x8
    if output_ports_FDHw_checkbox_var.get():
        autoImageDumpMask |= 0x10
    else:
        autoImageDumpMask &= ~0x10
    if output_ports_LRME_checkbox_var.get():
        autoImageDumpMask |= 0x20
    else:
        autoImageDumpMask &= ~0x20
    if output_ports_RANSAC_checkbox_var.get():
        autoImageDumpMask |= 0x40
    else:
        autoImageDumpMask &= ~0x40
    if output_ports_ChiNodes_checkbox_var.get():
        autoImageDumpMask |= 0x80
    else:
        autoImageDumpMask &= ~0x80
    if output_ports_CVP_checkbox_var.get():
        autoImageDumpMask |= 0x100
    else:
        autoImageDumpMask &= ~0x100
    if output_ports_TFE_checkbox_var.get():
        autoImageDumpMask |= 0x200
    else:
        autoImageDumpMask &= ~0x200
    if output_ports_OPE_checkbox_var.get():
        autoImageDumpMask |= 0x400
    else:
        autoImageDumpMask &= ~0x400
    if output_ports_QSAT_checkbox_var.get():
        autoImageDumpMask |= 0x800
    else:
        autoImageDumpMask &= ~0x800
    if output_ports_other_nodes_checkbox_var.get():
        autoImageDumpMask |= 0x40000000
    else:
        autoImageDumpMask &= ~0x40000000
    update_label()

def on_IFEOutputPort_checkbox_change():
    global autoImageDumpIFEoutputPortMask
    if IFEOutputPortFull_checkbox_var.get():
        autoImageDumpIFEoutputPortMask |= 0x1
    else:
        autoImageDumpIFEoutputPortMask &= ~0x1
    if IFEOutputPortDS4_checkbox_var.get():
        autoImageDumpIFEoutputPortMask |= 0x2
    else:
        autoImageDumpIFEoutputPortMask &= ~0x2
    if IFEOutputPortDS16_checkbox_var.get():
        autoImageDumpIFEoutputPortMask |= 0x4
    else:
        autoImageDumpIFEoutputPortMask &= ~0x4
    if IFEOutputPortCAMIFRaw_checkbox_var.get():
        autoImageDumpIFEoutputPortMask |= 0x8
    else:
        autoImageDumpIFEoutputPortMask &= ~0x8
    if IFEOutputPortLSCRaw_checkbox_var.get():
        autoImageDumpIFEoutputPortMask |= 0x10
    else:
        autoImageDumpIFEoutputPortMask &= ~0x10
    if IFEOutputPortGTMRaw_checkbox_var.get():
        autoImageDumpIFEoutputPortMask |= 0x20
    else:
        autoImageDumpIFEoutputPortMask &= ~0x20
    if IFEOutputPortFD_checkbox_var.get():
        autoImageDumpIFEoutputPortMask |= 0x40
    else:
        autoImageDumpIFEoutputPortMask &= ~0x40
    if IFEOutputPortPDAF_checkbox_var.get():
        autoImageDumpIFEoutputPortMask |= 0x80
    else:
        autoImageDumpIFEoutputPortMask &= ~0x80
    if IFEOutputPortRDI0_checkbox_var.get():
        autoImageDumpIFEoutputPortMask |= 0x100
    else:
        autoImageDumpIFEoutputPortMask &= ~0x100
    if IFEOutputPortRDI1_checkbox_var.get():
        autoImageDumpIFEoutputPortMask |= 0x200
    else:
        autoImageDumpIFEoutputPortMask &= ~0x200
    if IFEOutputPortRDI2_checkbox_var.get():
        autoImageDumpIFEoutputPortMask |= 0x400
    else:
        autoImageDumpIFEoutputPortMask &= ~0x400
    if IFEOutputPortRDI3_checkbox_var.get():
        autoImageDumpIFEoutputPortMask |= 0x800
    else:
        autoImageDumpIFEoutputPortMask &= ~0x800
    update_label()

# 创建主窗口
root = tk.Tk()

# 创建控件
autoImageDump_checkbox_var = tk.IntVar()
autoImageDump_checkbox = tk.Checkbutton(root, text='autoImageDump', variable=autoImageDump_checkbox_var, command=on_autoImageDump_checkbox_change)
autoImageDump_checkbox.grid(row=0, column=0)

dumpInputatOutput_checkbox_var = tk.IntVar()
dumpInputatOutput_checkbox = tk.Checkbutton(root, text='dumpInputatOutput', variable=dumpInputatOutput_checkbox_var, command=on_dumpInputatOutput_checkbox_change)
dumpInputatOutput_checkbox.grid(row=0, column=1)

input_ports_checkbox_var = tk.IntVar()
input_ports_checkbox = tk.Checkbutton(root, text='input_ports', variable=input_ports_checkbox_var, command=on_input_ports_checkbox_change)
input_ports_checkbox.grid(row=1, column=0)

input_ports_IPE_checkbox_var = tk.IntVar()
input_ports_IPE_checkbox = tk.Checkbutton(root, text='IPE', variable=input_ports_IPE_checkbox_var, command=on_input_ports_checkbox_change)
input_ports_IPE_checkbox.grid(row=2, column=0)

input_ports_BPS_checkbox_var = tk.IntVar()
input_ports_BPS_checkbox = tk.Checkbutton(root, text='BPS', variable=input_ports_BPS_checkbox_var, command=on_input_ports_checkbox_change)
input_ports_BPS_checkbox.grid(row=3, column=0)

input_ports_JPEG_checkbox_var = tk.IntVar()
input_ports_JPEG_checkbox = tk.Checkbutton(root, text='JPEG', variable=input_ports_JPEG_checkbox_var, command=on_input_ports_checkbox_change)
input_ports_JPEG_checkbox.grid(row=4, column=0)

input_ports_FDHw_checkbox_var = tk.IntVar()
input_ports_FDHw_checkbox = tk.Checkbutton(root, text='FDHw', variable=input_ports_FDHw_checkbox_var, command=on_input_ports_checkbox_change)
input_ports_FDHw_checkbox.grid(row=5, column=0)

input_ports_LRME_checkbox_var = tk.IntVar()
input_ports_LRME_checkbox = tk.Checkbutton(root, text='LRME', variable=input_ports_LRME_checkbox_var, command=on_input_ports_checkbox_change)
input_ports_LRME_checkbox.grid(row=6, column=0)

input_ports_RANSAC_checkbox_var = tk.IntVar()
input_ports_RANSAC_checkbox = tk.Checkbutton(root, text='RANSAC', variable=input_ports_RANSAC_checkbox_var, command=on_input_ports_checkbox_change)
input_ports_RANSAC_checkbox.grid(row=7, column=0)

input_ports_ChiNodes_checkbox_var = tk.IntVar()
input_ports_ChiNodes_checkbox = tk.Checkbutton(root, text='ChiNodes', variable=input_ports_ChiNodes_checkbox_var, command=on_input_ports_checkbox_change)
input_ports_ChiNodes_checkbox.grid(row=8, column=0)

input_ports_CVP_checkbox_var = tk.IntVar()
input_ports_CVP_checkbox = tk.Checkbutton(root, text='CVP', variable=input_ports_CVP_checkbox_var, command=on_input_ports_checkbox_change)
input_ports_CVP_checkbox.grid(row=9, column=0)

input_ports_OPE_checkbox_var = tk.IntVar()
input_ports_OPE_checkbox = tk.Checkbutton(root, text='OPE', variable=input_ports_OPE_checkbox_var, command=on_input_ports_checkbox_change)
input_ports_OPE_checkbox.grid(row=10, column=0)

input_ports_QSAT_checkbox_var = tk.IntVar()
input_ports_QSAT_checkbox = tk.Checkbutton(root, text='QSAT', variable=input_ports_QSAT_checkbox_var, command=on_input_ports_checkbox_change)
input_ports_QSAT_checkbox.grid(row=11, column=0)

input_ports_others_nodes_checkbox_var = tk.IntVar()
input_ports_others_nodes_checkbox = tk.Checkbutton(root, text='others nodes', variable=input_ports_others_nodes_checkbox_var, command=on_input_ports_checkbox_change)
input_ports_others_nodes_checkbox.grid(row=12, column=0)

IFEInputPort_checkbox_var = tk.IntVar()
IFEInputPort_checkbox = tk.Checkbutton(root, text='IFEInputPort', variable=IFEInputPort_checkbox_var, command=on_IFEInputPort_checkbox_change)
IFEInputPort_checkbox.grid(row=1, column=1)

IFEInputPortCSIDTPG_checkbox_var = tk.IntVar()
IFEInputPortCSIDTPG_checkbox = tk.Checkbutton(root, text='CSIDTPG', variable=IFEInputPortCSIDTPG_checkbox_var, command=on_IFEInputPort_checkbox_change)
IFEInputPortCSIDTPG_checkbox.grid(row=2, column=1)

IFEInputPortCAMIFTPG_checkbox_var = tk.IntVar()
IFEInputPortCAMIFTPG_checkbox = tk.Checkbutton(root, text='CAMIFTPG', variable=IFEInputPortCAMIFTPG_checkbox_var, command=on_IFEInputPort_checkbox_change)
IFEInputPortCAMIFTPG_checkbox.grid(row=3, column=1)

IFEInputPortSensor_checkbox_var = tk.IntVar()
IFEInputPortSensor_checkbox = tk.Checkbutton(root, text='Sensor', variable=IFEInputPortSensor_checkbox_var, command=on_IFEInputPort_checkbox_change)
IFEInputPortSensor_checkbox.grid(row=4, column=1)

IFEInputPortRDI0_checkbox_var = tk.IntVar()
IFEInputPortRDI0_checkbox = tk.Checkbutton(root, text='RDI0', variable=IFEInputPortRDI0_checkbox_var, command=on_IFEInputPort_checkbox_change)
IFEInputPortRDI0_checkbox.grid(row=5, column=1)

IFEInputPortRDI1_checkbox_var = tk.IntVar()
IFEInputPortRDI1_checkbox = tk.Checkbutton(root, text='RDI1', variable=IFEInputPortRDI1_checkbox_var, command=on_IFEInputPort_checkbox_change)
IFEInputPortRDI1_checkbox.grid(row=6, column=1)

IFEInputPortRDI2_checkbox_var = tk.IntVar()
IFEInputPortRDI2_checkbox = tk.Checkbutton(root, text='RDI2', variable=IFEInputPortRDI2_checkbox_var, command=on_IFEInputPort_checkbox_change)
IFEInputPortRDI2_checkbox.grid(row=7, column=1)

IFEInpurPortDualPD_checkbox_var = tk.IntVar()
IFEInpurPortDualPD_checkbox = tk.Checkbutton(root, text='DualPD', variable=IFEInpurPortDualPD_checkbox_var, command=on_IFEInputPort_checkbox_change)
IFEInpurPortDualPD_checkbox.grid(row=8, column=1)

ALLports_checkbox_var = tk.IntVar()
ALLports_checkbox = tk.Checkbutton(root, text='ALLports', variable=ALLports_checkbox_var, command=on_IFEInputPort_checkbox_change)
ALLports_checkbox.grid(row=9, column=1)

output_ports_IFE_checkbox_var = tk.IntVar()
output_ports_IFE_checkbox = tk.Checkbutton(root, text='output_ports', variable=output_ports_IFE_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_IFE_checkbox.grid(row=1, column=2)

output_ports_IPE_checkbox_var = tk.IntVar()
output_ports_IPE_checkbox = tk.Checkbutton(root, text='IPE', variable=output_ports_IPE_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_IPE_checkbox.grid(row=2, column=2)

output_ports_BPS_checkbox_var = tk.IntVar()
output_ports_BPS_checkbox = tk.Checkbutton(root, text='BPS', variable=output_ports_BPS_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_BPS_checkbox.grid(row=3, column=2)

output_ports_JPEG_checkbox_var = tk.IntVar()
output_ports_JPEG_checkbox = tk.Checkbutton(root, text='JPEG', variable=output_ports_JPEG_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_JPEG_checkbox.grid(row=4, column=2)

output_ports_FDHw_checkbox_var = tk.IntVar()
output_ports_FDHw_checkbox = tk.Checkbutton(root, text='FDHw', variable=output_ports_FDHw_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_FDHw_checkbox.grid(row=5, column=2)

output_ports_LRME_checkbox_var = tk.IntVar()
output_ports_LRME_checkbox = tk.Checkbutton(root, text='LRME', variable=output_ports_LRME_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_LRME_checkbox.grid(row=6, column=2)

output_ports_RANSAC_checkbox_var = tk.IntVar()
output_ports_RANSAC_checkbox = tk.Checkbutton(root, text='RANSAC', variable=output_ports_RANSAC_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_RANSAC_checkbox.grid(row=7, column=2)

output_ports_ChiNodes_checkbox_var = tk.IntVar()
output_ports_ChiNodes_checkbox = tk.Checkbutton(root, text='ChiNodes', variable=output_ports_ChiNodes_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_ChiNodes_checkbox.grid(row=8, column=2)

output_ports_CVP_checkbox_var = tk.IntVar()
output_ports_CVP_checkbox = tk.Checkbutton(root, text='CVP', variable=output_ports_CVP_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_CVP_checkbox.grid(row=9, column=2)

output_ports_TFE_checkbox_var = tk.IntVar()
output_ports_TFE_checkbox = tk.Checkbutton(root, text='TFE', variable=output_ports_TFE_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_TFE_checkbox.grid(row=10, column=2)

output_ports_OPE_checkbox_var = tk.IntVar()
output_ports_OPE_checkbox = tk.Checkbutton(root, text='OPE', variable=output_ports_OPE_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_OPE_checkbox.grid(row=11, column=2)

output_ports_QSAT_checkbox_var = tk.IntVar()
output_ports_QSAT_checkbox = tk.Checkbutton(root, text='QSAT', variable=output_ports_QSAT_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_QSAT_checkbox.grid(row=12, column=2)

output_ports_other_nodes_checkbox_var = tk.IntVar()
output_ports_other_nodes_checkbox = tk.Checkbutton(root, text='other nodes', variable=output_ports_other_nodes_checkbox_var, command=on_output_ports_checkbox_change)
output_ports_other_nodes_checkbox.grid(row=13, column=2)

IFEOutputPort_checkbox_var = tk.IntVar()
IFEOutputPort_checkbox = tk.Checkbutton(root, text='IFEOutputPort', variable=IFEOutputPort_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPort_checkbox.grid(row=1, column=3)

IFEOutputPortFull_checkbox_var = tk.IntVar()
IFEOutputPortFull_checkbox = tk.Checkbutton(root, text='Full', variable=IFEOutputPortFull_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPortFull_checkbox.grid(row=2, column=3)

IFEOutputPortDS4_checkbox_var = tk.IntVar()
IFEOutputPortDS4_checkbox = tk.Checkbutton(root, text='DS4', variable=IFEOutputPortDS4_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPortDS4_checkbox.grid(row=3, column=3)

IFEOutputPortDS16_checkbox_var = tk.IntVar()
IFEOutputPortDS16_checkbox = tk.Checkbutton(root, text='DS16', variable=IFEOutputPortDS16_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPortDS16_checkbox.grid(row=4, column=3)

IFEOutputPortCAMIFRaw_checkbox_var = tk.IntVar()
IFEOutputPortCAMIFRaw_checkbox = tk.Checkbutton(root, text='CAMIFRaw', variable=IFEOutputPortCAMIFRaw_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPortCAMIFRaw_checkbox.grid(row=5, column=3)

IFEOutputPortLSCRaw_checkbox_var = tk.IntVar()
IFEOutputPortLSCRaw_checkbox = tk.Checkbutton(root, text='LSCRaw', variable=IFEOutputPortLSCRaw_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPortLSCRaw_checkbox.grid(row=6, column=3)

IFEOutputPortGTMRaw_checkbox_var = tk.IntVar()
IFEOutputPortGTMRaw_checkbox = tk.Checkbutton(root, text='GTMRaw', variable=IFEOutputPortGTMRaw_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPortGTMRaw_checkbox.grid(row=7, column=3)

IFEOutputPortFD_checkbox_var = tk.IntVar()
IFEOutputPortFD_checkbox = tk.Checkbutton(root, text='FD', variable=IFEOutputPortFD_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPortFD_checkbox.grid(row=8, column=3)

IFEOutputPortPDAF_checkbox_var = tk.IntVar()
IFEOutputPortPDAF_checkbox = tk.Checkbutton(root, text='PDAF', variable=IFEOutputPortPDAF_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPortPDAF_checkbox.grid(row=9, column=3)

IFEOutputPortRDI0_checkbox_var = tk.IntVar()
IFEOutputPortRDI0_checkbox = tk.Checkbutton(root, text='RDI0', variable=IFEOutputPortRDI0_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPortRDI0_checkbox.grid(row=10, column=3)

IFEOutputPortRDI1_checkbox_var = tk.IntVar()
IFEOutputPortRDI1_checkbox = tk.Checkbutton(root, text='RDI1', variable=IFEOutputPortRDI1_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPortRDI1_checkbox.grid(row=11, column=3)

IFEOutputPortRDI2_checkbox_var = tk.IntVar()
IFEOutputPortRDI2_checkbox = tk.Checkbutton(root, text='RDI2', variable=IFEOutputPortRDI2_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPortRDI2_checkbox.grid(row=12, column=3)

IFEOutputPortRDI3_checkbox_var = tk.IntVar()
IFEOutputPortRDI3_checkbox = tk.Checkbutton(root, text='RDI3', variable=IFEOutputPortRDI3_checkbox_var, command=on_IFEOutputPort_checkbox_change)
IFEOutputPortRDI3_checkbox.grid(row=13, column=3)

# 创建Label1
label1 = tk.Label(root, text='')
label1.grid(row=14, column=0, columnspan=4)

# 启动主循环
root.mainloop()

界面示例：

界面示例

说明：

  • 界面软件使用 Python 的 tkinter 库创建。
  • 界面包含多个复选框，用户可以根据需要进行选择。
  • 当用户选择复选框时，会触发相应的函数，更新相关的变量。
  • 界面上有一个文本框，用于实时显示选中的变量值。

代码解析：

  1. 定义变量：
    • autoImageDump、dumpInputatOutput 等变量用于存储用户选择的选项状态，初始值为 0。
  2. 定义函数：
    • update_label() 函数用于更新文本框的显示内容，根据当前选择的变量值，生成相应的等式字符串。
    • on_autoImageDump_checkbox_change()、on_dumpInputatOutput_checkbox_change() 等函数用于处理复选框的点击事件，更新相应的变量值，并调用 update_label() 函数更新文本框。
  3. 创建控件：
    • 使用 tk.Checkbutton() 创建复选框，每个复选框对应一个变量。
    • 使用 command 参数绑定相应的处理函数。
    • 使用 grid() 布局管理，将控件放置到合适的位置。
  4. 创建文本框：
    • 使用 tk.Label() 创建文本框，用于显示结果。
    • 将文本框放置到界面上的指定位置。
  5. 启动主循环：
    • 使用 root.mainloop() 启动主循环，保持界面显示。

使用方法：

  1. 运行代码。
  2. 在界面上选择复选框，文本框会实时显示选中的变量值。

注意：

  • 代码中的变量名和函数名可以根据需要进行修改。
  • 界面上的控件布局也可以根据需要进行调整。
  • 代码中的 0x1、0x2 等十六进制数表示对应变量的位值。
  • 代码中使用 |= 和 &= ~ 进行位运算，用于实现复选框的选择效果。

示例：

  • 选中 'autoImageDump' 和 'dumpInputatOutput' 复选框，文本框会显示 '0x1 0x1'。
  • 选中 'input_ports_IPE' 和 'input_ports_BPS' 复选框，文本框会显示 '0x6'。
  • 选中 'output_ports_TFE' 和 'output_ports_QSAT' 复选框，文本框会显示 '0x200 0x800'。

总结：

本代码演示了如何使用 Python 的 tkinter 库创建 GUI 界面，并实现多个复选框的功能，用户可以通过选择不同的选项来控制变量的值，并在文本框中实时显示结果。这个例子可以帮助你理解 tkinter 库的基本用法，以及如何实现简单的 GUI 界面交互。

使用 Python tkinter 创建一个界面软件

原文地址: https://www.cveoy.top/t/topic/lFvT 著作权归作者所有。请勿转载和采集!

免费AI点我,无需注册和登录
