基于MindSpore的ResNet人脸识别模型训练与部署
基于MindSpore的ResNet人脸识别模型训练与部署
1. 简介
本文将介绍如何使用MindSpore深度学习框架构建ResNet模型，并将其应用于人脸识别任务。我们将详细讲解数据预处理、模型构建、训练过程以及如何加载预训练模型进行实时人脸识别。
2. 数据准备
首先，需要准备一个人脸数据集，并将图像数据进行预处理，例如：
- 图像大小调整
- 数据增强（例如随机裁剪、翻转等）
- 数据归一化
3. 模型构建
我们使用ResNet作为基础模型，并在其基础上进行修改以适应人脸识别任务。以下是一个使用MindSpore构建ResNet模型的示例代码：
import numpy as np
import mindspore.dataset as ds
import os
import cv2
import mindspore
import mindspore.nn as nn
from mindspore import Tensor, load_checkpoint, load_param_into_net
from mindspore.common.initializer import Normal
from mindspore import context
from mindspore.train.callback import ModelCheckpoint, CheckpointConfig, LossMonitor, TimeMonitor
from mindspore.ops.operations import TensorAdd
from mindspore import Model # 承载网络结构
from mindspore.nn.metrics import Accuracy # 测试模型用
np.random.seed(58)
class BasicBlock(nn.Cell):
def __init__(self, in_channels, out_channels, stride=1, downsample=None):
super(BasicBlock, self).__init__()
self.conv1 = nn.Conv2d(in_channels, out_channels, kernel_size=3, stride=stride, padding=1, pad_mode='pad',
has_bias=False)
self.bn1 = nn.BatchNorm2d(out_channels)
self.relu = nn.ReLU()
self.conv2 = nn.Conv2d(out_channels, out_channels, kernel_size=3, stride=1, padding=1, pad_mode='pad',
has_bias=False)
self.bn2 = nn.BatchNorm2d(out_channels)
self.downsample = downsample
self.add = TensorAdd()
def construct(self, x):
identity = x
out = self.conv1(x)
out = self.bn1(out)
out = self.relu(out)
out = self.conv2(out)
out = self.bn2(out)
if self.downsample is not None:
identity = self.downsample(x)
out = self.add(out, identity)
out = self.relu(out)
return out
class ResNet(nn.Cell):
def __init__(self, block, layers, num_classes=10):
super(ResNet, self).__init__()
self.in_channels = 64
self.conv1 = nn.Conv2d(3, 64, kernel_size=7, stride=2, padding=3, pad_mode='pad', has_bias=False)
self.bn1 = nn.BatchNorm2d(64)
self.relu = nn.ReLU()
self.maxpool = nn.MaxPool2d(kernel_size=3, stride=2, pad_mode='same')
self.layer1 = self.make_layer(block, 64, layers[0])
self.layer2 = self.make_layer(block, 128, layers[1], stride=2)
self.layer3 = self.make_layer(block, 256, layers[2], stride=2)
self.layer4 = self.make_layer(block, 512, layers[3], stride=2)
self.avgpool = nn.AvgPool2d(kernel_size=1, stride=1, pad_mode='valid') # 修改这里
self.flatten = nn.Flatten()
self.fc1 = nn.Dense(512 * 7 * 7, 11) # 修改全连接层输入维度
self.fc2 = nn.Dense(11, num_classes)
def make_layer(self, block, out_channels, blocks, stride=1):
downsample = None
if stride != 1 or self.in_channels != out_channels:
downsample = nn.SequentialCell([
nn.Conv2d(self.in_channels, out_channels, kernel_size=1, stride=stride, has_bias=False),
nn.BatchNorm2d(out_channels)
])
layers = []
layers.append(block(self.in_channels, out_channels, stride, downsample))
self.in_channels = out_channels
for _ in range(1, blocks):
layers.append(block(out_channels, out_channels))
return nn.SequentialCell(layers)
def construct(self, x):
x = self.conv1(x)
x = self.bn1(x)
x = self.relu(x)
x = self.maxpool(x)
x = self.layer1(x)
x = self.layer2(x)
x = self.layer3(x)
x = self.layer4(x)
x = self.avgpool(x)
x = self.flatten(x)
x = self.fc1(x)
x = self.fc2(x)
return x
class TrainDatasetGenerator:
def __init__(self, file_path):
self.file_path = file_path
self.img_names = os.listdir(file_path)
def __getitem__(self, index):
data = cv2.imread(os.path.join(self.file_path, self.img_names[index]))
label = self.img_names[index].split('_')[0]
label = int(label)
data = cv2.cvtColor(data, cv2.COLOR_BGR2RGB)
data = cv2.resize(data, (224, 224))
data = data.transpose().astype(np.float32) / 255.
return data, label
def __len__(self):
return len(self.img_names)
def load_model_from_ckpt():
context.set_context(mode=context.GRAPH_MODE, device_target='CPU')
# 创建ResNet模型
network = ResNet(BasicBlock, [2, 2, 2, 2])
# 加载ckpt文件中的模型参数
param_dict = load_checkpoint('D:/pythonProject7/ckpt/checkpoint_resnet_34-8_25.ckpt')
# 修改全连接层输出维度
# param_dict['layer4.1.conv2.weight'] = param_dict['layer4.1.conv2.weight'][:, :, :, :]
param_dict['fc1.weight'] = param_dict['fc1.weight'][:, :] # 修改参数名称
param_dict['fc2.weight'] = param_dict['fc2.weight'][:, :] # 修改参数名称
# 将模型参数加载到模型中
load_param_into_net(network, param_dict)
network.fc1 = nn.Dense(512 * 7 * 7, 100) # 修改全连接层输入维度
network.fc2 = nn.Dense(100, 11)
# 返回模型
return network
def train_resnet():
context.set_context(mode=context.GRAPH_MODE, device_target='CPU')
train_dataset_generator = TrainDatasetGenerator('D:/pythonProject7/train1')
ds_train = ds.GeneratorDataset(train_dataset_generator, ['data', 'label'], shuffle=True)
ds_train = ds_train.shuffle(buffer_size=10)
ds_train = ds_train.batch(batch_size=2, drop_remainder=True)
network = ResNet(BasicBlock, [2, 2, 2, 2], num_classes=100)
net_loss = nn.SoftmaxCrossEntropyWithLogits(sparse=True, reduction='mean')
net_opt = nn.Momentum(network.trainable_params(), learning_rate=0.001, momentum=0.9)
model = Model(network, net_loss, net_opt, metrics={'Accuracy': Accuracy()})
face_cascade = cv2.CascadeClassifier('haarcascade_frontalface_alt.xml') # 加载检测器
threshold = 0.95 # 设置阈值
cap = cv2.VideoCapture(0)
stop = False
while not stop:
success, img = cap.read()
subjects = ['1', '2', '3', '4', '5', '6', '7', '8', '9', '10', 'unknown']
# 生成图像的副本，这样就能保留原始图像
img1 = img.copy()
# 检测人脸
# 将测试图像转换为灰度图像，因为opencv人脸检测器需要灰度图像
gray = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
# 检测多尺度图像，返回值是一张脸部区域信息的列表（x,y,宽,高）
rect = face_cascade.detectMultiScale(img, scaleFactor=1.1, minNeighbors=5, minSize=(30, 30),
flags=cv2.CASCADE_SCALE_IMAGE)
# 如果未检测到面部
if len(rect) == 0:
txt = 'no face!'
cv2.putText(img1, txt, (10, 20), cv2.FONT_HERSHEY_COMPLEX, 1, (128, 128, 0), 2)
if not rect is None:
for (x, y, w, h) in rect:
face = img[y:y + w, x:x + h].astype(np.float32) # 数值转换
face = cv2.resize(face, (224, 224)) # 修改图像大小
face = face.transpose().astype(np.float32) / 255.
face = np.expand_dims(face, axis=0) # 扩展维度，变成(batch_size, channels, height, width)
face = Tensor(face)
cv2.rectangle(img1, (x, y), (x + w, y + h), (0, 255, 0), 2) # 画出矩形框
output = network(face)
predicted_class = np.argmax(output.asnumpy(), axis=1)
if output.asnumpy()[0][predicted_class[0]] < threshold:
label = 'unknown'
else:
label = subjects[predicted_class[0]]
# label = subjects[predicted_class[0]]
cv2.putText(img1, label, (x, y), cv2.FONT_HERSHEY_COMPLEX, 1, (128, 128, 0), 2)
cv2.imshow('img', img1)
if (cv2.waitKey(1) & 0xFF == ord('q')): # 按下q程序结束
stop = True
cv2.destroyAllWindows() # 释放窗口
if __name__ == '__main__':
train_resnet()
4. 模型训练
在完成数据准备和模型构建后，可以使用MindSpore提供的训练接口进行模型训练。
5. 模型加载与预测
训练完成后，可以加载训练好的模型进行人脸识别预测。以下是一个示例代码：
# 加载预训练模型
network = load_model_from_ckpt()
# 读取图像数据
image = cv2.imread('test_image.jpg')
# 对图像数据进行预处理
# ...
# 将图像数据转换为MindSpore Tensor
input_tensor = Tensor(image)
# 使用模型进行预测
output = network(input_tensor)
# 获取预测结果
predicted_class = np.argmax(output.asnumpy())
6. 错误分析
在代码中，出现ValueError: For 'MatMul', the input dimensions must be equal, but got 'x1_col': 8192 and 'x2_row': 512.错误的原因是在修改网络结构后，全连接层的输入维度没有进行相应的修改，导致维度不匹配。
解决方法是在修改网络结构后，将全连接层的输入维度也进行修改，例如：
# 修改全连接层输入维度
network.fc1 = nn.Dense(512 * 7 * 7, 100)
network.fc2 = nn.Dense(100, 11)
7. 总结
本文介绍了如何使用MindSpore构建ResNet模型进行人脸识别，并对代码中出现的错误进行了解释和修改。
