使用 MindSpore 训练 ResNet 模型进行人脸识别

from collections import defaultdict, Counter from mindspore.train.serialization import load_checkpoint, load_param_into_net import numpy as np import mindspore.dataset as ds import cv2 import mindspore.nn as nn import os from mindspore import context, ops, Tensor from mindspore.train.callback import ModelCheckpoint, CheckpointConfig, LossMonitor, TimeMonitor from mindspore.train import Model from mindspore.nn.metrics import Accuracy np.random.seed(58)

class ResidualBlock(nn.Cell): expansion = 1 def init(self, in_channels, out_channels, stride=1, downsample=None): super(ResidualBlock, self).init() self.conv1 = nn.Conv2d(in_channels, out_channels, kernel_size=3, stride=stride, pad_mode='same') self.bn1 = nn.BatchNorm2d(out_channels) self.relu = nn.ReLU() self.conv2 = nn.Conv2d(out_channels, out_channels, kernel_size=3, stride=1, pad_mode='same') self.bn2 = nn.BatchNorm2d(out_channels) self.downsample = downsample self.stride = stride

def construct(self, x):
    identity = x

    out = self.conv1(x)
    out = self.bn1(out)
    out = self.relu(out)

    out = self.conv2(out)
    out = self.bn2(out)

    if self.downsample is not None:
        identity = self.downsample(x)
    out += identity
    out = self.relu(out)

    return out

class ResNet(nn.Cell): def init(self, block, layers, num_classes=34): super(ResNet, self).init() self.in_channels = 64

    self.conv1 = nn.Conv2d(3, 64, kernel_size=7, stride=2,   pad_mode='valid')
    self.bn1 = nn.BatchNorm2d(64)
    self.relu = nn.ReLU()
    self.maxpool = nn.MaxPool2d(kernel_size=3, stride=2,   pad_mode='valid')

    self.layer1 = self.make_layer(block, 64, layers[0])
    self.layer2 = self.make_layer(block, 128, layers[1], stride=2)
    self.layer3 = self.make_layer(block, 256, layers[2], stride=2)
    self.layer4 = self.make_layer(block, 512, layers[3], stride=2)

    self.avgpool = nn.AvgPool2d(kernel_size=3, stride=1,   pad_mode='valid')
    self.fc = nn.Dense(512 * block.expansion, num_classes)

def make_layer(self, block, out_channels, blocks, stride=1):
    downsample = None
    if (stride != 1) or (self.in_channels != out_channels * block.expansion):
        downsample = nn.SequentialCell([
            nn.Conv2d(self.in_channels, out_channels * block.expansion, kernel_size=1, stride=stride),
            nn.BatchNorm2d(out_channels * block.expansion)
        ])
    layers = []
    layers.append(block(self.in_channels, out_channels, stride, downsample))
    self.in_channels = out_channels * block.expansion
    for _ in range(1, blocks):
        layers.append(block(self.in_channels, out_channels))
    return nn.SequentialCell(layers)

def construct(self, x):
    x = self.conv1(x)
    x = self.bn1(x)
    x = self.relu(x)
    x = self.maxpool(x)

    x = self.layer1(x)
    x = self.layer2(x)
    x = self.layer3(x)
    x = self.layer4(x)

    x = self.avgpool(x)
    x = ops.Reshape()(x, (ops.Shape()(x)[0], -1))
    x = self.fc(x)

    return x

class TrainDatasetGenerator: def init(self, file_path): self.file_path = file_path self.img_names = os.listdir(file_path)

def __getitem__(self, index=0):
    data = cv2.imread(os.path.join(self.file_path, self.img_names[index]))
    label = int(self.img_names[index].split('-')[0])
    data = cv2.resize(data,(100,100))
    data = data.transpose().astype(np.float32) / 255.
    return data, label

def __len__(self):
    return len(self.img_names)

def load_model_from_ckpt(): context.set_context(mode=context.GRAPH_MODE, device_target='CPU') # 创建ResNet模型 network = ResNet(ResidualBlock,[2,2,2,2]) # 加载ckpt文件中的模型参数 param_dict = load_checkpoint('D:/pythonproject2/ckpt/checkpoint_resnet_1-20_49.ckpt') #将模型参数加载到模型中 load_param_into_net(network, param_dict) # 返回模型 return network

def train_resnet(): context.set_context(mode=context.GRAPH_MODE, device_target='CPU') train_dataset_generator = TrainDatasetGenerator('D:/pythonproject2/digital_mindspore/dataset') ds_train = ds.GeneratorDataset(train_dataset_generator, ['data', 'label'], shuffle=True) ds_train = ds_train.shuffle(buffer_size=10) ds_train = ds_train.batch(batch_size=4, drop_remainder=True) network = load_model_from_ckpt() net_loss = nn.SoftmaxCrossEntropyWithLogits(sparse=True, reduction='mean') net_opt = nn.Momentum(network.trainable_params(), learning_rate=0.001, momentum=0.9) #time_cb = TimeMonitor(data_size=ds_train.get_dataset_size()) #config_ck = CheckpointConfig(save_checkpoint_steps=10,keep_checkpoint_max=10) #config_ckpt_path = 'D:/pythonproject2/ckpt/' #ckpoint_cb = ModelCheckpoint(prefix='checkpoint_resnet', directory=config_ckpt_path, config=config_ck)

model = Model(network, net_loss, net_opt, metrics={'Accuracy': Accuracy()})
#epoch_size = 20
#print('============== Starting Training =============')
#model.train(epoch_size, ds_train, callbacks=[time_cb, ckpoint_cb, LossMonitor()])
face_cascade = cv2.CascadeClassifier('haarcascade_frontalface_alt.xml')  # 加载检测器
# 训练阶段

cap = cv2.VideoCapture(0)
stop = False
while not stop:
    success, img = cap.read()
    subjects = ['0', '1', '2', '3', '4', '5', '6', '7', '8', '9', '10', '11', '12', '13', '14', '15', '16', '17',
                '18', '19', '20', '21', '22', '23', '24', '25', '26', '27', '28', '29', '30', '31', '32', '33']
    # 生成图像的副本，这样就能保留原始图像
    img1 = img.copy()
    # 检测人脸
    # 将测试图像转换为灰度图像，因为opencv人脸检测器需要灰度图像
    gray = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
    # 检测多尺度图像，返回值是一张脸部区域信息的列表（x,y,宽,高）
    rect = face_cascade.detectMultiScale(img, scaleFactor=1.1, minNeighbors=5, minSize=(30, 30),
                                         flags=cv2.CASCADE_SCALE_IMAGE)
    # 如果未检测到面部
    if len(rect) == 0:
        txt = 'no face!'
        cv2.putText(img1, txt, (10, 20), cv2.FONT_HERSHEY_COMPLEX, 1, (128, 128, 0), 2)
    if not rect is None:
        for (x, y, w, h) in rect:
            face = gray[y:y + w, x:x + h].astype(np.float32)  # 数值转换
            face = cv2.resize(face, (100, 100))
            face = face.transpose().astype(np.float32) / 255.
            face = np.expand_dims(face, axis=0)  # 扩展维度，变成(batch_size, channels, height, width)
            face = Tensor(face)
            print(face.shape)
            cv2.rectangle(img1, (x, y), (x + w, y + h), (0, 255, 0), 2)  # 画出矩形框
            output =network(face)
            predicted_class = np.argmax(output.asnumpy(),axis=1)
            label = subjects[predicted_class[0]]
            #if min_d < 200000000000:
            cv2.putText(img1, label, (x, y), cv2.FONT_HERSHEY_COMPLEX, 1, (128, 128, 0), 2)
            #else:
             #   label = 'unknown'
              #  cv2.putText(img1, label, (x, y), cv2.FONT_HERSHEY_COMPLEX, 1, (128, 128, 0), 2)
    cv2.imshow('img', img1)
    if (cv2.waitKey(1) & 0xFF == ord('q')):  # 按下q程序结束
            stop = True
            cv2.destroyAllWindows()  # 释放窗口

if name == 'main': train_resnet()

为什么face是3维的，使用了face = np.expand_dims(face, axis=0) 也没有变成4维

内容：根据代码，face 是一个 shape 为 (100, 100, 3) 的三维数组，其中最后一维是颜色通道，因为图像是 RGB 格式。在使用 np.expand_dims(face, axis=0) 扩展维度时，只是在最前面添加了一个 batch_size 维度，变成了 shape 为 (1, 100, 100, 3) 的四维数组，但是颜色通道仍然存在。因此，需要将颜色通道转换为通道数为 1，可以使用 cv2.cvtColor 将图像转换为灰度图像，或者在 face 上使用 np.expand_dims(face, axis=-1) 添加一个通道维度。这样扩展维度后，face 的 shape 变成了 (1, 100, 100, 1)。
