ResNet 模型训练与人脸识别 (MindSpore) - 解决方案和优化
这个错误提示是说 Conv2D 操作的输入必须是四维的，但是你的输入只有三维。可能是在使用 Conv2D 之前没有将数据的维度进行扩展。你可以在 Conv2D 之前加上一个维度扩展操作，将数据从三维变成四维，例如：
data = np.expand_dims(data, axis=0) # 扩展维度，变成(batch_size, channels, height, width)
data = Tensor(data)
out = self.conv(data)
这样就可以解决报错问题了。
以下是对代码进行优化和解释后的完整版本，并包含了对错误处理的说明：
from collections import defaultdict, Counter
from mindspore.train.serialization import load_checkpoint, load_param_into_net
import numpy as np
import mindspore.dataset as ds
import cv2
import mindspore.nn as nn
import os
from mindspore import context, ops, Tensor
from mindspore.train.callback import ModelCheckpoint, CheckpointConfig, LossMonitor, TimeMonitor
from mindspore.train import Model
from mindspore.nn.metrics import Accuracy
np.random.seed(58)
class ResidualBlock(nn.Cell):
expansion = 1
def __init__(self, in_channels, out_channels, stride=1, downsample=None):
super(ResidualBlock, self).__init__()
self.conv1 = nn.Conv2d(in_channels, out_channels, kernel_size=3, stride=stride, pad_mode='same')
self.bn1 = nn.BatchNorm2d(out_channels)
self.relu = nn.ReLU()
self.conv2 = nn.Conv2d(out_channels, out_channels, kernel_size=3, stride=1, pad_mode='same')
self.bn2 = nn.BatchNorm2d(out_channels)
self.downsample = downsample
self.stride = stride
def construct(self, x):
identity = x
out = self.conv1(x)
out = self.bn1(out)
out = self.relu(out)
out = self.conv2(out)
out = self.bn2(out)
if self.downsample is not None:
identity = self.downsample(x)
out += identity
out = self.relu(out)
return out
class ResNet(nn.Cell):
def __init__(self, block, layers, num_classes=34):
super(ResNet, self).__init__()
self.in_channels = 64
self.conv1 = nn.Conv2d(3, 64, kernel_size=7, stride=2, pad_mode='valid')
self.bn1 = nn.BatchNorm2d(64)
self.relu = nn.ReLU()
self.maxpool = nn.MaxPool2d(kernel_size=3, stride=2, pad_mode='valid')
self.layer1 = self.make_layer(block, 64, layers[0])
self.layer2 = self.make_layer(block, 128, layers[1], stride=2)
self.layer3 = self.make_layer(block, 256, layers[2], stride=2)
self.layer4 = self.make_layer(block, 512, layers[3], stride=2)
self.avgpool = nn.AvgPool2d(kernel_size=3, stride=1, pad_mode='valid')
self.fc = nn.Dense(512 * block.expansion, num_classes)
def make_layer(self, block, out_channels, blocks, stride=1):
downsample = None
if (stride != 1) or (self.in_channels != out_channels * block.expansion):
downsample = nn.SequentialCell([
nn.Conv2d(self.in_channels, out_channels * block.expansion, kernel_size=1, stride=stride),
nn.BatchNorm2d(out_channels * block.expansion)
])
layers = []
layers.append(block(self.in_channels, out_channels, stride, downsample))
self.in_channels = out_channels * block.expansion
for _ in range(1, blocks):
layers.append(block(self.in_channels, out_channels))
return nn.SequentialCell(layers)
def construct(self, x):
x = self.conv1(x)
x = self.bn1(x)
x = self.relu(x)
x = self.maxpool(x)
x = self.layer1(x)
x = self.layer2(x)
x = self.layer3(x)
x = self.layer4(x)
x = self.avgpool(x)
x = ops.Reshape()(x, (ops.Shape()(x)[0], -1))
x = self.fc(x)
return x
class TrainDatasetGenerator:
def __init__(self, file_path):
self.file_path = file_path
self.img_names = os.listdir(file_path)
def __getitem__(self, index=0):
data = cv2.imread(os.path.join(self.file_path, self.img_names[index]))
label = int(self.img_names[index].split('-')[0])
data = cv2.resize(data,(100,100))
data = data.transpose().astype(np.float32) / 255.
return data, label
def __len__(self):
return len(self.img_names)
def load_model_from_ckpt():
context.set_context(mode=context.GRAPH_MODE, device_target='CPU')
# 创建ResNet模型
network = ResNet(ResidualBlock,[2,2,2,2])
# 加载ckpt文件中的模型参数
param_dict = load_checkpoint('D:/pythonproject2/ckpt/checkpoint_resnet_1-20_49.ckpt')
#将模型参数加载到模型中
load_param_into_net(network, param_dict)
# 返回模型
return network
def train_resnet():
context.set_context(mode=context.GRAPH_MODE, device_target='CPU')
train_dataset_generator = TrainDatasetGenerator('D:/pythonproject2/digital_mindspore/dataset')
ds_train = ds.GeneratorDataset(train_dataset_generator, ['data', 'label'], shuffle=True)
ds_train = ds_train.shuffle(buffer_size=10)
ds_train = ds_train.batch(batch_size=4, drop_remainder=True)
network = load_model_from_ckpt()
net_loss = nn.SoftmaxCrossEntropyWithLogits(sparse=True, reduction='mean')
net_opt = nn.Momentum(network.trainable_params(), learning_rate=0.001, momentum=0.9)
#time_cb = TimeMonitor(data_size=ds_train.get_dataset_size())
#config_ck = CheckpointConfig(save_checkpoint_steps=10,keep_checkpoint_max=10)
#config_ckpt_path = 'D:/pythonproject2/ckpt/'
#ckpoint_cb = ModelCheckpoint(prefix='checkpoint_resnet', directory=config_ckpt_path, config=config_ck)
model = Model(network, net_loss, net_opt, metrics={'Accuracy': Accuracy()})
#epoch_size = 20
#print('============== Starting Training =============')
#model.train(epoch_size, ds_train, callbacks=[time_cb, ckpoint_cb, LossMonitor()])
face_cascade = cv2.CascadeClassifier('haarcascade_frontalface_alt.xml') # 加载检测器
# 训练阶段
cap = cv2.VideoCapture(0)
stop = False
while not stop:
success, img = cap.read()
subjects = ['0', '1', '2', '3', '4', '5', '6', '7', '8', '9', '10', '11', '12', '13', '14', '15', '16', '17',
'18', '19', '20', '21', '22', '23', '24', '25', '26', '27', '28', '29', '30', '31', '32', '33']
# 生成图像的副本，这样就能保留原始图像
img1 = img.copy()
# 检测人脸
# 将测试图像转换为灰度图像，因为opencv人脸检测器需要灰度图像
gray = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
# 检测多尺度图像，返回值是一张脸部区域信息的列表（x,y,宽,高）
rect = face_cascade.detectMultiScale(img, scaleFactor=1.1, minNeighbors=5, minSize=(30, 30),
flags=cv2.CASCADE_SCALE_IMAGE)
# 如果未检测到面部
if len(rect) == 0:
txt = 'no face!'
cv2.putText(img1, txt, (10, 20), cv2.FONT_HERSHEY_COMPLEX, 1, (128, 128, 0), 2)
if not rect is None:
for (x, y, w, h) in rect:
face = gray[y:y + w, x:x + h].astype(np.float32) # 数值转换
face = cv2.resize(face, (100, 100))
face = face.transpose().astype(np.float32) / 255.
face = np.expand_dims(face, axis=0) # 扩展维度，变成(batch_size, channels, height, width)
face = Tensor(face)
cv2.rectangle(img1, (x, y), (x + w, y + h), (0, 255, 0), 2) # 画出矩形框
output =network(face)
predicted_class = np.argmax(output.asnumpy(),axis=1)
label = subjects[predicted_class[0]]
#if min_d < 200000000000:
cv2.putText(img1, label, (x, y), cv2.FONT_HERSHEY_COMPLEX, 1, (128, 128, 0), 2)
#else:
# label = 'unknown'
# cv2.putText(img1, label, (x, y), cv2.FONT_HERSHEY_COMPLEX, 1, (128, 128, 0), 2)
cv2.imshow('img', img1)
if (cv2.waitKey(1) & 0xFF == ord('q')): # 按下q程序结束
stop = True
cv2.destroyAllWindows() # 释放窗口
if __name__ == '__main__':
train_resnet()
代码优化和解释
- **维度扩展：**在
train_resnet函数中，使用np.expand_dims(face, axis=0)将face数据扩展为四维，以满足Conv2D操作的输入要求。 - **错误处理：**在
train_resnet函数中，使用if len(rect) == 0:检查是否检测到人脸，如果未检测到，则显示 'no face!'。 - **代码风格：**调整代码格式，使用更清晰的变量名和注释。
- **训练和识别分离：**将模型训练部分代码注释掉，将重点放在人脸识别部分。
人脸识别流程
- **加载预训练模型：**从
checkpoint_resnet_1-20_49.ckpt文件加载已训练好的 ResNet 模型。 - **人脸检测：**使用 OpenCV 的
haarcascade_frontalface_alt.xml检测器检测图像中的人脸。 - **人脸预处理：**将检测到的图像裁剪、调整大小并进行归一化。
- **特征提取：**使用加载的 ResNet 模型提取人脸特征。
- **预测分类：**通过模型输出的结果预测人脸的类别。
- **显示结果：**在图像上显示人脸框和预测的类别。
其他优化建议：
- 可以使用其他更先进的人脸识别模型，例如 FaceNet、ArcFace 等。
- 可以使用 GPU 训练模型，加速训练过程。
- 可以增加训练数据，提高模型的识别精度。
- 可以使用迁移学习，将预训练好的模型应用于其他领域的人脸识别任务。
- 可以使用数据增强技术，增加训练数据的多样性，提高模型的鲁棒性。
总结：
本文介绍了如何使用 MindSpore 框架训练 ResNet 模型并进行人脸识别，并提供了对代码的优化和解释。希望本文能对您学习 MindSpore 和人脸识别有所帮助。
