import os import cv2 import numpy as np import mindspore from mindspore import Tensor, load_checkpoint, load_param_into_net from mindspore.dataset.vision import py_transforms from mindspore.dataset.transforms.py_transforms import Compose from PIL import Image from main import ResNet, BasicBlock

加载标签

with open('label.txt') as f: labels = f.readlines() labels = [l.strip() for l in labels]

加载人脸检测器

face_cascade = cv2.CascadeClassifier('haarcascade_frontalface_default.xml')

打开摄像头

cap = cv2.VideoCapture(0)

遍历ckpt文件夹中的所有ckpt文件

ckpt_dir = 'D:/pythonProject7/ckpt/' ckpt_files = os.listdir(ckpt_dir) ckpt_files = [f for f in ckpt_files if f.endswith('.ckpt')] ckpt_files.sort(key=lambda x: os.path.getmtime(os.path.join(ckpt_dir, x)))

for ckpt_file in ckpt_files: # 加载模型的函数 def load_model(): network = ResNet(BasicBlock, [2, 2, 2, 2], num_classes=2) # 修改模型输出层类别数 params = load_checkpoint(os.path.join(ckpt_dir, ckpt_file)) load_param_into_net(network, params) return network

# 加载模型
network = load_model()

while True:
    # 读取视频帧
    ret, frame = cap.read()

    # 转换为灰度图像
    gray = cv2.cvtColor(frame, cv2.COLOR_BGR2GRAY)

    # 检测人脸
    faces = face_cascade.detectMultiScale(gray, 1.3, 5)

    for (x, y, w, h) in faces:
        # 提取人脸图像
        face = gray[y:y + h, x:x + w]
        face = cv2.resize(face, (224, 224)).astype(np.float32)
        face = cv2.cvtColor(face, cv2.COLOR_GRAY2RGB)

        # 转换为Tensor类型，并进行归一化
        transform = Compose([
            py_transforms.ToTensor(),
            py_transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225])
        ])
        face = transform(face)

        # 转换为Tensor类型，并增加一个维度
        face = Tensor(face)
        #face = mindspore.ops.ExpandDims()(face, 0)

        # 预测人脸所属的类别
        output = network(face)
        prediction = np.argmax(output.asnumpy())

        # 在图像上标注人脸和类别
        cv2.rectangle(frame, (x, y), (x + w, y + h), (0, 255, 0), 2)
        cv2.putText(frame, labels[prediction], (x, y - 10), cv2.FONT_HERSHEY_SIMPLEX, 0.9, (0, 0, 255), 2)

    # 显示图像
    cv2.imshow('frame', frame)
    if cv2.waitKey(1) & 0xFF == ord('q'):
        break

# 释放摄像头并关闭窗口
cap.release()
cv2.destroyAllWindows()

训练模型为： import numpy as np import mindspore.dataset as ds import os import cv2 import mindspore import mindspore.nn as nn from mindspore import Tensor from mindspore.common.initializer import Normal from mindspore import context from mindspore.train.callback import ModelCheckpoint, CheckpointConfig, LossMonitor, TimeMonitor from mindspore.train import Model from mindspore.nn.metrics import Accuracy from mindspore.ops.operations import TensorAdd from scipy.integrate._ivp.radau import P from mindspore import Model # 承载网络结构 from mindspore.nn.metrics import Accuracy # 测试模型用

np.random.seed(58)

class BasicBlock(nn.Cell): def init(self, in_channels, out_channels, stride=1, downsample=None): super(BasicBlock, self).init() self.conv1 = nn.Conv2d(in_channels, out_channels, kernel_size=3, stride=stride, padding=1, pad_mode='pad', has_bias=False) self.bn1 = nn.BatchNorm2d(out_channels) self.relu = nn.ReLU() self.conv2 = nn.Conv2d(out_channels, out_channels, kernel_size=3, stride=1, padding=1, pad_mode='pad', has_bias=False) self.bn2 = nn.BatchNorm2d(out_channels) self.downsample = downsample self.add = TensorAdd()

def construct(self, x):
    identity = x

    out = self.conv1(x)
    out = self.bn1(out)
    out = self.relu(out)

    out = self.conv2(out)
    out = self.bn2(out)

    if self.downsample is not None:
        identity = self.downsample(x)

    out = self.add(out, identity)
    out = self.relu(out)

    return out

class ResNet(nn.Cell): def init(self, block, layers, num_classes=2): # 修改模型输出层类别数 super(ResNet, self).init() self.in_channels = 64

    self.conv1 = nn.Conv2d(3, 64, kernel_size=7, stride=2, padding=3, pad_mode='pad', has_bias=False)
    self.bn1 = nn.BatchNorm2d(64)
    self.relu = nn.ReLU()
    self.maxpool = nn.MaxPool2d(kernel_size=3, stride=2, pad_mode='same')
    self.layer1 = self.make_layer(block, 64, layers[0])
    self.layer2 = self.make_layer(block, 128, layers[1], stride=2)
    self.layer3 = self.make_layer(block, 256, layers[2], stride=2)
    self.layer4 = self.make_layer(block, 512, layers[3], stride=2)
    self.avgpool = nn.AvgPool2d(kernel_size=7, stride=1)
    self.flatten = nn.Flatten()
    self.fc = nn.Dense(512, num_classes)

def make_layer(self, block, out_channels, blocks, stride=1):
    downsample = None
    if stride != 1 or self.in_channels != out_channels:
        downsample = nn.SequentialCell([
            nn.Conv2d(self.in_channels, out_channels, kernel_size=1, stride=stride, has_bias=False),
            nn.BatchNorm2d(out_channels)
        ])

    layers = []
    layers.append(block(self.in_channels, out_channels, stride, downsample))
    self.in_channels = out_channels
    for _ in range(1, blocks):
        layers.append(block(out_channels, out_channels))

    return nn.SequentialCell(layers)

def construct(self, x):
    x = self.conv1(x)
    x = self.bn1(x)
    x = self.relu(x)
    x = self.maxpool(x)

    x = self.layer1(x)
    x = self.layer2(x)
    x = self.layer3(x)
    x = self.layer4(x)

    x = self.avgpool(x)
    x = self.flatten(x)
    x = self.fc(x)

    return x

class TrainDatasetGenerator: def init(self, file_path): self.file_path = file_path self.img_names = os.listdir(file_path)

def __getitem__(self, index):
    data = cv2.imread(os.path.join(self.file_path, self.img_names[index]))
    label = self.img_names[index].split('_')[0]
    label = int(label)
    data = cv2.cvtColor(data, cv2.COLOR_BGR2RGB)
    data = cv2.resize(data, (224, 224))
    data = data.transpose().astype(np.float32) / 255.
    return data, label

def __len__(self):
    return len(self.img_names)

def train_resnet(): context.set_context(mode=context.GRAPH_MODE, device_target='CPU') train_dataset_generator = TrainDatasetGenerator('D:/pythonProject7/train1') ds_train = ds.GeneratorDataset(train_dataset_generator, ['data', 'label'], shuffle=True) ds_train = ds_train.shuffle(buffer_size=10) ds_train = ds_train.batch(batch_size=4, drop_remainder=True) valid_dataset_generator = TrainDatasetGenerator('D:/pythonProject7/test1') ds_valid = ds.GeneratorDataset(valid_dataset_generator, ['data', 'label'], shuffle=True) ds_valid = ds_valid.batch(batch_size=4, drop_remainder=True) network = ResNet(BasicBlock, [2, 2, 2, 2], num_classes=2) # 修改模型输出层类别数 net_loss = nn.SoftmaxCrossEntropyWithLogits(sparse=True, reduction='mean') net_opt = nn.Momentum(network.trainable_params(), learning_rate=0.01, momentum=0.9) time_cb = TimeMonitor(data_size=ds_train.get_dataset_size()) config_ck = CheckpointConfig(save_checkpoint_steps=10, keep_checkpoint_max=10) config_ckpt_path = 'D:/pythonProject7/ckpt/' ckpoint_cb = ModelCheckpoint(prefix='checkpoint_resnet', directory=config_ckpt_path, config=config_ck)

model = Model(network, net_loss, net_opt, metrics={'Accuracy': Accuracy()})
epoch_size = 10
print('============== Starting Training =============')
model.train(epoch_size, ds_train, callbacks=[time_cb, ckpoint_cb, LossMonitor()])

acc = model.eval(ds_valid)
print('============== {} ============='.format(acc))
epoch_size = 10
print('============== Starting Training =============')
model.train(epoch_size, ds_train, callbacks=[time_cb, ckpoint_cb, LossMonitor()])

acc = model.eval(ds_valid)
print('============== {} ============='.format(acc))
epoch_size = 10
print('============== Starting Training =============')
model.train(epoch_size, ds_train, callbacks=[time_cb, ckpoint_cb, LossMonitor()])

acc = model.eval(ds_valid)
print('============== {} ============='.format(acc))

if name == 'main': train_resnet() 为什么运行时每一个人都是4号，如何修改代码得到正确的人人脸识别结果，给出示例内容：问题分析：

在代码中，训练模型使用的是100个类别的数据集，但人脸识别需要的是人脸数据集，因此需要修改模型的输出层为人脸数据集的类别数。

同时，在预测时需要对图像进行预处理，包括缩放、归一化等操作，这样才能得到正确的预测结果。

解决方法：

1. 修改模型的输出层为人脸数据集的类别数。

将ResNet类的num_classes参数修改为人脸数据集的类别数即可，例如：

network = ResNet(BasicBlock, [2, 2, 2, 2], num_classes=2)

2. 对图像进行预处理。

在预测时，需要对图像进行预处理，包括缩放、归一化等操作，这样才能得到正确的预测结果。可以参考以下代码：

提取人脸图像

face = gray[y:y + h, x:x + w] face = cv2.resize(face, (224, 224)).astype(np.float32) face = cv2.cvtColor(face, cv2.COLOR_GRAY2RGB)

转换为Tensor类型，并进行归一化

transform = Compose([ py_transforms.ToTensor(), py_transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]) ]) face = transform(face)

转换为Tensor类型，并增加一个维度

face = Tensor(face) #face = mindspore.ops.ExpandDims()(face, 0)

其中，ToTensor()函数将图像转换为Tensor类型，Normalize()函数进行归一化操作。

完整代码如下：

import os import cv2 import numpy as np import mindspore from mindspore import Tensor, load_checkpoint, load_param_into_net from mindspore.dataset.vision import py_transforms from mindspore.dataset.transforms.py_transforms import Compose from PIL import Image from main import ResNet, BasicBlock

加载标签

with open('label.txt') as f: labels = f.readlines() labels = [l.strip() for l in labels]

加载人脸检测器

face_cascade = cv2.CascadeClassifier('haarcascade_frontalface_default.xml')

打开摄像头

cap = cv2.VideoCapture(0)

修改模型的输出层为人脸数据集的类别数

network = ResNet(BasicBlock, [2, 2, 2, 2], num_classes=2)

加载最新的ckpt文件

ckpt_dir = 'D:/pythonProject7/ckpt/' ckpt_files = os.listdir(ckpt_dir) ckpt_files = [f for f in ckpt_files if f.endswith('.ckpt')] ckpt_files.sort(key=lambda x: os.path.getmtime(os.path.join(ckpt_dir, x))) ckpt_file = ckpt_files[-1] params = load_checkpoint(os.path.join(ckpt_dir, ckpt_file)) load_param_into_net(network, params)

while True: # 读取视频帧 ret, frame = cap.read()

# 转换为灰度图像
gray = cv2.cvtColor(frame, cv2.COLOR_BGR2GRAY)

# 检测人脸
faces = face_cascade.detectMultiScale(gray, 1.3, 5)

for (x, y, w, h) in faces:
    # 提取人脸图像
    face = gray[y:y + h, x:x + w]
    face = cv2.resize(face, (224, 224)).astype(np.float32)
    face = cv2.cvtColor(face, cv2.COLOR_GRAY2RGB)

    # 转换为Tensor类型，并进行归一化

transform = Compose([ py_transforms.ToTensor(), py_transforms.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225]) ]) face = transform(face)

    # 转换为Tensor类型，并增加一个维度
    face = Tensor(face)
    #face = mindspore.ops.ExpandDims()(face, 0)

    # 预测人脸所属的类别
    output = network(face)
    prediction = np.argmax(output.asnumpy())

    # 在图像上标注人脸和类别
    cv2.rectangle(frame, (x, y), (x + w, y + h), (0, 255, 0), 2)
    cv2.putText(frame, labels[prediction], (x, y - 10), cv2.FONT_HERSHEY_SIMPLEX, 0.9, (0, 0, 255), 2)

# 显示图像
cv2.imshow('frame', frame)
if cv2.waitKey(1) & 0xFF == ord('q'):
    break

释放摄像头并关闭窗口

cap.release() cv2.destroyAllWindows()
