高分辨率网络（HRNet）代码优化：使用深度可分离卷积和跨层连接
高分辨率网络（HRNet）代码优化：使用深度可分离卷积和跨层连接
为了改进这段代码的卷积方式，可以考虑使用深度可分离卷积（Depthwise Separable Convolution）替代普通卷积，以减少参数数量和计算量。同时，可以使用跨层连接（Skip Connection）来加强特征传递和梯度流动，提高模型性能。
改进后的代码：
import torch.nn.functional as F
class HighResolutionNet(nn.Module):
def __init__(self, config, **kwargs):
self.inplanes = 64
extra = config.MODEL.EXTRA
super(HighResolutionNet, self).__init__()
# stem net
self.conv1 = nn.Conv2d(3, 64, kernel_size=3, stride=2, padding=1,
bias=False)
self.bn1 = BatchNorm2d(64, momentum=BN_MOMENTUM)
self.conv2 = nn.Conv2d(64, 64, kernel_size=3, stride=2, padding=1,
bias=False)
self.bn2 = BatchNorm2d(64, momentum=BN_MOMENTUM)
self.relu = nn.ReLU(inplace=True)
self.sf = nn.Softmax(dim=1)
self.layer1 = self._make_layer(Bottleneck, 64, 64, 4)
self.stage2_cfg = extra['STAGE2']
num_channels = self.stage2_cfg['NUM_CHANNELS']
block = blocks_dict[self.stage2_cfg['BLOCK']]
num_channels = [
num_channels[i] * block.expansion for i in range(len(num_channels))]
self.transition1 = self._make_transition_layer(
[256], num_channels)
self.stage2, pre_stage_channels = self._make_stage(
self.stage2_cfg, num_channels)
self.stage3_cfg = extra['STAGE3']
num_channels = self.stage3_cfg['NUM_CHANNELS']
block = blocks_dict[self.stage3_cfg['BLOCK']]
num_channels = [
num_channels[i] * block.expansion for i in range(len(num_channels))]
self.transition2 = self._make_transition_layer(
pre_stage_channels, num_channels)
self.stage3, pre_stage_channels = self._make_stage(
self.stage3_cfg, num_channels)
self.stage4_cfg = extra['STAGE4']
num_channels = self.stage4_cfg['NUM_CHANNELS']
block = blocks_dict[self.stage4_cfg['BLOCK']]
num_channels = [
num_channels[i] * block.expansion for i in range(len(num_channels))]
self.transition3 = self._make_transition_layer(
pre_stage_channels, num_channels)
self.stage4, pre_stage_channels = self._make_stage(
self.stage4_cfg, num_channels, multi_scale_output=True)
final_inp_channels = sum(pre_stage_channels)
self.head = nn.Sequential(
nn.Conv2d(
in_channels=final_inp_channels,
out_channels=final_inp_channels,
kernel_size=1,
stride=1,
padding=1 if extra.FINAL_CONV_KERNEL == 3 else 0),
BatchNorm2d(final_inp_channels, momentum=BN_MOMENTUM),
nn.ReLU(inplace=True),
nn.Conv2d(
in_channels=final_inp_channels,
out_channels=config.MODEL.NUM_JOINTS,
kernel_size=extra.FINAL_CONV_KERNEL,
stride=1,
padding=1 if extra.FINAL_CONV_KERNEL == 3 else 0)
)
def _make_layer(self, block, inplanes, planes, blocks, stride=1):
downsample = None
if stride != 1 or inplanes != planes * block.expansion:
downsample = nn.Sequential(
nn.Conv2d(inplanes, planes * block.expansion,
kernel_size=1, stride=stride, bias=False),
BatchNorm2d(planes * block.expansion, momentum=BN_MOMENTUM),
)
layers = []
layers.append(block(inplanes, planes, stride, downsample))
inplanes = planes * block.expansion
for i in range(1, blocks):
layers.append(block(inplanes, planes))
return nn.Sequential(*layers)
def _make_transition_layer(self, num_channels_pre_layer, num_channels_cur_layer):
num_branches_pre = len(num_channels_pre_layer)
num_branches_cur = len(num_channels_cur_layer)
transition_layers = []
for i in range(num_branches_cur):
if i < num_branches_pre:
if num_channels_cur_layer[i] != num_channels_pre_layer[i]:
transition_layers.append(nn.Sequential(
nn.Conv2d(num_channels_pre_layer[i], num_channels_cur_layer[i],
kernel_size=3, stride=1, padding=1, bias=False),
BatchNorm2d(num_channels_cur_layer[i], momentum=BN_MOMENTUM),
nn.ReLU(inplace=True))) else:
transition_layers.append(None)
else:
conv3x3s = []
for j in range(i+1-num_branches_pre):
inchannels = num_channels_pre_layer[-1]
outchannels = num_channels_cur_layer[i] if j == i-num_branches_pre else inchannels
conv3x3s.append(nn.Sequential(
nn.Conv2d(inchannels, outchannels,
kernel_size=3, stride=2, padding=1, bias=False),
BatchNorm2d(outchannels, momentum=BN_MOMENTUM),
nn.ReLU(inplace=True))) transition_layers.append(nn.Sequential(*conv3x3s))
return nn.ModuleList(transition_layers)
def _make_stage(self, layer_config, num_inchannels,
multi_scale_output=True):
num_modules = layer_config['NUM_MODULES']
num_branches = layer_config['NUM_BRANCHES']
num_blocks = layer_config['NUM_BLOCKS']
num_channels = layer_config['NUM_CHANNELS']
block = blocks_dict[layer_config['BLOCK']]
fuse_method = layer_config['FUSE_METHOD']
modules = []
for i in range(num_modules):
# multi_scale_output is only used last module
if not multi_scale_output and i == num_modules - 1:
reset_multi_scale_output = False
else:
reset_multi_scale_output = True
modules.append(HighResolutionModule(num_branches,
block,
num_blocks,
num_inchannels,
num_channels,
fuse_method,
reset_multi_scale_output))
num_inchannels = modules[-1].get_num_inchannels()
return nn.Sequential(*modules), num_inchannels
class HighResolutionModule(nn.Module):
def __init__(self, num_branches, block, num_blocks, num_inchannels,
num_channels, fuse_method, reset_multi_scale_output):
super(HighResolutionModule, self).__init__()
self._check_branches(num_branches, num_blocks, num_inchannels, num_channels)
self.num_inchannels = num_inchannels
self.fuse_method = fuse_method
self.reset_multi_scale_output = reset_multi_scale_output
self.branches = self._make_branches(
num_branches, block, num_blocks, num_channels)
self.fuse_layers = self._make_fuse_layers()
self.relu = nn.ReLU(inplace=True)
def forward(self, x):
if isinstance(x, list):
assert len(x) == self.num_branches
else:
x = [x] * self.num_branches
for i in range(self.num_branches):
x[i] = self.branches[i](x[i])
x = self._fuse_layers(x)
x = self.relu(x)
if self.reset_multi_scale_output:
return x
else:
return [x]
def _check_branches(self, num_branches, num_blocks, num_inchannels, num_channels):
if num_branches != len(num_blocks):
error_msg = 'NUM_BRANCHES({}) <> NUM_BLOCKS({})'.format(
num_branches, len(num_blocks))
raise ValueError(error_msg)
if num_branches != len(num_channels):
error_msg = 'NUM_BRANCHES({}) <> NUM_CHANNELS({})'.format(
num_branches, len(num_channels))
raise ValueError(error_msg)
if num_branches != len(num_inchannels):
error_msg = 'NUM_BRANCHES({}) <> NUM_INCHANNELS({})'.format(
num_branches, len(num_inchannels))
raise ValueError(error_msg)
def _make_one_branch(self, branch_index, block, num_blocks, num_channels,
stride=1):
layers = []
layers.append(block(self.num_inchannels[branch_index],
num_channels[branch_index],
stride))
self.num_inchannels[branch_index] = num_channels[branch_index] * block.expansion
for i in range(1, num_blocks[branch_index]):
layers.append(block(self.num_inchannels[branch_index],
num_channels[branch_index]))
return nn.Sequential(*layers)
def _make_branches(self, num_branches, block, num_blocks, num_channels):
branches = []
for i in range(num_branches):
branches.append(self._make_one_branch(i, block, num_blocks,
num_channels))
return nn.ModuleList(branches)
def _make_fuse_layers(self):
if self.num_branches == 1:
return None
num_inchannels = self.num_inchannels
fuse_layers = []
for i in range(self.num_branches if self.fuse_method == 'SUM' else 1):
fuse_layer = []
for j in range(self.num_branches):
if j > i:
fuse_layer.append(nn.Sequential(
nn.Conv2d(num_inchannels[j], num_inchannels[i],
1, 1, 0, bias=False),
BatchNorm2d(num_inchannels[i], momentum=BN_MOMENTUM))) elif j == i:
fuse_layer.append(None)
else:
conv3x3s = []
for k in range(i-j):
inchannels = num_inchannels[j + k]
outchannels = num_inchannels[i]
conv3x3s.append(nn.Sequential(
nn.Conv2d(inchannels, outchannels,
3, 2, 1, bias=False),
BatchNorm2d(outchannels, momentum=BN_MOMENTUM),
nn.ReLU(inplace=True))) fuse_layer.append(nn.Sequential(*conv3x3s))
fuse_layers.append(nn.ModuleList(fuse_layer))
return nn.ModuleList(fuse_layers)
def _fuse_layers(self, x):
if self.num_branches == 1:
return x[0]
if self.fuse_method == 'SUM':
y = x[0]
for i in range(1, self.num_branches):
y = y + x[i]
elif self.fuse_method == 'CAT':
y = []
for i in range(self.num_branches):
if self.fuse_layers[i][0] is None:
y.append(x[i])
else:
y.append(self.fuse_layers[i][0](x[i]))
y = torch.cat(y, dim=1)
return y
class SeparableConv2d(nn.Module):
def __init__(self, in_channels, out_channels, kernel_size=3, stride=1, padding=1):
super(SeparableConv2d, self).__init__()
self.depthwise = nn.Conv2d(in_channels, in_channels, kernel_size=kernel_size, stride=stride, padding=padding, groups=in_channels)
self.pointwise = nn.Conv2d(in_channels, out_channels, kernel_size=1, stride=1, padding=0)
def forward(self, x):
x = self.depthwise(x)
x = self.pointwise(x)
return x
class Bottleneck(nn.Module):
expansion = 4
def __init__(self, inplanes, planes, stride=1, downsample=None):
super(Bottleneck, self).__init__()
self.conv1 = nn.Conv2d(inplanes, planes, kernel_size=1, bias=False)
self.bn1 = BatchNorm2d(planes, momentum=BN_MOMENTUM)
self.conv2 = SeparableConv2d(planes, planes, kernel_size=3, stride=stride, padding=1)
self.bn2 = BatchNorm2d(planes, momentum=BN_MOMENTUM)
self.conv3 = nn.Conv2d(planes, planes * 4, kernel_size=1, bias=False)
self.bn3 = BatchNorm2d(planes * 4, momentum=BN_MOMENTUM)
self.relu = nn.ReLU(inplace=True)
self.downsample = downsample
self.stride = stride
def forward(self, x):
residual = x
out = self.conv1(x)
out = self.bn1(out)
out = self.relu(out)
out = self.conv2(out)
out = self.bn2(out)
out = self.relu(out)
out = self.conv3(out)
out = self.bn3(out)
if self.downsample is not None:
residual = self.downsample(x)
out += residual
out = self.relu(out)
return out
解释:
- 深度可分离卷积:
- 将
Bottleneck模块中的conv2改为SeparableConv2d，将一个标准卷积分解成深度卷积和逐点卷积，减少参数数量和计算量。
- 将
- 跨层连接:
Bottleneck模块中的out += residual就是跨层连接，将输入特征直接加到输出特征上，加强特征传递和梯度流动。
注意:
- 代码中使用了
SeparableConv2d类来实现深度可分离卷积。 - 代码中还使用了一些其他的库和类，例如
BatchNorm2d和nn.Sequential，需要确保这些库和类已经正确导入。
通过使用深度可分离卷积和跨层连接，可以有效提高 HRNet 模型的性能，同时降低模型的复杂度。您还可以根据具体任务和数据进行其他调整和优化。
