Jupyter Notebook: Implementing a Variational Autoencoder (VAE) with Regression

import sys
sys.path.append('F:\python3\anaconda3\python.exe')
import tensorflow as tf

# keeping the random seed constant from one experiment to the next makes it
# easier to interpret the effects of hyper-parameters values
seed = 99
random.seed(seed)
tf.random.set_seed(seed)

def create_model(timesteps, input_dim, intermediate_dim, batch_size, latent_dim, epochs, optimizer):
    # Setup the network parameters:
    timesteps = timesteps
    input_dim = input_dim
    intermediate_dim = intermediate_dim
    batch_size = batch_size
    latent_dim = latent_dim
    epochs = epochs
    if optimizer == 'adam':
        optimizer = keras.optimizers.Adam(learning_rate=0.0001)
    else:
        print('unimplemented optimizer')
        exit(-1)
    masking_value = -99.

    class Sampling(keras.layers.Layer):
        '''Uses (z_mean, sigma) to sample z, the vector encoding an engine trajetory.'''
        def call(self, inputs):
            mu, sigma = inputs
            batch = tf.shape(mu)[0]
            dim = tf.shape(mu)[1]
            epsilon = tf.keras.backend.random_normal(shape=(batch, dim))
            return mu + tf.exp(0.5 * sigma) * epsilon

    inputs = Input(shape=(timesteps, input_dim,), name='encoder_input')

    mask = Masking(mask_value=masking_value)(inputs)

    # LSTM encoding
    h = Bidirectional(LSTM(intermediate_dim))(mask)

    # VAE Z layer
    mu = Dense(latent_dim)(h)
    sigma = Dense(latent_dim)(h)

    z = Sampling()([mu, sigma])

    # Instantiate the encoder model:
    encoder = keras.Model(inputs, [z, mu, sigma], name='encoder')
    print(encoder.summary())
    # -------------------------------------------------------

    # ----------------------- Regressor --------------------
    reg_latent_inputs = Input(shape=(latent_dim,), name='z_sampling_reg')
    reg_intermediate = Dense(200, activation='tanh')(reg_latent_inputs)
    reg_outputs = Dense(1, name='reg_output')(reg_intermediate)
    # Instantiate the classifier model:
    regressor = keras.Model(reg_latent_inputs, reg_outputs, name='regressor')
    print(regressor.summary())
    # -------------------------------------------------------

    ''' uncomment if needed
    # ----------------------- Decoder --------------------
    latent_inputs = Input(shape=(latent_dim,), name='z_sampling')
    h_decoded = RepeatVector(timesteps)(latent_inputs)
    h_decoded = Bidirectional(LSTM(intermediate_dim, return_sequences=True))(h_decoded)
    # decoded layer
    outputs = LSTM(input_dim, return_sequences=True)(h_decoded)
    # Instantiate the decoder model:
    decoder = keras.Model(latent_inputs, outputs, name='decoder')
    print(decoder.summary())
    # -------------------------------------------------------
    '''

    # -------------------- Wrapper model --------------------
    class RVAE(keras.Model):
        def __init__(self, encoder, regressor, decoder=None, **kwargs):
            super(RVAE, self).__init__(**kwargs)
            self.encoder = encoder
            self.regressor = regressor
            self.total_loss_tracker = keras.metrics.Mean(name='total_loss')
            self.kl_loss_tracker = keras.metrics.Mean(name='kl_loss')
            self.reg_loss_tracker = keras.metrics.Mean(name='reg_loss')
            self.decoder = decoder
            if self.decoder!=None:
                self.reconstruction_loss_tracker = keras.metrics.Mean(name='reconstruction_loss')


        @property
        def metrics(self):
            if self.decoder!=None:
                return [
                    self.total_loss_tracker,
                    self.kl_loss_tracker,
                    self.reg_loss_tracker,
                    self.reconstruction_loss_tracker
                ]
            else:
                return [
                    self.total_loss_tracker,
                    self.kl_loss_tracker,
                    self.reg_loss_tracker,
                ]

        def train_step(self, data):
            x, target_x = data
            with tf.GradientTape() as tape:
                # kl loss
                z, mu, sigma = self.encoder(x)
                kl_loss = -0.5 * (1 + sigma - tf.square(mu) - tf.exp(sigma))
                kl_loss = tf.reduce_mean(tf.reduce_sum(kl_loss, axis=1))
                # Regressor
                reg_prediction = self.regressor(z)
                reg_loss = tf.reduce_mean(
                    keras.losses.mse(target_x, reg_prediction)
                )
                # Reconstruction
                if self.decoder!=None:
                    reconstruction = self.decoder(z)
                    reconstruction_loss = tf.reduce_mean(
                        keras.losses.mse(x, reconstruction)
                    )
                    total_loss = kl_loss + reg_loss + reconstruction_loss
                    self.reconstruction_loss_tracker.update_state(reconstruction_loss)
                else:
                    total_loss = kl_loss + reg_loss
            grads = tape.gradient(total_loss, self.trainable_weights)
            self.optimizer.apply_gradients(zip(grads, self.trainable_weights))
            self.total_loss_tracker.update_state(total_loss)
            self.kl_loss_tracker.update_state(kl_loss)
            self.reg_loss_tracker.update_state(reg_loss)
            return {
                'loss': self.total_loss_tracker.result(),
                'kl_loss': self.kl_loss_tracker.result(),
                'reg_loss': self.reg_loss_tracker.result(),
            }


        def test_step(self, data):
            x, target_x = data

            # kl loss
            z, mu, sigma = self.encoder(x)
            kl_loss = -0.5 * (1 + sigma - tf.square(mu) - tf.exp(sigma))
            kl_loss = tf.reduce_mean(tf.reduce_sum(kl_loss, axis=1))
                # Regressor
            reg_prediction = self.regressor(z)
            reg_loss = tf.reduce_mean(
                keras.losses.mse(target_x, reg_prediction)
            )
            # Reconstruction
            if self.decoder!=None:
                reconstruction = self.decoder(z)
                reconstruction_loss = tf.reduce_mean(
                    keras.losses.mse(x, reconstruction)
                )
                total_loss = kl_loss + reg_loss + reconstruction_loss
            else:
                total_loss = kl_loss + reg_loss

            return {
                'loss': total_loss,
                'kl_loss': kl_loss,
                'reg_loss': reg_loss,
            }
    # -------------------------------------------------------

    vae = RVAE(encoder, regressor)
    vae.compile(optimizer=optimizer)

    return vae

The code imports the following libraries:

• sys
• tensorflow (imported as tf)
• keras (imported as part of tensorflow)
• random
