Variational Autoencoder (VAE) with Regressor for Time Series Data

The code is implementing a Variational Autoencoder (VAE) with a Regressor on top of the latent space. The VAE is composed of an Encoder and a Decoder. The Encoder takes in a time series of data and encodes it into a lower-dimensional latent space. The Decoder takes in a sample from the latent space and reconstructs the original time series data. The Regressor takes in a sample from the latent space and predicts a target value. The model is trained end-to-end to minimize the sum of the reconstruction error, the KL divergence between the learned latent distribution and a prior distribution, and the regression error. The training is performed using the ADAM optimizer. The code also includes a custom training loop and custom metrics for tracking the losses during training and evaluation.

import random
import tensorflow as tf
from tensorflow import keras
from tensorflow.keras.layers import Input, Dense, LSTM, Bidirectional, Masking

# keeping the random seed constant from one experiment to the next makes it
# easier to interpret the effects of hyper-parameters values
seed = 99
random.seed(seed)
tf.random.set_seed(seed)

def create_model(timesteps, input_dim, intermediate_dim, batch_size, latent_dim, epochs, optimizer):
	# Setup the network parameters:
	timesteps = timesteps
	input_dim = input_dim
	intermediate_dim = intermediate_dim
	batch_size = batch_size
	latent_dim = latent_dim
	epochs = epochs
	if optimizer == 'adam':
		optimizer = keras.optimizers.Adam(learning_rate=0.001)
	else:
		print("unimplemented optimizer")
		exit(-1)
	masking_value = -99.

	class Sampling(keras.layers.Layer):
		'''Uses (z_mean, sigma) to sample z, the vector encoding an engine trajetory.'''
		def call(self, inputs):
			mu, sigma = inputs
			batch = tf.shape(mu)[0]
			dim = tf.shape(mu)[1]
			epsilon = tf.keras.backend.random_normal(shape=(batch, dim))
			return mu + tf.exp(0.5 * sigma) * epsilon

	# ----------------------- Encoder -----------------------
	inputs = Input(shape=(timesteps, input_dim,), name='encoder_input')

	mask = Masking(mask_value=masking_value)(inputs)

	# LSTM encoding
	h = Bidirectional(LSTM(intermediate_dim))(mask)

	# VAE Z layer
	mu = Dense(latent_dim)(h)
	sigma = Dense(latent_dim)(h)

	z = Sampling()([mu, sigma])

	# Instantiate the encoder model:
	encoder = keras.Model(inputs, [z, mu, sigma], name='encoder')
	print(encoder.summary())
	# -------------------------------------------------------

	# ----------------------- Regressor --------------------
	reg_latent_inputs = Input(shape=(latent_dim,), name='z_sampling_reg')
	reg_intermediate = Dense(200, activation='tanh')(reg_latent_inputs)
	reg_outputs = Dense(1, name='reg_output')(reg_intermediate)
	# Instantiate the classifier model:
	regressor = keras.Model(reg_latent_inputs, reg_outputs, name='regressor')
	print(regressor.summary())
	# -------------------------------------------------------

	''' uncomment if needed
	# ----------------------- Decoder --------------------
	latent_inputs = Input(shape=(latent_dim,), name='z_sampling')
	h_decoded = RepeatVector(timesteps)(latent_inputs)
	h_decoded = Bidirectional(LSTM(intermediate_dim, return_sequences=True))(h_decoded)
	# decoded layer
	outputs = LSTM(input_dim, return_sequences=True)(h_decoded)
	# Instantiate the decoder model:
	decoder = keras.Model(latent_inputs, outputs, name='decoder')
	print(decoder.summary())
	# -------------------------------------------------------
	'''

	# -------------------- Wrapper model --------------------
	class RVE(keras.Model):
		def __init__(self, encoder, regressor, decoder=None, **kwargs):
			super(RVE, self).__init__(**kwargs)
			self.encoder = encoder
			self.regressor = regressor
			self.total_loss_tracker = keras.metrics.Mean(name="total_loss")
			self.kl_loss_tracker = keras.metrics.Mean(name="kl_loss")
			self.reg_loss_tracker = keras.metrics.Mean(name="reg_loss")
			self.decoder = decoder
			if self.decoder!=None:
				self.reconstruction_loss_tracker = keras.metrics.Mean(name="reconstruction_loss")


		@property
			def metrics(self):
				if self.decoder!=None:
					return [
						self.total_loss_tracker,
						self.kl_loss_tracker,
						self.reg_loss_tracker,
						self.reconstruction_loss_tracker
					]
				else:
					return [
						self.total_loss_tracker,
						self.kl_loss_tracker,
						self.reg_loss_tracker,
					]

		def train_step(self, data):
			x, target_x = data
			with tf.GradientTape() as tape:
				# kl loss
				z, mu, sigma = self.encoder(x)
				kl_loss = -0.5 * (1 + sigma - tf.square(mu) - tf.exp(sigma))
				kl_loss = tf.reduce_mean(tf.reduce_sum(kl_loss, axis=1))
				# Regressor
				reg_prediction = self.regressor(z)
				reg_loss = tf.reduce_mean(
					keras.losses.mse(target_x, reg_prediction)
				)
				# Reconstruction
				if self.decoder!=None:
					reconstruction = self.decoder(z)
					reconstruction_loss = tf.reduce_mean(
						keras.losses.mse(x, reconstruction)
					)
					total_loss = kl_loss + reg_loss + reconstruction_loss
					self.reconstruction_loss_tracker.update_state(reconstruction_loss)
				else:
					total_loss = kl_loss + reg_loss
			grads = tape.gradient(total_loss, self.trainable_weights)
			self.optimizer.apply_gradients(zip(grads, self.trainable_weights))
			self.total_loss_tracker.update_state(total_loss)
			self.kl_loss_tracker.update_state(kl_loss)
			self.reg_loss_tracker.update_state(reg_loss)
			return {
				"loss": self.total_loss_tracker.result(),
				"kl_loss": self.kl_loss_tracker.result(),
				"reg_loss": self.reg_loss_tracker.result(),
			}


		def test_step(self, data):
			x, target_x = data

			# kl loss
				z, mu, sigma = self.encoder(x)
				kl_loss = -0.5 * (1 + sigma - tf.square(mu) - tf.exp(sigma))
				kl_loss = tf.reduce_mean(tf.reduce_sum(kl_loss, axis=1))
				# Regressor
				reg_prediction = self.regressor(z)
				reg_loss = tf.reduce_mean(
					keras.losses.mse(target_x, reg_prediction)
				)
				# Reconstruction
				if self.decoder!=None:
					reconstruction = self.decoder(z)
					reconstruction_loss = tf.reduce_mean(
						keras.losses.mse(x, reconstruction)
					)
					total_loss = kl_loss + reg_loss + reconstruction_loss
				else:
					total_loss = kl_loss + reg_loss

			return {
				"loss": total_loss,
				"kl_loss": kl_loss,
				"reg_loss": reg_loss,
			}
	# -------------------------------------------------------

	rve = RVE(encoder, regressor)
	rve.compile(optimizer=optimizer)

	return rve
