Variational Autoencoder with Regressor for Time Series Data

This code defines a function create_model that creates a Variational Autoencoder (VAE) with a regressor. The VAE is used to encode time series data into a lower-dimensional latent space, which is then fed into a regressor to predict a target variable. The VAE is implemented using an encoder-decoder architecture, where the encoder is a Bidirectional LSTM that maps the input time series to a latent space, and the decoder is another LSTM that maps the latent space back to the original time series. However, the decoder is commented out in this code, indicating that it is not being used. The VAE is trained using a loss function that includes a reconstruction loss (when the decoder is used), a KL divergence loss to ensure the latent space is normally distributed, and a regression loss to predict the target variable. The model is trained using the train_step function and tested using the test_step function. The model is compiled using an optimizer, which is either Adam or an error message is printed.

import random
import tensorflow as tf
from tensorflow import keras
from tensorflow.keras.layers import Input, Dense, LSTM, Bidirectional, Masking

# keeping the random seed constant from one experiment to the next makes it
# easier to interpret the effects of hyper-parameters values
seed = 99
random.seed(seed)
tf.random.set_seed(seed)

def create_model(timesteps, input_dim, intermediate_dim, batch_size, latent_dim, epochs, optimizer):
	# Setup the network parameters:
	timesteps = timesteps
	input_dim = input_dim
	intermediate_dim = intermediate_dim
	batch_size = batch_size
	latent_dim = latent_dim
	epochs = epochs
	if optimizer == 'adam':
		optimizer = keras.optimizers.Adam(learning_rate=0.001)
	else:
		print('unimplemented optimizer')
		exit(-1)
	masking_value = -99.

	class Sampling(keras.layers.Layer):
		'''Uses (z_mean, sigma) to sample z, the vector encoding an engine trajetory.'''
		def call(self, inputs):
			mu, sigma = inputs
			batch = tf.shape(mu)[0]
			dim = tf.shape(mu)[1]
			epsilon = tf.keras.backend.random_normal(shape=(batch, dim))
			return mu + tf.exp(0.5 * sigma) * epsilon

	# ----------------------- Encoder -----------------------
	inputs = Input(shape=(timesteps, input_dim,), name='encoder_input')

	mask = Masking(mask_value=masking_value)(inputs)

	# LSTM encoding
	h = Bidirectional(LSTM(intermediate_dim))(mask)

	# VAE Z layer
	mu = Dense(latent_dim)(h)
	sigma = Dense(latent_dim)(h)

	z = Sampling()([mu, sigma])

	# Instantiate the encoder model:
	encoder = keras.Model(inputs, [z, mu, sigma], name='encoder')
	print(encoder.summary())
	# -------------------------------------------------------

	# ----------------------- Regressor --------------------
	reg_latent_inputs = Input(shape=(latent_dim,), name='z_sampling_reg')
	reg_intermediate = Dense(200, activation='tanh')(reg_latent_inputs)
	reg_outputs = Dense(1, name='reg_output')(reg_intermediate)
	# Instantiate the classifier model:
	regressor = keras.Model(reg_latent_inputs, reg_outputs, name='regressor')
	print(regressor.summary())
	# -------------------------------------------------------

	''' uncomment if needed
	# ----------------------- Decoder --------------------
	latent_inputs = Input(shape=(latent_dim,), name='z_sampling')
	h_decoded = RepeatVector(timesteps)(latent_inputs)
	h_decoded = Bidirectional(LSTM(intermediate_dim, return_sequences=True))(h_decoded)
	# decoded layer
	outputs = LSTM(input_dim, return_sequences=True)(h_decoded)
	# Instantiate the decoder model:
	decoder = keras.Model(latent_inputs, outputs, name='decoder')
	print(decoder.summary())
	# -------------------------------------------------------
	'''

	# -------------------- Wrapper model --------------------
	class RVE(keras.Model):
		def __init__(self, encoder, regressor, decoder=None, **kwargs):
			super(RVE, self).__init__(**kwargs)
			self.encoder = encoder
			self.regressor = regressor
			self.total_loss_tracker = keras.metrics.Mean(name='total_loss')
			self.kl_loss_tracker = keras.metrics.Mean(name='kl_loss')
			self.reg_loss_tracker = keras.metrics.Mean(name='reg_loss')
			self.decoder = decoder
			if self.decoder!=None:
				self.reconstruction_loss_tracker = keras.metrics.Mean(name='reconstruction_loss')


		@property
			def metrics(self):
				if self.decoder!=None:
					return [
						self.total_loss_tracker,
						self.kl_loss_tracker,
						self.reg_loss_tracker,
						self.reconstruction_loss_tracker
					]
				else:
					return [
						self.total_loss_tracker,
						self.kl_loss_tracker,
						self.reg_loss_tracker,
					]

		def train_step(self, data):
			x, target_x = data
			with tf.GradientTape() as tape:
				# kl loss
				z, mu, sigma = self.encoder(x)
				kl_loss = -0.5 * (1 + sigma - tf.square(mu) - tf.exp(sigma))
				kl_loss = tf.reduce_mean(tf.reduce_sum(kl_loss, axis=1))
				# Regressor
				reg_prediction = self.regressor(z)
				reg_loss = tf.reduce_mean(
					keras.losses.mse(target_x, reg_prediction)
				)
				# Reconstruction
				if self.decoder!=None:
					reconstruction = self.decoder(z)
					reconstruction_loss = tf.reduce_mean(
						keras.losses.mse(x, reconstruction)
					)
					total_loss = kl_loss + reg_loss + reconstruction_loss
					self.reconstruction_loss_tracker.update_state(reconstruction_loss)
				else:
					total_loss = kl_loss + reg_loss
			grads = tape.gradient(total_loss, self.trainable_weights)
			self.optimizer.apply_gradients(zip(grads, self.trainable_weights))
			self.total_loss_tracker.update_state(total_loss)
			self.kl_loss_tracker.update_state(kl_loss)
			self.reg_loss_tracker.update_state(reg_loss)
			return {
				'loss': self.total_loss_tracker.result(),
				'kl_loss': self.kl_loss_tracker.result(),
				'reg_loss': self.reg_loss_tracker.result(),
			}


		def test_step(self, data):
			x, target_x = data

			# kl loss
				z, mu, sigma = self.encoder(x)
				kl_loss = -0.5 * (1 + sigma - tf.square(mu) - tf.exp(sigma))
				kl_loss = tf.reduce_mean(tf.reduce_sum(kl_loss, axis=1))
				# Regressor
				reg_prediction = self.regressor(z)
				reg_loss = tf.reduce_mean(
					keras.losses.mse(target_x, reg_prediction)
				)
				# Reconstruction
				if self.decoder!=None:
					reconstruction = self.decoder(z)
					reconstruction_loss = tf.reduce_mean(
						keras.losses.mse(x, reconstruction)
					)
					total_loss = kl_loss + reg_loss + reconstruction_loss
				else:
					total_loss = kl_loss + reg_loss

			return {
				'loss': total_loss,
				'kl_loss': kl_loss,
				'reg_loss': reg_loss,
			}
	# -------------------------------------------------------

	rve = RVE(encoder, regressor)
	rve.compile(optimizer=optimizer)

	return rve
