ROS2 雷达跟踪数据转换节点

这个 ROS2 节点将雷达跟踪数据转换为跟踪对象消息。它订阅雷达跟踪数据和里程计数据，然后将雷达跟踪数据转换为跟踪对象消息并发布到指定的主题。

功能

  • 将雷达跟踪数据（RadarTracks 消息）转换为跟踪对象数据（TrackedObjects 消息）。
  • 使用 tf2 将雷达坐标系中的数据转换为指定坐标系中的数据。
  • 支持使用里程计数据进行速度补偿。

参数

  • update_rate_hz (double): 更新频率，默认为 20Hz。
  • new_frame_id (string): 输出坐标系，默认为 base_link。
  • use_twist_compensation (bool): 是否使用里程计数据进行速度补偿，默认为 false。

订阅主题

  • ~/input/radar_objects (RadarTracks 消息): 雷达跟踪数据。
  • ~/input/odometry (Odometry 消息): 里程计数据（用于速度补偿）。

发布主题

  • ~/output/radar_objects (TrackedObjects 消息): 转换后的跟踪对象数据。

代码示例

// Copyright 2022 TIER IV, Inc.
//
// Licensed under the Apache License, Version 2.0 (the 'License');
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//     http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an 'AS IS' BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.

#include "radar_tracks_msgs_converter/radar_tracks_msgs_converter_node.hpp"

#include <tf2/utils.h>

#ifdef ROS_DISTRO_GALACTIC
#include <tf2_geometry_msgs/tf2_geometry_msgs.h>
#else
#include <tf2_geometry_msgs/tf2_geometry_msgs.hpp>
#endif

#include <memory>
#include <string>
#include <vector>

using namespace std::literals;
using std::chrono::duration;
using std::chrono::duration_cast;
using std::chrono::nanoseconds;
using std::placeholders::_1;

namespace
{
template <class T>
bol update_param(
  const std::vector<rclcpp::Parameter> & params, const std::string & name, T & value)
{
  const auto itr = std::find_if(
    params.cbegin(), params.cend(),
    [&name](const rclcpp::Parameter & p) { return p.get_name() == name; });

  // Not found
  if (itr == params.cend()) {
    return false;
  }

  value = itr->template get_value<T>();
  return true;
}
}  // namespace

namespace radar_tracks_msgs_converter
{

enum class RadarTrackObjectID {
  UNKNOWN = 32000,
  CAR = 32001,
  TRUCK = 32002,
  BUS = 32003,
  TRAILER = 32004,
  MOTORCYCLE = 32005,
  BICYCLE = 32006,
  PEDESTRIAN = 32007
};

RadarTracksMsgsConverterNode::RadarTracksMsgsConverterNode(const rclcpp::NodeOptions & node_options)
: Node("radar_tracks_msgs_converter", node_options)
{
  // Parameter Server
  set_param_res_ = this->add_on_set_parameters_callback(
    std::bind(&RadarTracksMsgsConverterNode::onSetParam, this, _1));

  // Node Parameter
  node_param_.update_rate_hz = declare_parameter<double>("update_rate_hz", 20.0);
  node_param_.new_frame_id = declare_parameter<std::string>("new_frame_id", "base_link");
  node_param_.use_twist_compensation = declare_parameter<bool>("use_twist_compensation", false);

  // Subscriber
  sub_radar_ = create_subscription<RadarTracks>
    ("~/input/radar_objects", rclcpp::QoS{1},
    std::bind(&RadarTracksMsgsConverterNode::onRadarTracks, this, _1));
  sub_odometry_ = create_subscription<Odometry>
    ("~/input/odometry", rclcpp::QoS{1},
    std::bind(&RadarTracksMsgsConverterNode::onTwist, this, _1));
  transform_listener_ = std::make_shared<tier4_autoware_utils::TransformListener>(this);

  // Publisher
  pub_radar_ = create_publisher<TrackedObjects>("~/output/radar_objects", 1);

  // Timer
  const auto update_period_ns = rclcpp::Rate(node_param_.update_rate_hz).period();
  timer_ = rclcpp::create_timer(
    this, get_clock(), update_period_ns, std::bind(&RadarTracksMsgsConverterNode::onTimer, this));
}

void RadarTracksMsgsConverterNode::onRadarTracks(const RadarTracks::ConstSharedPtr msg)
{
  radar_data_ = msg;
}

void RadarTracksMsgsConverterNode::onTwist(const Odometry::ConstSharedPtr msg)
{
  odometry_data_ = msg;
}

rcl_interfaces::msg::SetParametersResult RadarTracksMsgsConverterNode::onSetParam(
  const std::vector<rclcpp::Parameter> & params)
{
  rcl_interfaces::msg::SetParametersResult result;

  try {
    // Node Parameter
    {
      auto & p = node_param_;

      // Update params
      update_param(params, "update_rate_hz", p.update_rate_hz);
      update_param(params, "new_frame_id", p.new_frame_id);
      update_param(params, "use_twist_compensation", p.use_twist_compensation);
    }
  } catch (const rclcpp::exceptions::InvalidParameterTypeException & e) {
    result.successful = false;
    result.reason = e.what();
    return result;
  }

  result.successful = true;
  result.reason = "success";
  return result;
}

bol RadarTracksMsgsConverterNode::isDataReady()
{
  if (!radar_data_) {
    RCLCPP_INFO_THROTTLE(get_logger(), *get_clock(), 1000, "waiting for radar msg...");
    return false;
  }

  return true;
}

void RadarTracksMsgsConverterNode::onTimer()
{
  if (!isDataReady()) {
    return;
  }
  const auto & header = radar_data_->header;
  transform_ = transform_listener_->getTransform(
    node_param_.new_frame_id, header.frame_id, header.stamp, rclcpp::Duration::from_seconds(0.01));

  TrackedObjects tracked_objects = convertRadarTrackToTrackedObjects();
  if (!tracked_objects.objects.empty()) {
    pub_radar_->publish(tracked_objects);
  }
}

TrackedObjects RadarTracksMsgsConverterNode::convertRadarTrackToTrackedObjects()
{
  TrackedObjects tracked_objects;
  tracked_objects.header = radar_data_->header;
  tracked_objects.header.frame_id = node_param_.new_frame_id;
  using POSE_IDX = tier4_autoware_utils::xyzrpy_covariance_index::XYZRPY_COV_IDX;
  using RADAR_IDX = tier4_autoware_utils::xyz_upper_covariance_index::XYZ_UPPER_COV_IDX;

  for (auto & radar_track : radar_data_->tracks) {
    TrackedObject tracked_object;

    tracked_object.object_id = radar_track.uuid;
    tracked_object.existence_probability = 1.0;

    tracked_object.shape.type = Shape::BOUNDING_BOX;
    tracked_object.shape.dimensions = radar_track.size;

    // kinematics
    TrackedObjectKinematics kinematics;
    kinematics.orientation_availability = TrackedObjectKinematics::AVAILABLE;
    kinematics.is_stationary = false;

    // convert by tf
    geometry_msgs::msg::PoseStamped radar_pose_stamped{};
    radar_pose_stamped.pose.position = radar_track.position;
    geometry_msgs::msg::PoseStamped transformed_pose_stamped{};
    tf2::doTransform(radar_pose_stamped, transformed_pose_stamped, *transform_);
    kinematics.pose_with_covariance.pose = transformed_pose_stamped.pose;

    {
      auto & pose_cov = kinematics.pose_with_covariance.covariance;
      auto & radar_position_cov = radar_track.position_covariance;
      pose_cov[POSE_IDX::X_X] = radar_position_cov[RADAR_IDX::X_X];
      pose_cov[POSE_IDX::X_Y] = radar_position_cov[RADAR_IDX::X_Y];
      pose_cov[POSE_IDX::X_Z] = radar_position_cov[RADAR_IDX::X_Z];
      pose_cov[POSE_IDX::Y_X] = radar_position_cov[RADAR_IDX::X_Y];
      pose_cov[POSE_IDX::Y_Y] = radar_position_cov[RADAR_IDX::Y_Y];
      pose_cov[POSE_IDX::Y_Z] = radar_position_cov[RADAR_IDX::Y_Z];
      pose_cov[POSE_IDX::Z_X] = radar_position_cov[RADAR_IDX::X_Z];
      pose_cov[POSE_IDX::Z_Y] = radar_position_cov[RADAR_IDX::Y_Z];
      pose_cov[POSE_IDX::Z_Z] = radar_position_cov[RADAR_IDX::Z_Z];
    }

    // convert by tf
    geometry_msgs::msg::Vector3Stamped radar_velocity_stamped{};
    radar_velocity_stamped.vector = radar_track.velocity;
    geometry_msgs::msg::Vector3Stamped transformed_vector3_stamped{};
    tf2::doTransform(radar_velocity_stamped, transformed_vector3_stamped, *transform_);
    kinematics.twist_with_covariance.twist.linear = transformed_vector3_stamped.vector;

    // twist compensation
    if (node_param_.use_twist_compensation) {
      if (odometry_data_) {
        kinematics.twist_with_covariance.twist.linear.x += odometry_data_->twist.twist.linear.x;
        kinematics.twist_with_covariance.twist.linear.y += odometry_data_->twist.twist.linear.y;
        kinematics.twist_with_covariance.twist.linear.z += odometry_data_->twist.twist.linear.z;
      } else {
        RCLCPP_INFO(get_logger(), "Odometry data is not coming");
      }
    }

    {
      auto & twist_cov = kinematics.twist_with_covariance.covariance;
      auto & radar_vel_cov = radar_track.velocity_covariance;
      twist_cov[POSE_IDX::X_X] = radar_vel_cov[RADAR_IDX::X_X];
      twist_cov[POSE_IDX::X_Y] = radar_vel_cov[RADAR_IDX::X_Y];
      twist_cov[POSE_IDX::X_Z] = radar_vel_cov[RADAR_IDX::X_Z];
      twist_cov[POSE_IDX::Y_X] = radar_vel_cov[RADAR_IDX::X_Y];
      twist_cov[POSE_IDX::Y_Y] = radar_vel_cov[RADAR_IDX::Y_Y];
      twist_cov[POSE_IDX::Y_Z] = radar_vel_cov[RADAR_IDX::Y_Z];
      twist_cov[POSE_IDX::Z_X] = radar_vel_cov[RADAR_IDX::X_Z];
      twist_cov[POSE_IDX::Z_Y] = radar_vel_cov[RADAR_IDX::Y_Z];
      twist_cov[POSE_IDX::Z_Z] = radar_vel_cov[RADAR_IDX::Z_Z];
    }
    {
      auto & accel_cov = kinematics.acceleration_with_covariance.covariance;
      auto & radar_accel_cov = radar_track.acceleration_covariance;
      accel_cov[POSE_IDX::X_X] = radar_accel_cov[RADAR_IDX::X_X];
      accel_cov[POSE_IDX::X_Y] = radar_accel_cov[RADAR_IDX::X_Y];
      accel_cov[POSE_IDX::X_Z] = radar_accel_cov[RADAR_IDX::X_Z];
      accel_cov[POSE_IDX::Y_X] = radar_accel_cov[RADAR_IDX::X_Y];
      accel_cov[POSE_IDX::Y_Y] = radar_accel_cov[RADAR_IDX::Y_Y];
      accel_cov[POSE_IDX::Y_Z] = radar_accel_cov[RADAR_IDX::Y_Z];
      accel_cov[POSE_IDX::Z_X] = radar_accel_cov[RADAR_IDX::X_Z];
      accel_cov[POSE_IDX::Z_Y] = radar_accel_cov[RADAR_IDX::Y_Z];
      accel_cov[POSE_IDX::Z_Z] = radar_accel_cov[RADAR_IDX::Z_Z];
    }

    tracked_object.kinematics = kinematics;

    // classification
    ObjectClassification classification;
    classification.probability = 1.0;
    classification.label = convertClassification(radar_track.classification);
    tracked_object.classification.emplace_back(classification);

    tracked_objects.objects.emplace_back(tracked_object);
  }
  return tracked_objects;
}

uint8_t RadarTracksMsgsConverterNode::convertClassification(const uint16_t classification)
{
  if (classification == static_cast<uint16_t>(RadarTrackObjectID::UNKNOWN)) {
    return ObjectClassification::UNKNOWN;
  } else if (classification == static_cast<uint16_t>(RadarTrackObjectID::CAR)) {
    return ObjectClassification::CAR;
  } else if (classification == static_cast<uint16_t>(RadarTrackObjectID::TRUCK)) {
    return ObjectClassification::TRUCK;
  } else if (classification == static_cast<uint16_t>(RadarTrackObjectID::BUS)) {
    return ObjectClassification::BUS;
  } else if (classification == static_cast<uint16_t>(RadarTrackObjectID::TRAILER)) {
    return ObjectClassification::TRAILER;
  } else if (classification == static_cast<uint16_t>(RadarTrackObjectID::MOTORCYCLE)) {
    return ObjectClassification::MOTORCYCLE;
  } else if (classification == static_cast<uint16_t>(RadarTrackObjectID::BICYCLE)) {
    return ObjectClassification::BICYCLE;
  } else if (classification == static_cast<uint16_t>(RadarTrackObjectID::PEDESTRIAN)) {
    return ObjectClassification::PEDESTRIAN;
  } else {
    RCLCPP_INFO_THROTTLE(get_logger(), *get_clock(), 1000, "Receive unknown label for RadarTracks");
    return ObjectClassification::UNKNOWN;
  }
}

}  // namespace radar_tracks_msgs_converter

#include "rclcpp_components/register_node_macro.hpp"
RCLCPP_COMPONENTS_REGISTER_NODE(radar_tracks_msgs_converter::RadarTracksMsgsConverterNode)

使用方法

  1. 在你的 ROS2 工作空间中创建一个新的包，例如 radar_tracks_msgs_converter_example。
  2. 在 package.xml 文件中添加对 radar_tracks_msgs_converter 包的依赖。
  3. 在你的包的 launch 文件夹中创建一个启动文件，例如 launch/radar_tracks_msgs_converter.launch.py。
  4. 在启动文件中使用以下代码启动节点：
from launch import LaunchDescription
from launch_ros.actions import Node

def generate_launch_description():
  return LaunchDescription([
    Node(
      package='radar_tracks_msgs_converter',
      executable='radar_tracks_msgs_converter_node',
      name='radar_tracks_msgs_converter',
      output='screen',
      parameters=[{'update_rate_hz': 20.0},
                  {'new_frame_id': 'base_link'},
                  {'use_twist_compensation': False}]
    )
  ])
  1. 运行启动文件：
ros2 launch radar_tracks_msgs_converter_example radar_tracks_msgs_converter.launch.py

说明

  • 该节点使用 tier4_autoware_utils 包中的 TransformListener 类来获取坐标系转换信息。
  • 该节点使用 rclcpp::Rate 类来控制更新频率。
  • 该节点使用 std::bind 函数来绑定回调函数。
  • 该节点使用 rclcpp::create_timer 函数来创建一个定时器。
  • 该节点使用 rclcpp::declare_parameter 函数来声明节点参数。
  • 该节点使用 rclcpp::add_on_set_parameters_callback 函数来注册参数回调函数。
  • 该节点使用 rclcpp::create_subscription 函数来创建订阅者。
  • 该节点使用 rclcpp::create_publisher 函数来创建发布者。

总结

这个 ROS2 节点可以将雷达跟踪数据转换为跟踪对象消息，并提供了一些参数来定制节点的行为。该节点可以用于自动驾驶系统中，以将雷达传感器的数据转换为更易于使用的形式。

ROS2 雷达跟踪数据转换节点 - 将雷达跟踪数据转换为跟踪对象消息

原文地址: https://www.cveoy.top/t/topic/jFy7 著作权归作者所有。请勿转载和采集!

免费AI点我,无需注册和登录
