WPF 数据行控件定义及布局示例

以下代码展示了如何使用 WPF 控件定义和布局一个数据行，每个字段之间用 Border 添加一行一竖的格式。代码中只展示了每个字段的定义和添加到 Grid 中的代码。其中包括日期选择器、下拉框、文本框、按钮和图片等控件，用于实现对光源设备的控制和监测。同时，每个控件都设置了相应的属性，如 Margin、VerticalAlignment、Name 等，以及事件处理函数，如 Click、PreviewMouseLeftButtonDown 等，用于实现相应的功能。最终，这些控件被添加到一个 Grid 中，形成了一个完整的数据行。

public RowInfo()
{
    Panel = new Grid
    {
        Margin = thickness
    };
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(30) });
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(140) });
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(140) });
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(width) });
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(width) });
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(70) });
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(70) });
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(120) });
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(width) });
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(140) });
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(100) });
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(width) });
    Panel.ColumnDefinitions.Add(new ColumnDefinition { Width = new GridLength(50) });

    //序号
    var serialNumber = new TextBlock
    {
        Margin = thickness,
        VerticalAlignment = VerticalAlignment.Center
    };
    Panel.Children.Add(serialNumber);
    Grid.SetColumn(serialNumber, 0);

    //开始日期
    var startDate = new DatePicker
    {
        Margin = thickness,
        VerticalAlignment = VerticalAlignment.Center,
        Name = 'startDate'
    };
    Panel.Children.Add(startDate);
    Grid.SetColumn(startDate, 1);

    //结束日期
    var endDate = new DatePicker
    {
        Margin = thickness,
        VerticalAlignment = VerticalAlignment.Center,
        Name = 'endDate'
    };
    Panel.Children.Add(endDate);
    Grid.SetColumn(endDate, 2);

    //电源设备
    var PowerSupplyEquipment = new ComboBox
    {
        Margin = thickness,
        VerticalAlignment = VerticalAlignment.Center,
        ItemsSource = new[] { '光源1', '光源2', '光源3', '光源4', '光源5', '光源6', '光源7', '光源8', '光源9', '光源10', '光源11', '光源12', '光源13', '光源14', '光源15', '光源16', '光源17', '光源18', '光源19', '光源20' },
        Name = 'PowerSupplyEquipment'
    };
    Panel.Children.Add(PowerSupplyEquipment);
    Grid.SetColumn(PowerSupplyEquipment, 3);

    //端口号
    var port = new ComboBox
    {
        Margin = thickness,
        VerticalAlignment = VerticalAlignment.Center,
        Name = 'port'
    };
    port.PreviewMouseLeftButtonDown += CurrentTextBox_PreviewMouseLeftButtonDown;
    Panel.Children.Add(port);
    Grid.SetColumn(port, 4);

    //电流
    var current = new TextBox
    {
        Margin = thickness,
        VerticalAlignment = VerticalAlignment.Center,
        HorizontalContentAlignment = HorizontalAlignment.Center,
        Name = 'current'
    };
    Panel.Children.Add(current);
    Grid.SetColumn(current, 5);

    //电压
    var voltage = new TextBox
    {
        Margin = thickness,
        VerticalAlignment = VerticalAlignment.Center,
        HorizontalContentAlignment = HorizontalAlignment.Center,
        Name = 'voltage'
    };
    Panel.Children.Add(voltage);
    Grid.SetColumn(voltage, 6);

    //泵异常温度
    var pumpAbnormalTemperature = new TextBox
    {
        Margin = thickness,
        VerticalAlignment = VerticalAlignment.Center,
        HorizontalContentAlignment = HorizontalAlignment.Center,
        Name = 'pumpAbnormalTemperature'
    };
    Panel.Children.Add(pumpAbnormalTemperature);
    Grid.SetColumn(pumpAbnormalTemperature, 7);

    //泵温度
    var pumpTemperature = new TextBox
    {
        Margin = thickness,
        VerticalAlignment = VerticalAlignment.Center,
        HorizontalContentAlignment = HorizontalAlignment.Center,
        Name = 'pumpTemperature'
    };
    Panel.Children.Add(pumpTemperature);
    Grid.SetColumn(pumpTemperature, 8);

    //功率异常值
    var powerAbnormalValue = new TextBox
    {
        Margin = thickness,
        VerticalAlignment = VerticalAlignment.Center,
        HorizontalContentAlignment = HorizontalAlignment.Center,
        Name = 'powerAbnormalValue'
    };
    Panel.Children.Add(powerAbnormalValue);
    Grid.SetColumn(powerAbnormalValue, 9);

    //功率值
    var powerValue = new TextBox
    {
        Margin = thickness,
        VerticalAlignment = VerticalAlignment.Center,
        HorizontalContentAlignment = HorizontalAlignment.Center,
        Name = 'powerValue'
    };
    Panel.Children.Add(powerValue);
    Grid.SetColumn(powerValue, 10);

     //开关
    var switchButton = new Button
    {
        Content = '开',
        Margin = thickness,
        VerticalAlignment = VerticalAlignment.Center,
        HorizontalContentAlignment = HorizontalAlignment.Center,
        Style = (Style)FindResource('butt')
    };
    switchButton.Click += SwitchButton_Click;
    Panel.Children.Add(switchButton);
    Grid.SetColumn(switchButton, 11);

    //开光图片
    var image = new Image
    {
        Source = new BitmapImage(new Uri('pack://application:,,,/img/led_gray.png')),
        Width = 30,
        Height = 30
    };
    image.Name = 'isImg';
    Panel.Children.Add(image);
    Grid.SetColumn(image, 12);
}

以上代码展示了一个数据行的控件定义和布局示例，您可以根据您的需求进行调整和扩展。
