用c语言编写一个程序使得在6818开发板上点击一次屏幕换一种随机颜色。
以下是一个示例程序,使用C语言在6818开发板上实现点击屏幕后随机更换颜色的功能:
#include <stdio.h>
#include <stdlib.h>
#include <fcntl.h>
#include <unistd.h>
#define FB_DEV "/dev/fb0"
// 获取随机颜色值
unsigned int get_random_color() {
return rand() % (1 << 24);
}
// 设置像素点颜色
void set_pixel_color(unsigned char *fbp, int x, int y, unsigned int color) {
long location = (x + y * 800) * 4;
*((unsigned int*)(fbp + location)) = color;
}
int main() {
int fbfd = open(FB_DEV, O_RDWR);
if (fbfd == -1) {
perror("Error: cannot open framebuffer device");
exit(1);
}
unsigned char *fbp = (unsigned char *)mmap(0, 800 * 480 * 4, PROT_READ | PROT_WRITE, MAP_SHARED, fbfd, 0);
if (fbp == MAP_FAILED) {
perror("Error: failed to map framebuffer device to memory");
exit(1);
}
srand(time(NULL)); // 设置随机数种子
while (1) {
// 等待点击事件
// 此处省略相关代码,可以使用6818开发板上的触摸屏库函数来实现
// 获取随机颜色
unsigned int color = get_random_color();
// 更换屏幕颜色
for (int y = 0; y < 480; y++) {
for (int x = 0; x < 800; x++) {
set_pixel_color(fbp, x, y, color);
}
}
}
munmap(fbp, 800 * 480 * 4);
close(fbfd);
return 0;
}
请注意,此示例程序假设您已经配置好了6818开发板的触摸屏和帧缓冲设备,并具备了相关的开发环境和库函数。如果您的开发环境和硬件配置不同,请根据实际情况进行相应的修改和适配
