The circuit depicted in Figure 16 is a representation of a single output buffer. Each buffer is powered by OVDD and OGND, which are separate from the power and ground of the ADC. The presence of an extra N-channel transistor in the output driver enables operation at low voltages. The inclusion of an internal resistor in series with the output results in the output appearing as 50Ω to external circuitry, potentially eliminating the requirement for external damping resistors.

Please paraphrase the following paragraphFigure 16 shows an equivalent circuit for a single output buffer Each buffer is powered by OVDD and OGND isolated from the ADC power and ground The additional
